What is the Sitrak C7 With Movable Pedal Narrow Body Cab Electric Lift (Raised Model)

  • The Sitrak C7 With Movable Pedal Narrow Body Cab Electric Lift (Raised Model) is a cutting-edge automotive solution designed to enhance the driving experience and vehicle performance. This model incorporates a range of high-quality components that work together seamlessly to ensure reliability, functionality, and ease of use.​
  • At the core of its lifting mechanism, the model features a Right-side quick-insert large electric oil pump, which provides the necessary power to drive the lifting system. Paired with the Narrow body quick insert cylinder, this pump enables efficient and smooth lifting operations. The Lifting cylinder left upper bracket assembly plays a crucial role in supporting the lifting cylinder, ensuring stability and durability during the lifting process.​
  • For control and operation, the Switch bracket assembly II and Hand-held cab rollover mobile switch assembly are key components. The Switch bracket assembly II provides a secure mounting point for the switches, while the hand-held mobile switch assembly allows for convenient and flexible control of the cab rollover function. The Upper bracket further supports the overall structure, enhancing the rigidity of the system.​
  • Fasteners are essential for maintaining the integrity of the vehicle, and this model includes a variety of high-quality ones. The Hexagon head flange bolts (MAN222-M12X1,5X25H-MK14X4-10.9-MAN183-B1) and Hexagon head flange face bolts (MAN222-M16X1,5X 85 B MK24-8.8-MAN183-B1) are designed to provide strong and secure connections. Gaskets and spacers are used to ensure proper sealing and spacing between components, while Self-locking nuts prevent loosening due to vibration. Additionally, Hexagon head flange face bolts M10 are used in various applications to secure different parts.​
  • The hydraulic system of the model is supported by a range of hoses and fittings. Double-bend quick-connect hose A(1250) and B (1250) allow for quick and easy connections, while Single side 180 degree bend high pressure hose (800), Single 180° bend high-pressure hose (900), and Double bend hose (3100) are designed to handle high-pressure fluid transmission. Tee Fitting is used to branch the fluid flow, and Plastic Fastening Tape A5*280 is used to secure the hoses in place. Double-bend vertical hose(300) and Double-bend vertical low-pressure hose(260) are suitable for vertical applications, and Hose Clamps ensure that the hoses are firmly attached.​
  • Other important components include the Motor assembly (mounting holes on the side), which provides the power for the lifting system, and the Switch catch bracket, which secures the switches in place. Cross recessed pan head screws are used for various fastening tasks, and the Wiring harness hook helps to organize and secure the wiring. The Cab flip operation instructions provide clear guidance for operating the cab flip function, and the Hook assembly is used for attaching and securing different parts of the vehicle.

Product Parameters of Sitrak C7 With Movable Pedal Narrow Body Cab Electric Lift (Raised Model)

811-#05F0-1242  C7 With Movable Pedal Narrow Body Cab Electric Lift (Raised Model)
Serial No.  Drawing No. Name Quantity
1 811W41723-6008 Right-side quick-insert large electric oil pump 1
2 811W41723-6021 Narrow body quick insert cylinder 1
3 850W41720-5031 Lifting cylinder left upper bracket assembly 1
4 WG9925820069 Switch bracket assembly II 1
5 WG9925820110 Hand-held cab rollover mobile switch assembly 1
6 850W41720-0056 Upper bracket 1
7 MQ6-02836-4558 Hexagon head flange bolts(MAN222-M12X1,5X25H-MK14X4-10.9-MAN183-B1) 6
8 MQ6-02856-2720 Hexagon head flange face bolts(MAN222-M16X1,5X 85 B MK24-8.8-MAN183-B1) 1
9 850W90710-0010 Gasket 1
10 850W90710-0011 Spacer 1
11 190003888626 Self-locking nuts 1
12 ZQ1841016TF6 Hexagon head flange face bolts M10 2
13 810W41701-0085 Bracket 1
14 811W41723-6030 Double-bend quick-connect hose A(1250) 1
15 811W41723-6031 Double-bend quick-connect hose B (1250) 1
16 WG9719820260 Single side 180 degree bend high pressure hose (800) 1
17 WG9719820278 Single 180° bend high-pressure hose (900) 1
18 811W41723-6032 Double bend hose (3100) 1
19 190003559482 Tee Fitting 1
20 WG9003171356 Plastic Fastening Tape A5*280 15
21 WG9719820261 Double-bend vertical hose(300) 1
22 WG9719820262 Double-bend vertical low-pressure hose(260) 1
23 WG9925820065 Hose Clamps 2
24 Q150B0840 Hexagon head bolts 1
25 Q33008 All-metal hexagonal flange face lock nut 1
26 WG9925821031 Motor assembly (mounting holes on the side) 1
27 ZQ1840820TF6 Hexagonal flange face bolts M8 2
28 WG9925820111 Switch catch bracket 1
29 Q2140616 Cross recessed pan head screws 2
30 WG9925820112 Wiring harness hook 1
31 810W97812-0071 Cab flip operation instructions 1
32 WG9925820113 Hook assembly 1
