What is the Sitrak Metal Bumpers (N/F/Fwd Headlamp Guards)

  • The Sitrak Metal Bumpers (N/F/Fwd Headlamp Guards) are rugged, purpose-built automotive components designed to deliver superior front-end protection, structural reinforcement, and enhanced aesthetics for commercial vehicles. Engineered with precision and durability in mind, these bumpers integrate a comprehensive suite of high-quality components to withstand harsh conditions while ensuring easy installation and maintenance.​
  • Core Structural Components​
  • At the heart of the design lies the Bumper Center Section Assembly, the backbone of the bumper system that provides centralized strength and impact resistance. Flanking this core are the Bumper Left Segment Assembly and symmetrical Bumper Right Section Assembly, designed to create a balanced, robust framework. The Traction pin assembly and Spring Tab enhance towing capability and structural flexibility, while Reinforced fixing clips secure critical connections, minimizing vibration and ensuring long-term stability.​
  • Protective Skid Plates and Trim​
  • The bumpers feature Bumper Plastic Skid Plate I and II, strategically positioned to shield the vehicle’s undercarriage from debris, rocks, and road hazards. These skid plates combine lightweight durability with impact absorption, extending the lifespan of vulnerable components. For aesthetic and functional enhancement, the New Narrow Body Trim Plate, Left trim plate, Right Trim Plate, and Upper right bumper trim plate assembly offer a sleek, customized look while reinforcing edge protection. The Upper Left Bumper Plate Assembly adds additional coverage for high-impact zones, ensuring all-round defense.​
  • Fasteners and Hardware​
  • A robust array of fasteners ensures secure assembly and long-lasting performance. Dodecagonal bolts and Hexagon nuts type 1 provide heavy-duty clamping force for major structural connections, while Cross recessed pan head tapping screws and flat washers assemblies offer precision fastening for trim plates and accessory components. Spring Washers and Circlip Nuts prevent loosening due to mechanical stress, ideal for vibrational environments, while Shaft Retaining Rings and Pin fixtures secure movable or load-bearing parts, such as the traction system. Small washers and Hexagon nuts are used for detailed adjustments, ensuring every component fits snugly without friction.​
  • Headlamp Protection and Connectivity​
  • The Headlamp protectors are a key feature, shielding vital lighting components from impacts, debris, and weather damage while maintaining optimal light dispersion. These guards are integrated seamlessly with the bumper structure, fastened using Cross recessed countersunk head screws and Reed nuts for a flush, secure fit. Black hose clamps manage wiring and fluid lines along the bumper, enhancing cable organization and preventing wear, while Washers distribute load pressure across fastener points to avoid surface damage.​
  • Symmetrical Design and Installation Ease​
  • Designed for versatility, the Bumper Right Section Assembly (symmetrical to left piece) ensures balanced protection and simplified inventory management, as components are interchangeable for left and right sides. This symmetry, combined with intuitive mounting points and clear installation guidelines, reduces downtime during assembly or replacement. Every component—from the Bracket supports to the Circlip nuts—is precision-engineered to meet OEM standards, ensuring compatibility with Sitrak N/F models and other commercial vehicles.​
  • Built to excel in rugged environments, the Sitrak Metal Bumpers (N/F/Fwd Headlamp Guards) blend industrial-grade strength with thoughtful design, offering unparalleled protection for both the vehicle and its occupants. Whether navigating rough terrain or urban job sites, these bumpers deliver reliability, durability, and ease of maintenance—making them the ideal choice for fleets and operators who demand excellence from their equipment.

Product Parameters of Sitrak Metal Bumpers (N/F/Fwd Headlamp Guards)

812-#04A0-0142  Metal Bumpers (N/F/Fwd Headlamp Guards)
Serial No.  Drawing No. Name Quantity
1 810W41610-5663 Bumper Center Section Assembly 1
2 810W41614-2177 Bumper Plastic Skid Plate I 1
3 810W41614-2178 Bumper Plastic Skid Plate II 1
4 810W41610-6525 Bumper Left Segment Assembly 1
5 810W41610-0259 Pin 1
5 810W41610-0259 Pin 1
6 810W41610-0341 Bracket 1
6 810W41610-0341 Bracket 1
7 Q43122F3 Shaft Retaining Ring 1
7 Q43122F3 Shaft retaining ring 1
8 Q40012T16F9 Small washers 3
8 Q40012T16F9 Small washers 3
9 Q341C12 Hexagon nuts 3
9 Q341C12 Hexagon nuts 3
9 Q341C12 Hexagonal nut 10
10 810W41610-5529 Upper Left Bumper Plate Assembly 1
11 Q40312 Spring Washers 1
11 Q40312 Spring Washers 1
12 WG1632110004 Circlip Nut 4
12 WG1632110004 Circlip Nut 4
13 MQ6W13189-0095 Circlip Nut 4
13 MQ6W13189-0095 Circlip nuts 4
14 Q2205519 Cross recessed pan head tapping screws and flat washers assemblies 5
14 Q2205519 Cross recessed pan head tapping screws and flat washers assemblies 2
15 810W90685-0432 Circlip nuts 4
15 810W90685-0432 Circlip nuts 4
16 Q2214819F31 Cross recessed pan head tapping screws and flat washers assemblies 4
16 Q2214819F31 Cross recessed pan head tapping screws and flat washers assemblies 4
17 Q39739162 Reed nuts 9
18 Q2714813F31 Cross recessed pan head tapping screws 9
19 AZ9003997001 Black hose clamps 4
20 Q2204822F31 Cross recessed pan head tapping screws and flat washers assemblies 8
21 712W41630-5047 Headlamp protectors 2
22 712W41685-0052 New Narrow Body Trim Plate 1
23 712W41685-0063 Reinforced fixing clips 3
24 810W41610-0387 Left trim plate 1
25 810W41610-0390 Right Trim Plate 1
26 810W41610-5530 Upper right bumper trim plate assembly 1
27 810W41610-6524 Bumper right section assembly (symmetrical to left piece) 1
28 810W91101-5183 Traction pin assembly 1
29 810W97640-0290 Spring Tab 1
30 MQ6W41610-0249 Washers 10
31 MQ6W90410-0014 Dodecagonal bolts 10
32 Q2560520 Cross recessed countersunk head screws 16
33 Q340B05 Hexagon nuts type 1 16
