Dongfeng Front Wheel Drive Axle ( Middle )

Dongfeng Front Wheel Drive Axle ( Middle )
Dongfeng Front Wheel Drive Axle ( Middle )
Download Catalog
Get Quotation

What is the Dongfeng Front Wheel Drive Axle ( Middle )

  • Dongfeng Front Wheel Drive Axle (Middle): Robust Power Transfer Core for Demanding 4WD Tractors
    Engineered as the critical pivot point in heavy-duty drivetrains, this center axle assembly delivers reliable torque transfer and precise steering articulation. Its heavy-duty construction withstands extreme loads while maintaining optimal gear alignment for peak agricultural and industrial performance.
  • Precision Geartrain & Differential System
  • High-Strength Gear Housing: The Main Drive Case houses the Bevel Drive Pinion Assembly and Differential Assembly, engineered for efficient power splitting.
  • Calibrated Gear Alignment: Utilizes Shims for Main Drive Case and Shims for Bearing Seat for micron-level gear tooth contact optimization.
  • Dual Differential Configuration: Features a robust Differential Assembly design for balanced torque distribution to both wheels.
  • Heavy-Duty Axle Housings & Support
  • Structural Pedestal System:
  • Front Pedestal & Rear Pedestal provide rigid mounting points, fitted with wear-resistant Front Pedestal Bush and Rear Pedestal Bush.
  • Shims for Front Swing Axle enable precise swing angle calibration.
  • Sealed Axle Terminations:
  • Left Half Shaft Housing and Right Half Shaft Housing incorporate large O-Ring Seals (160×3.55) for contaminant exclusion.
  • End Covers (Front/Rear Pedestal) with End Cover Gaskets and Gasket for End Cover ensure complete enclosure integrity.
  • Critical Sealing & Lubrication Management
  • Multi-Point Sealing: Utilizes specialized O-Ring Seals (65×2.65, 69×3.55, 69×2.65, 48.7×3.55) at all interfaces and Gasket for Upright Shaft Housing to prevent oil leaks.
  • Optimized Lubrication: Features Grease Cup M10×1 for manual bearing servicing and Oil Dipstick for level checks. Oil Drain Plug with Combined Seal Washer enables efficient fluid changes.
  • Pressure Equalization: Vent Plug and Vent Pipe prevent seal damage from thermal pressure buildup.
  • Secure Assembly & Steering Integration
  • Vibration-Resistant Fastening:
  • Critical Hex. Head Bolts (M16×65, M12×1.5×35, M10×35, M8×25, M6×12) with matching Spring Lock Washers (16, 12, 10, 8, 6) and Hex. Nut M16 maintain structural integrity under shock loads.
  • Straight Pins (A10×20, A10×16) provide positive alignment for key components.
  • Steering Compatibility: Power Steering Cylinder Bracket enables direct hydraulic cylinder mounting for responsive directional control.
  • Swing Axle Pivot: The Front Swing Axle facilitates steering articulation while Casing Cap protects internal components.
  • Engineered for Uncompromising Durability
    The Dongfeng Front Wheel Drive Axle (Middle) integrates over 30 precision components – from the Differential Assembly core to the smallest Spring Lock Washer 6 – into a unified power transfer solution. The synergy between its hardened geartrain, shim-adjusted alignment, triple-sealed housings (Main Drive Case, Half Shaft Housings), and industrial-grade fasteners delivers unmatched reliability in muddy fields, construction sites, and steep terrain. Exceeding OEM specifications, it maximizes uptime by preventing lubrication failure, gear misalignment, and structural fatigue.

Parameters of Dongfeng Front Wheel Drive Axle ( Middle )

No. Part No. Name Quantity
1 GB5783-86 Hex. head bolt M6×12 4
2 GB93-87 Spring lock washer 6 4
3 GB1152-89 Grease cup M10×1 2
4 304.31.019 End cover of front pedestal 1
5 304.31.122 End cover gasket 1
6 GB6170-86  Hex. nut M16 4
7 GB93-87  Spring lock washer 16 4
8 304.31.220-2 Front pedestal 1
9 GB27-88 Hex. head bolt M16×65 4
10 304.31.219-1 Front pedestal bush 1
11 304.31.123-1 Shims for front swing axle one set
12 GB3452.1-82 O-ring seal 65×2.65 1
13 ZB T32003-88  Casing cap 1
14 GB5786-86 Hex. head bolt M12×1.5×35 8
15 GB93-87 Spring lock washer 12 24
16 304.31.124-2 Front swing axle 1
17 GB3452.1-82  O-ring seal 69×3.55 1
18 304.31.116-2 Main drive case 1
19 200.38.024 Oil drain plug 1
20 12.37.149 Combined seal washer 3
21 304.31.125-1 Shims for bearing seat one set
22 304.31.022-1 Bevel drive pinion assembly 1
23 304.31.222-2 Rear pedestal 1
24 304.31.221-1 Rear pedestal  bush 1
25 GB3452.1-82 O-ring seal 69×2.65 1
26 304.31.126 Gasket for end cover 1
27 304.31.127-1 End cover of rear pedestal 1
28 GB3452.1-82  O-ring seal 48.7×3.55 1
29 GB93-87 Spring lock washer 8 4
30 GB5783-86 Hex. Head bolt M8×25 4
31 304.31.128-1 Gasket for Upright shaft housing 2
32 GB5783-86  Hex. head bolt M10×35 20
33 GB93-87 Spring lock washer 10 20
34 304.31.013-1 Oil dipstick 1
35 304.31.233-1 Left half shaft housing 1
36 GB3452.1-82 O-ring seal 160×3.55 2
37 GB5783-86 Hex. head bolt M12×35 16
38 GB119-86 Straight pin A10×20 2
39 304.31.234 Power steering cylinder bracket 1
40 304.31.117-1 Shims for main drive case two set
41 304.31.014-1 Differential assembly 1
304.31.014A Differential assembly 1
42 GB119-86 Straight pin A10×16 2
43 304.31.115-1 Right half shaft housing 1
44 304.31.118-1 Vent plug 1
45 304.31.119-1 Vent pipe 1
