Genuine H4110020109A0 Fuel Tank Assembly: Complete Fuel Storage Solution for FOTON Trucks

Complete System Overview and Critical Functions

The Fuel Tank Assembly, identified by the precise OEM number H4110020109A0, is a fully integrated unit that replaces the entire primary fuel storage and preliminary delivery system on specific FOTON truck models. Unlike replacing individual components, this assembly provides a complete solution. It typically includes the main fuel tank reservoir, internal baffles, fuel pickup unit and sender (fuel level sensor), fuel supply and return lines, tank mounting brackets, vent lines, and often the fuel cap assembly. The primary function of the H4110020109A0 is to safely store a large volume of diesel fuel, ensure a consistent and air bubble-free supply to the engine’s injection system, and accurately relay fuel level data to the vehicle’s instrument cluster.

The design of the H4110020109A0 addresses critical challenges in heavy-duty vehicles. Internal baffles prevent fuel sloshing, which can affect vehicle stability and cause inaccurate fuel readings. The pickup unit is positioned to maximize fuel usage and prevent air ingress. The assembly is engineered to integrate seamlessly with the vehicle’s chassis, fuel lines, and electrical system. For operators dealing with a damaged, leaking, or corroded tank, replacing it with the complete H4110020109A0 assembly is the most efficient and reliable repair method, ensuring all sub-components are new, compatible, and function as an integrated system.

Robust Construction and Advanced Material Technology

The genuine H4110020109A0 is built for maximum durability and safety. The tank body is traditionally constructed from high-quality, corrosion-resistant materials. For modern FOTON trucks, this is often cross-linked polyethylene (XLPE) or coated steel. XLPE offers excellent impact resistance, is immune to rust, and is non-corrosive when in contact with diesel and biodiesel blends. Steel tanks are made from treated steel sheets with robust internal and external coatings for corrosion protection. The tank is manufactured using advanced techniques like rotational molding (for plastic) or welding and pressure testing (for metal) to ensure it is leak-proof and can withstand the vibrations and shocks of off-road and highway use.

Integrated into the H4110020109A0 are high-quality components. The fuel level sender is a precision instrument that provides accurate readings. All fittings, bungs, and ports are pre-installed and sealed at the factory to prevent leaks. Mounting brackets are welded or molded in place, designed to match the vehicle’s chassis perfectly. Vent lines and rollover valves are included to manage tank pressure and prevent fuel spillage in case of an accident. Every aspect of the H4110020109A0’s construction is focused on creating a sealed, secure, and long-lasting fuel storage system that meets strict OEM safety and performance standards.

Technical Specifications: H4110020109A0 Assembly

Installation Process and Critical Pre-Installation Checks

Replacing a fuel tank assembly is a significant repair that requires proper preparation and safety procedures. Installation of the H4110020109A0 begins with safely draining and removing the old tank. The vehicle must be supported securely, and all fuel lines, electrical connections, and vent hoses disconnected. Before lifting the new H4110020109A0 into position, a thorough inspection is crucial. Check all fittings for tightness and ensure no shipping plugs remain in the ports. The mounting surfaces on the chassis should be cleaned and inspected for corrosion or damage.

The assembly is then carefully positioned, aligning the mounting brackets with the chassis holes. All bolts should be tightened to the specified torque to avoid stress cracks. Fuel lines and vent hoses must be reconnected securely using new clamps where recommended. The electrical connector for the sender unit must be engaged firmly. After installation, it is critical to prime the fuel system and check for leaks before starting the engine. A post-installation test drive should include monitoring the fuel gauge for accurate operation. Due to the weight and complexity, this job is best performed by a qualified technician with the right equipment.

Symptoms of a Failing Fuel Tank and Benefits of Complete Assembly Replacement

Several signs indicate the need for a fuel tank replacement. The most obvious is visible fuel leakage, often caused by corrosion, physical damage, or failed seam seals. A persistently inaccurate or non-functional fuel gauge frequently points to a faulty sender unit inside the tank. Contamination of fuel with rust, water, or debris often originates from a corroded tank interior. Difficulties in refueling, such as frequent pump nozzle shut-offs, can indicate a blocked or malfunctioning vent system within the assembly.

Opting for the complete H4110020109A0 assembly over patching or piecemeal repairs offers definitive benefits. It guarantees that all aging components (sender, lines, mounts) are renewed simultaneously, preventing near-future failures. It ensures perfect compatibility and fit, eliminating adaptation issues. Most importantly, it restores the fuel system to its original, leak-proof, and safe condition. For fleet managers, this comprehensive replacement minimizes vehicle downtime by addressing all potential failure points in one service event, providing long-term reliability and peace of mind.

The Superior Value of the Genuine H4110020109A0 Assembly

Choosing the authentic H4110020109A0 assembly is an investment in quality, safety, and total cost of ownership. Genuine FOTON parts are engineered and tested to withstand the specific vibrational, environmental, and load conditions of their trucks. The material specifications, weld integrity, and component quality are validated to OEM standards. This means the H4110020109A0 will have the correct internal baffling, the sender will provide accurate readings matched to the vehicle’s instrument cluster, and all ports will align perfectly with the existing fuel lines.

Aftermarket or generic tanks may have dimensional variances, inferior corrosion protection, or lack essential internal components, leading to installation challenges, premature failure, or even safety hazards. The genuine H4110020109A0 comes as a complete, ready-to-install kit, saving valuable workshop time. For owners and operators, this translates to a reliable repair that protects the significant investment in the vehicle, ensures compliance with safety regulations, and provides the performance longevity expected from a factory part. The avoidance of fuel leaks, inaccurate gauges, and contamination issues justifies the choice of the genuine assembly.

Conclusion: The Foundation of a Reliable Fuel System

The H4110020109A0 Fuel Tank Assembly is a critical investment in the operational integrity and safety of your FOTON truck. Its comprehensive, OEM-engineered design provides a complete solution for fuel storage and delivery, eliminating guesswork and ensuring perfect system integration. By choosing the genuine H4110020109A0, you secure a leak-proof, durable, and fully functional fuel system that supports maximum vehicle uptime and performance. Trust in the original factory specification to deliver the reliability your commercial operation depends on—specify the H4110020109A0 for your fuel system replacement needs.

Critical Note: Always confirm the application of part number H4110020109A0 using your truck’s VIN and an official FOTON parts catalog. Fuel system work involves flammable materials and should only be performed by qualified technicians following all safety protocols.
