Sitrak Wing (F) (Metal Bumper)

Sitrak Wing (F) (Metal Bumper)
Sitrak Wing (F) (Metal Bumper)
Download Catalog
Get Quotation

What is the Sitrak Wing (F) (Metal Bumper)

  • The Sitrak Wing (F) (Metal Bumper) is a robust, high-performance automotive component engineered to deliver superior front-end protection while enhancing the vehicle’s structural integrity. Designed with precision and durability in mind, this metal bumper incorporates a range of carefully selected components that ensure reliable performance and easy installation.​
  • Front Structure and Bracket Assembly​
  • At the core of its design, the bumper features the Front section of the left wing panel, a critical structural element that forms the foundational framework for the front-end protection system. Paired with the Left wing front section bracket assembly, this component provides stable support, ensuring optimal alignment and load distribution. The Right wing front section and its corresponding Right wing front section bracket assembly mirror this design, creating a balanced and symmetrical structure that enhances both aesthetics and functionality.​
  • Fasteners and Hardware​
  • A variety of high-quality fasteners secure the bumper’s components, ensuring long-lasting stability. Hexagon socket cheese head screws + large washers (Q2100825F31+Q40208F31) are used throughout the assembly to connect critical panels and brackets, offering strong resistance to vibration and impact. These are complemented by Hexagon bolts, Flat washers, and Ⅰ type hexagonal nuts, which work together to fasten structural elements with precision. Spring washers add an extra layer of security, preventing loosening due to mechanical stress, while Cross recessed pan head screw and flat washer assemblies ensure secure attachment for smaller components, such as the Left wing panel extension plate and Right wing panel extension.​
  • Protection and Skid Plates​
  • The bumper includes Wing Skid Plate I and Wing Skid Plate II, designed to shield the vehicle’s undercarriage and front components from debris, impacts, and road hazards. These skid plates are strategically positioned to absorb shocks and distribute force, extending the lifespan of vulnerable parts. Secured with Hexagon head bolts and Flat washers, they offer easy access for maintenance while maintaining rugged durability.​
  • Extension Panels and Accessories​
  • For enhanced coverage and customization, the Left wing panel extension plate and Right wing panel extension provide additional surface area and structural support, ideal for adapting to different vehicle configurations. These extensions are fastened using Cross recessed pan head tapping screws and Reed Nuts, ensuring a snug fit without compromising on strength. Plug covers are integrated to protect exposed ports and connectors, adding a layer of weather resistance and aesthetic refinement.​
  • Installation and Connectivity​
  • The bumper’s design prioritizes ease of installation with components like the Elastic retaining ring for splash guard connection/81908200340, which securely attaches splash guards to prevent mud and water ingress. Open end rivets and Bolt fixtures ensure permanent and reliable connections for non-removable parts, while Spacers maintain precise spacing between panels to avoid friction and ensure smooth operation. Large washers and Flat Washers are used strategically to distribute load pressure, enhancing the longevity of both fasteners and connected components.​
  • Engineered for performance and built to last, the Sitrak Wing (F) (Metal Bumper) combines rugged construction with meticulous design, making it an ideal choice for vehicles that require reliable front-end protection in demanding environments. Each component is precision-crafted to meet OEM standards, ensuring compatibility, durability, and ease of maintenance—key factors that make this bumper a trusted solution for commercial and industrial applications.

Product Parameters of Sitrak Wing (F) (Metal Bumper)

810-#0470-1217  Wing (F) (Metal Bumper)
Serial No.  Drawing No. Name Quantity
1 810W61510-0769 Front section of left wing panel 1
2 AZ9003921001 Hexagon socket cheese head screws + large washers(Q2100825F31+Q40208F31) 5
2 AZ9003921001 Hexagon socket cheese head screws + large washers(Q2100825F31+Q40208F31) 2
2 AZ9003921001 Hexagon socket cheese head screws + large washers(Q2100825F31+Q40208F31) 5
2 AZ9003921001 Hexagon socket cheese head screws + large washers(Q2100825F31+Q40208F31) 2
3 810W61540-5031 Left wing front section bracket assembly 1
4 Q151C1225 Hexagon bolts 2
4 Q151C1225 Hexagon bolts 1
4 Q151C1225 Hexagon bolts 1
5 Q40112 Flat washers 2
5 Q40112 Flat Washer 2
6 810W61511-0001 Wing Skid Plate I 1
6 810W61511-0001 Wing Skid Plate I 1
7 810W61510-0490 Wing Skid Plate II 1
7 810W61510-0490 Wing Skid Plate II 1
8 Q150B0822 Hexagon head bolts 8
8 Q150B0822 Hexagon head bolts 8
9 Q40108F31 Flat Washers 7
9 Q40108F31 Flat washers 7
10 Q340B08F31 Ⅰ type hexagonal nuts 8
10 Q340B08F31 Ⅰ type hexagonal nuts 8
11 Q40308F31 Spring washers 8
11 Q40308F31 Spring washers 8
12 810W61210-0617 Left wing panel extension plate 1
13 Q2300516F31 Cross recessed pan head screw and flat washer assemblies 2
13 Q2300516F31 Cross recessed pan head screw and flat washer assemblies 2
15 810W61243-0118 Bracket 1
16 Q40106F31 Flat washers 2
17 Q340B06F31 Hexagon nuts 2
18 810W61510-0469 Plug cover 1
18 810W61510-0469 Plug cover 1
19 810W61200-7439 Left fender assembly 1
20 Q40212 Large washer 1
20 Q40212 Large washer 1
21 Q2140620 Cross recessed pan head screws 2
21 Q2140620 Cross recessed pan head screws 2
22 Q40106 Flat Washers 2
22 Q40106 Flat washers 5
22 Q40106 Flat washers 2
22 Q40106 Flat Washers 5
23 Q39748202F31 Reed Nuts 5
23 Q39748202F31 Reed nuts 5
24 Q2714822F31 Cross recessed pan head tapping screws 5
24 Q2714822F31 Cross recessed pan head tapping screws 5
27 810W61210-0616 Right wing panel extension 1
28 810W61510-0770 Right wing front section 1
29 810W61540-5032 Right wing front section bracket assembly 1
30 MQ6W90712-0422 Spacer 1
30 MQ6W90712-0422 Spacer 1
31 AZ9003921404 Cross recessed pan head screws, large washers(Q2140616F31\Q40206F31) 5
31 AZ9003921404 Cross recessed pan head screw, large washer (Q2140616F31\Q40206F31) 5
32 AZ1608230117 Elastic retaining ring for splash guard connection/81908200340 3
32 AZ1608230117 Elastic retaining ring for splash guard connection/81908200340 3
33 Q150B1225 Bolt 2
34 810W61230-0214 Right fender 1
35 810W61230-0117 Plug cover 1
36 810W92201-0115 Open end rivet 5
