Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)

Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)
Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)
Download Catalog
Get Quotation

What is the Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)

  • Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030): Heavy-Duty Performance for Unmatched Stability​
  • Engineered to meet the extreme demands of 38-ton heavy-duty mixing trucks, the Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension is a high-precision solution designed for maximum load-bearing capacity and stability. With specifications like 14-square configurations, 12×23×1350 plate spring dimensions, an 850 frame with 8+5 leaf spring setup, and a 1030mm plate spring distance, this suspension system integrates a comprehensive suite of components to ensure seamless operation, even under the most challenging conditions.​
  • Load-Bearing and Spring Components​
  • The Rear plate spring assembly forms the core of the suspension’s load-bearing capabilities. Comprising 12 robust leaf springs, each 23mm thick and 1350mm long, it evenly distributes the 38-ton load across the axles. The Four Riding Bolt Ball Iron Plate Spring Press Block, secured by Flange Nut M24*3 and Rear Spring Riding Bolt, compresses the springs, ensuring optimal tension and shock absorption. A Guide pin and Guide plate facilitate smooth movement, reducing friction and wear during dynamic operations.​
  • Structural Support and Limiting Mechanisms​
  • Limit Block Assembly and Limit bracket, fastened with Hexagon head bolts M14*1.5, prevent overextension of the springs, safeguarding the suspension from damage under heavy loads. The Balance shaft with housing assembly serves as the central pivot point, transferring forces between the axles and springs. Its high-strength alloy construction, combined with Lower thrust rod assembly, enhances lateral stability, minimizing body roll during sharp turns or uneven terrain traversal.​
  • Mounting and Fastening Systems​
  • The Rear leaf spring left rear bracket and Rear leaf spring right rear bracket (symmetrical with left part) provide secure mounting points for the leaf springs. These brackets, bolted with Hexagon head bolt M14*1.5, ensure a rigid connection to the vehicle frame. The Rubber support assembly, secured by Hexagon head bolt M22*1.5, cushions vibrations, reducing noise and protecting the frame from stress-induced damage.​
  • Thrust Rod and Anti-Loosening Components​
  • The V-type thrust rod assembly, connected by V-type thrust rod bolts and reinforced with an Anti-loosening sleeve, stabilizes the rear axles, preventing unwanted movement during acceleration, braking, or cornering. Hexagonal flange face bolts M20*1.5, Hexagonal flange face nuts M20*1.5, and Double head studs with Spring washers create a secure, vibration-resistant connection for the thrust rods. The Hexagonal flange bolts with teeth M16*1.5 and Type 2 hexagon nuts M16*1.5 further reinforce critical joints, ensuring long-term reliability.​
  • Precision Fasteners and Design Excellence​
  • A variety of precision fasteners, including Hexagon socket countersunk head screws and Hexagonal flange nuts with teeth M16*1.5, are used throughout the assembly to ensure tight, reliable connections. Each component, from the Thrust rod front left bracket to the Garden post pin–Pin GB119 A20*24, undergoes rigorous testing for strength and durability, meeting or exceeding industry standards. The system’s casting cross member (Mat16bg) and four-rider design optimize weight distribution, enhancing overall efficiency and reducing wear on tires and axles.​
  • SEO-Optimized Features for Commercial Relevance​
  • Keyword Precision: Prioritizes product model, technical specifications, and component names to dominate exact-match searches in parts catalogs and technical databases.​
  • Technical Depth: Highlights material science (alloy steel, rubber supports), load-bearing capacity, and anti-loosening technologies to attract mechanical professionals and fleet managers.​
  • Benefit-Driven Messaging: Emphasizes stability, durability, and reduced maintenance, addressing core concerns for operators of heavy-duty mixing trucks.​
  • In summary, the Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension sets a benchmark for heavy-duty performance, combining rugged construction, advanced engineering, and precision components. Trust in its reliability to keep your mixing trucks stable, efficient, and on the road—even under the most punishing loads and conditions.

Product Parameters of Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)

AC99255200318 Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)
Serial No. Drawing No.  Name Quantity
1 WG9725520489 Rear plate spring assembly 2
2 AZ992552000010 Four Riding Bolt Ball Iron Plate Spring Press Block 2
3 ZQ32724T13F3 Flange Nut M24*3 16
4 AZ9925521268 Rear Spring Riding Bolt 8
5 WG9000520006 Guide pin 4
6 WG9725523250 Guide plate 4
7 Q150B1260 Hexagon head bolts 16
8 WG9725520727 Limit Block Assembly 4
9 WG9725520730 Limit bracket 4
10 ZQ151B1460 Hexagon head bolts M14*1.5 4
11 ZQ151B1470 Hexagon head bolts M14*1.5 12
12 ZQ340B10 Type 1 hexagonal nut M10*1.5 16
13 ZQ361B14 Type 2 hexagonal nut M14*1.5 16
14 AZ9925520310 Balance shaft with housing assembly 2
15 AZ9925520655 Lower thrust rod assembly 4
16 WG9725520277 Rear leaf spring left rear bracket 2
17 WG9725520279 Rear leaf spring right rear bracket (symmetrical with left part) 2
18 ZQ151B1430TF6 Hexagon head bolt M14*1.5 16
19 AZ9725520683 Rubber support assembly 4
20 ZQ151B22280TF6 Hexagon head bolt M22*1.5 16
21 190003901905 Garden post pin–Pin GB119 A20*24 4
22 WG9725520590 Thrust rod front left bracket 4
23 ZQ361B22T13F6 Type 2 hexagonal nut M22*1.5 16
24 ZQ151B20100TF6 Hexagon head bolts M20*1.5 8
25 ZQ32320T13F6 Hexagonal flange face nuts M20*1.5 12
26 ZQ18520180TF6 Hexagonal flange face bolts M20*1.5 4
27 ZQ1811665TF6 Hexagonal flange face bolts with teeth M16*1.5 24
28 WG9925521007 Hexagon socket countersunk head screws 4
29 ZQ361B16T13F6 Type 2 hexagon nuts M16*1.5 4
30 ZQ32516T13F6 Hexagonal flange nuts with teeth M16*1.5 34
30 ZQ32516T13F6 Hexagonal flange nuts with teeth M16*1.5 16
31 ZQ1811680TF6 Hexagonal flange bolts with teeth M16*1.5 16
32 AZ9725529272 V-type thrust rod assembly 2
33 WG9725520114 V-type thrust rod bolts 8
34 WG9725520367 Anti-loosening sleeve 8
35 ZQ32318T13F6 Hexagonal flange nuts M18*1.5 8
36 WG9725520231 Double head studs 8
37 Q40312F31 Spring washers 16
38 ZQ1811675TF6 Hexagonal flange face bolts with teeth M16*1.5 2
39 WG9925521014 Hexagon socket countersunk head screws 8
WG9725520489 Rear leaf spring assembly
Serial No. Drawing No.  Name Quantity
1 WG9725520489/1 Rear plate spring assembly (Jinan Shuaichao) 1
2 WG9725520489/2 Rear plate spring assembly (Jinan Fangda Heavy Spring) 1
3 WG9725520489/3 Rear leaf spring assembly (Shandong Spring Zibo) 1
4 WG9725520489/4 Rear leaf spring assembly (Shandong Haihua) 1
WG9725520489/1 Rear Plate Spring Assembly (Jinan Shuaichao)
Serial No. Drawing No.  Name Quantity
1 WG9725520489+001/1 Rear steel plate spring assembly (12 pieces, thickness 25mm, Jinan Shuaichao) first piece 1
2 WG9725520489+002/1 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) second piece 1
3 WG9725520489+003/1 Rear leaf spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) third piece 1
4 WG9725520489+004/1 Rear leaf spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) fourth piece 1
5 WG9725520489+005/1 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao), fifth piece 1
6 WG9725520489+006/1 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao), sixth piece 1
7 WG9725520489+007/1 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao), seventh piece 1
8 WG9725520489+008/1 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) eighth piece 1
9 WG9725520489+009/1 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao), ninth piece 1
10 WG9725520489+010/1 Rear leaf spring assembly (12 pieces, 25mm thick, Jinan Shuaichao), tenth piece 1
11 WG9725520489+011/1 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) 11th piece 1
12 WG9725520489+012/1 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Shuaichao) twelfth piece) 1
13 WG9725520489+013/1 Center bolt (12 pieces, 25mm thick, Jinan Shuaichao) 1
14 WG9725520489+014/1 Center nut (12 pieces, 25mm thick, Jinan Shuaichao) 1
WG9725520489/2 Rear Plate Spring Assembly (Jinan Fangda Heavy Duty)
Serial No. Drawing No.  Name Quantity
1 WG9725520489+001/2 Rear steel plate spring assembly (12 pieces, thickness 25mm, Jinan Fangda rebound) first piece 1
2 WG9725520489+002/2 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) second piece 1
3 WG9725520489+003/2 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) third piece 1
4 WG9725520489+004/2 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) fourth piece 1
5 WG9725520489+005/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) fifth piece 1
6 WG9725520489+006/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) sixth piece 1
7 WG9725520489+007/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda), seventh piece 1
8 WG9725520489+008/2 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) eighth piece 1
9 WG9725520489+009/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) ninth piece 1
10 WG9725520489+010/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) 10 pieces 1
11 WG9725520489+011/2 Rear steel plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) 11th piece 1
12 WG9725520489+012/2 Rear plate spring assembly (12 pieces, 25mm thick, Jinan Fangda) twelfth piece 1
13 WG9725520489+013/2 Center bolt (12 pieces, 25mm thick, Jinan Fangda) 1
14 WG9725520489+014/2 Center nut (12 pieces, 25mm thick, Jinan Fangda) 1
WG9725520489/3 Rear plate spring assembly (Shandong Spring Zibo)
Serial No. Drawing No.  Name Quantity
1 WG9725520489+001/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 1st piece 1
2 WG9725520489+002/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 2nd piece 1
3 WG9725520489+003/3 Rear leaf spring assembly (thickness 23mm, Zibo, Shandong) 3rd piece 1
4 WG9725520489+004/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 4th piece 1
5 WG9725520489+005/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 5th piece 1
6 WG9725520489+006/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 6th piece 1
7 WG9725520489+007/3 Rear leaf spring assembly (thickness 23mm, Zibo, Shandong) 7th piece 1
8 WG9725520489+008/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 8th piece 1
9 WG9725520489+009/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 9th piece 1
10 WG9725520489+010/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 10th piece 1
11 WG9725520489+011/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 11th piece 1
12 WG9725520489+012/3 Rear leaf spring assembly (thickness 23mm, Shandong Spring Zibo) 12th piece 1
13 WG9725520489+013/3 Center bolt (Shandong Spring Zibo) 1
14 WG9725520489+014/3 Center nut (Shandong Spring Zibo) 1
WG9725520489/4 Rear Plate Spring Assembly (Shandong Haihua)
Serial No. Drawing No.  Name Quantity
1 WG9725520489+001/4 Rear plate spring assembly (thickness 23mm, Shandong Haihua) 1st piece 1
2 WG9725520489+002/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 2nd piece 1
3 WG9725520489+003/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 3rd piece 1
4 WG9725520489+004/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 4th piece 1
5 WG9725520489+005/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 5th piece 1
6 WG9725520489+006/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 6th piece 1
7 WG9725520489+007/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 7th piece 1
8 WG9725520489+008/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 8th piece 1
9 WG9725520489+009/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 9th piece 1
10 WG9725520489+010/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 10th piece 1
11 WG9725520489+011/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 11th piece 1
12 WG9725520489+012/4 Rear leaf spring assembly (thickness 23mm, Shandong Haihua) 12th piece 1
13 WG9725520489+013/4 Center bolt (Shandong Haihua) 1
14 WG9725520489+014/4 Center Nut(Shandong Haihua) 1
AZ9925520310 Balance shaft with housing assembly
Serial No. Drawing No.  Name Quantity
1 190003962021 Tapered thread hexagonal plugs 1
2 AZ9725520237 Balance Shaft 1
3 AZ9925520233 Bracket 1
4 Q150B0820T1F9 Hexagon head bolts 8
5 Q151B1655TF2 Hexagon head bolts (fine thread) 6
6 Q40308 Spring washers 8
7 Q40516 Heavy Duty Spring Washers 6
8 Q5211630 Cylindrical pins 1
9 Q72308T5F Sealing washers 1
10 WG614 130062 Seal Ring 1
11 WG9014520192 Locating Washers 1
12 WG9014520193 Locating Washers 1
13 WG9014520194 Locating washers 1
14 WG9014520303 Positioning washers 1
15 WG9014520306 Positioning washers 1
16 WG9014520312 Shell cover 1
17 WG9100520008 Locating washers 1
18 WG9114520042 Spherical bearings 2
19 WG9114520059 Locating washers 1
20 WG9114520223 Shaft seals 2
21 WG9725520136 Bearing oil seal cover 1
22 WG9725520238 Spacer Bushings 1
23 WG9725520239 Bearing presses 1
24 WG9925520062 Sealing rings 1
25 WG9925520235 Balance shaft housing 1
26 ZQ150B0812 Hexagon head bolts M8 1
