Dongfeng Front Wheel Drive Axle ( Right side-Slowdown )

Dongfeng Front Wheel Drive Axle ( Right side-Slowdown )
Dongfeng Front Wheel Drive Axle ( Right side-Slowdown )
Download Catalog
Get Quotation

What is the Dongfeng Front Wheel Drive Axle ( Right side-Slowdown )

  • Dongfeng Front Wheel Drive Axle (Right Side-Slowdown): Precision Torque Control for Balanced 4WD Performance
    Engineered as the mirrored counterpart to the left-side system, this right-side axle integrates a geared slowdown mechanism for symmetrical traction management. It delivers optimized power distribution during high-load operations while maintaining steering integrity across challenging terrain like slopes, plowed fields, and construction sites.
  • Final Drive Reduction & Power Transfer
  • Geared Speed Reduction: Features the Driving Bevel Gear of Final Drive meshing with the Driven Bevel Gear of Final Drive within the Right Final Drive Housing for controlled torque multiplication.
  • Precision Gear Alignment: Adjusting Shims for Final Drive enable micron-level backlash control and contact pattern optimization.
  • Bearing Load Management: Combines Ball Bearing 207, Ball Bearing 209, and Thrust Ball Bearing 8106 to handle radial forces and axial thrust during aggressive deceleration.
  • Primary Gear Stage & Upright Shaft Assembly
  • First Reduction Phase: The Driving Bevel Gear of the First Drive transfers power through the Upright Shaft to the Driven Bevel Gear of the First Drive.
  • Bearing Preload Calibration: Utilizes Adjusting Shims for the First Drive with Ball Bearings 305, 111, and 208 for vibration-free rotation under maximum load.
  • Axial Security: Blocking Ring of Upright Shaft and Lock Washer prevent shaft migration, while Straight Pin A10×20 maintains gear alignment.
  • Drive Shaft System & Sealing
  • Torque Transmission Core: The Drive Shaft connects via Drive Shaft Sleeve, secured by Fixing Ring of Drive Shaft and supported by Final Drive Housing Bushing.
  • Dual Lip Protection: Oil-Seal W50×72×7 and Oil-Seal PD50×72×12 create redundant barriers against lubricant leakage and contaminant ingress.
  • Shielded Access: Drive Shaft Cover with Gasket safeguards internal components from debris impact.
  • Steering Linkage Integration
  • Right-Side Control Points:
  • Right Linking Arm provides steering input through Steering Arm Bushing.
  • Right Steering Trapezoid Arm transmits directional control forces.
  • Secure Mounting: Fastened with Hex. Head Bolts (M12×35, M10×25) and Spring Lock Washers 12.
  • Sealed Lubrication & Service Design
  • Multi-Point Sealing: Utilizes O-Rings (56×2.65, 34.5×2.65, 85×2.65) at critical interfaces with Felt Washer supplementary protection.
  • Maintenance Access: Features Grease Cup M10×1 for manual lubrication and Oil Drain Plug with Combined Seal Washer for efficient fluid service.
  • Bearing Protection: Upper Bearing Cover and Lower Bearing Cover enclose precision components.
  • Robust Fastening & Structure
  • Vibration-Proof Hardware: Critical connections use Hex. Head Bolts (M18×1.5×35, M10×30) with Spring Lock Washers (18, 10) and Hex. Nut M18×1.5.
  • Reinforced Joints: Double Screw Bolt enhances high-stress point integrity.
  • Precision Spacing: Spacer elements maintain optimal gear clearances.
  • Engineered for Symmetrical Durability
    As the power-balanced counterpart to the left-side system, this axle integrates 38 specialized components – from the torque-output Half Shaft to the alignment-critical Straight Pin A10×28. The synergy between its dual-gear reduction stages (First Drive & Final Drive Bevel Gears), triple-bearing supported Upright Shaft, and sealed Right Final Drive Housing ensures matched torque management during heavy draft work. Exceeding OEM specifications, it delivers three critical advantages for right-wheel dynamics:
  • Balanced Traction Control: Synchronized slowdown with left axle
  • Reduced Torque Steer: Neutral handling during asymmetric loads
  • Extended Component Life: Optimized gear mesh prevents premature wear

Parameters of Dongfeng Front Wheel Drive Axle ( Right side-Slowdown )

No. Part No. Name Quantity
1 GB6176-86 Hex. nut  M18×1.5 2
2 GB93-87 Spring lock washer 18 6
3 304.31.179 Double screw bolt 2
4 GB5786-86 hex. head bolt M18×1.5×35 4
5 304.31.101-2 Drive shaft 1
6 HG4-692-67 Oil-seal W50×72×7 2
7 HG4-692-67 Oil-seal PD50×72×12 2
8 GB5783-86  Hex. head bolt M10×30 20
9 GB93-87 Spring lock washer 10 26
10 304.31.104-3 Drive shaft cover 1
11 GB276-89 Ball bearing 209 1
12 304.31.102-2 Fixing ring of drive shaft 2
13 304.31.103-2 Drive shaft sleeve 1
14 304.31.132-2 Driven bevel gear of final drive 1
15 GB276-89  Ball bearing 207 1
16 304.31.105-1 Gasket for drive shaft cover 1
17 304.31.216-4 Right final drive housing 1
18 GB119-86 Straight pin A10×28 2
19 304.30.130 Felt washer 1
20 304.31.217-1 Final drive housing bushing 1
21 GB301-84  Thrust ball bearing 8106 1
22 304.31.131-2 Driving bevel gear of final drive 1
23 304.31.140 Spacer 1
24 304.31.107-3 Upright shaft 1
25 GB276-89 Ball bearing 305 1
26 304.31.139 Adjusting shims for final drive one set
27 GB3452.1-82 O-ring seal 56×2.65 1
28 304.31.137-2 Lower bearing cover 1
29 12.37.149 Combined seal washer 1
30 200.38.024 Oil drain plug 1
31 GB1152-89 Grease cup M10×1 1
32 304.31.215-3 Right linking arm 1
33 304.31.202-1 Steering arm bushing 1
34 GB5783-86 Hex. head bolt M12×35 4
35 GB93-87  Spring lock washer 12 4
36 GB5783-86 Hex. head bolt M10×25 7
37 GB3452.1-82 O-ring seal 34.5×2.65 1
38 304.31.111-3 Upper bearing cover 1
39 GB3452.1-82 O-ring seal 85×2.65 1
40 304.31.133 Adjusting shims for the first drive one set
41 GB276-89  Ball bearing 111 1
42 304.31.138 Lock washer 1
43 304.31.110-1 Blocking ring of upright shaft 1
44 304.31.112-2 Adjusting shims one set
45 304.31.113-1 Driven bevel gear of the first drive 1
46 304.31.108-3 Upright shaft housing 1
47 304.31.129-1 Driving bevel gear of the first driv 1
48 GB276-89 Ball bearing 208 1
49 304.31.114-2 Half shaft 1
50 304.31.121-2 Right steering trapezoid arm 1
51 GB119-86 Straight pin A10×20 2
