Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)
Sitrak Version 20 Standard Weight Mixing Disconnecting Balance Suspension (14 Square/38t/12×23×1350/Frame 850_8+5_casting Cross Member/Mat16bg/Four Riders/Plate Spring Distance 1030)
2025-05-11
Sitrak Weichai Euro 5 Wp10 ECU Transition Line (Tx/G7w)
Sitrak Weichai Euro 5 Wp10 ECU Transition Line (Tx/G7w)
2025-05-11

Sitrak Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)

Sitrak Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)
Sitrak Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)
Download Catalog
Get Quotation

What is the Sitrak Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)

  • Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar): Unrivaled Stability for Heavy-Duty Operations​
  • Engineered to enhance the handling and stability of dump trucks, the Rear Lateral Stabilizer For Dump Trucks, Version 20, is a high-performance solution tailored for vehicles with an 850mm rear-wide frame. Featuring a solid bar construction, this stabilizer significantly reduces body roll during turns and mitigates the impact of uneven terrain, ensuring safer and more efficient operation, even under heavy loads.​
  • Core Assembly and Structural Components​
  • The Rear Stabilizer Bar Assembly lies at the heart of this system. Crafted from high-strength alloy steel, the solid bar is designed to withstand the extreme forces generated by heavy-duty applications. Its robust build resists deformation, providing consistent performance over extended periods. The Balance Clamp Assembly plays a crucial role in evenly distributing the load across the stabilizer bar, ensuring optimal functionality and preventing premature wear.​
  • Mounting and Connecting Elements​
  • Secure mounting is achieved through a combination of precision-engineered components. The Bearing Clamp and Rubber Bearing work in tandem to attach the stabilizer bar to the truck’s frame. The rubber bearing acts as a shock absorber, reducing vibrations and noise, while the bearing clamp ensures a tight, secure fit. Hexagon head bolts M12*1.25 and Type 2 hexagonal nut M12*1.25 are used to fasten these components, providing a reliable connection that can withstand the rigors of heavy-duty driving.​
  • The Stabilizer bar bracket (standard hole) serves as a key mounting point, providing a stable foundation for the entire assembly. It is firmly secured using Hexagonal flange face bolts with teeth M14*1.5 and Hexagonal flange face nut with teeth M14*1.5, which offer superior grip and resistance to loosening, even under intense vibrations.​
  • Fasteners and Reinforcement​
  • A variety of high-quality fasteners are employed to ensure the stability and durability of the system. Hexagonal nut type 2 M16*1.5 and Type 2 hexagonal nut M16*1.5 are used at critical connection points, providing a high level of clamping force. Washers are strategically placed to distribute the load evenly and prevent damage to the connected surfaces. The Bearing and Sleeve components further enhance the assembly’s performance by reducing friction and allowing for smooth movement of the stabilizer bar.​
  • Design for Heavy-Duty Excellence​
  • The Rear Lateral Stabilizer is designed with heavy-duty dump truck operations in mind. Each component undergoes rigorous testing to ensure it meets the highest standards of quality and reliability. The solid bar construction, combined with precision-engineered fasteners and mounting elements, ensures that the stabilizer can handle the extreme conditions typical of dump truck applications. Its compatibility with the 850mm rear-wide frame makes it an ideal choice for a wide range of dump truck models, offering enhanced stability and safety.​
  • SEO-Optimized Features​
  • Keyword Integration: Prominently features the product name, version number, frame specification, and key component names to target exact-match searches in parts catalogs, technical resources, and industry platforms.​
  • Technical Depth: Details the function and benefits of each component, highlighting material quality, engineering design, and performance enhancements to attract automotive professionals and fleet managers.​
  • Benefit-Driven Messaging: Emphasizes stability, safety, and durability, addressing the key concerns of dump truck operators and owners seeking reliable solutions to improve vehicle handling and reduce maintenance costs.​
  • In summary, the Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar), is a top-of-the-line solution that offers unparalleled stability and performance. With its robust construction, advanced design, and high-quality components, it is the perfect choice for heavy-duty dump truck operators looking to enhance the safety and efficiency of their vehicles.

Product Parameters of Sitrak Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)

AC99316800205 Rear Lateral Stabilizer For Dump Trucks, Version 20 (Frame Rear Wide 850/Solid Bar)
Serial No. Drawing No.  Name Quantity
1 WG9719680006 Rear Stabilizer Bar Assembly 1
2 WG780  680032 Bearing Clamp 2
3 WG9100680067 Rubber Bearing 2
4 ZQ151B12100 Hexagon head bolts M12*1.25 4
5 WG9750680075 Balance Clamp Assembly 2
6 ZQ361B12 Type 2 hexagonal nut M12*1.25 4
7 WG9725681008 Stabilizer bar bracket (standard hole) 2
8 ZQ32514T13F6 Hexagonal flange face nut with teeth M14*1.5 6
9 ZQ1811465TF6 Hexagonal flange bolts with teeth M14*1.5 2
11 ZQ361B16 Hexagonal nut type 2 M16*1.5 2
11 ZQ361B16 Type 2 hexagonal nut M16*1.5 2
12 WG9725680030 Washers 2
12 WG9725680030 Washers 2
13 WG9100680071 Washers 4
14 199100680066 Bearing 4
15 199100680037 Sleeve 2
16 190003930010 Washers 2
17 WG80  680029 Bolt 2
17 WG80  680029 Bolt 2
18 ZQ1811455TF6 Hexagonal flange face bolts with teeth M14*1.5 4
