XCMG Timing Box Gear

What is the XCMG Timing Box Gear

The XCMG Timing Box Gear assembly forms the critical heart of engine timing synchronization, integrating an IDLER WHEEL and OIL PUMP GEAR that work in perfect harmony to maintain precise component coordination. This sophisticated system utilizes a precisely machined SHAFT KIT supported by a structural PLATE and secured with multiple high-strength BOLT fasteners and WASHER elements. The incorporation of a specialized SEMI-CIRCLE KEY ensures positive rotational engagement between components, guaranteeing accurate timing alignment throughout the operational range. The robust construction and precision engineering of the XCMG Timing Box Gear ensure reliable power transmission and optimal engine performance, delivering exceptional durability and synchronization accuracy in demanding heavy machinery applications.

Parameters of XCMG Timing Box Gear

800169559 TIMING BOX GEAR
800160419 ENGINE ASSEMBLY
No.	PART NUMBER	NAME
1	800167964	IDLER WHEEL
2	800167910	SHAFT KIT
3	800167926	BOLT
4	800168241	PLATE
5	800168382	BOLT
6	800168271	OIL PUMP GEAR
7	800168330	SEMI-CIRCLE KEY
8	800168286	BOLT
9	800168175	WASHER
8	800168286	BOLT
10	800168049	CAMSHAFT GEAR
11	800168393	SET PIN
12	800168351	BOLT
13	800168295	PLATE
14	800168236	BOLT
15	800168098	WASHER
16	800167972	O-RING
17	800168196	O-RING
18	800168261	ADAPTER
5	800168382	BOLT
8	800168286	BOLT
19	800168141	IDLER WHEEL
20	800168142	ENGINE BLOCK
21	800168146	PLATE
22	800168265	WASHER
23	800168303	NUT
5	800168382	BOLT
8	800168286	BOLT
21	800168146	PLATE
22	800168265	WASHER
23	800168303	NUT
24	800168173	IDLER WHEEL
25	800168123	STUD BOLT
