Sitrak Rear Wing (C5h2376/850-865 Frame) (Certified)

Sitrak Rear Wing (C5h2376/850-865 Frame) (Certified)
Sitrak Rear Wing (C5h2376/850-865 Frame) (Certified)
Download Catalog
Get Quotation

What is the Sitrak Rear Wing (C5h2376/850-865 Frame) (Certified)

  • The Sitrak Rear Wing (C5h2376/850 – 865 Frame) (Certified) is a crucial component of the vehicle, engineered to offer both functionality and aesthetic appeal. This rear wing is crafted with high – quality materials and precision manufacturing, ensuring it meets the strictest industry standards.
  • Left Rear Wing Components
  • The left rear wing panel bracket assembly forms the foundation for the left side of the rear wing. It is securely fastened using hexagonal flange bolts with teeth M121.25 and hexagonal flange surface with teeth bolts M121.25. These specialized bolts provide a strong and stable connection, preventing any loosening due to vibrations or road shocks. The corresponding hexagonal flange nuts with teeth M12*1.25 are used to secure the bolts in place, creating a reliable joint.
  • The rear wing panels on both sides are an essential part of the overall design. They are attached using hexagonal flange bolts and hexagonal flange screws, along with large washers. These large washers distribute the load evenly, reducing the risk of damage to the panels. Type 1 all – metal hexagonal locknuts are also used to further enhance the stability of the connections, ensuring that the panels remain firmly in place over time.
  • Right Rear Wing Components
  • The right rear fender bracket assembly is designed to support the right side of the rear wing. Similar to the left side, it uses a combination of high – strength fasteners for a secure installation. The inner fender adds an extra layer of protection, shielding the vehicle’s components from debris and water.
  • Special nuts are employed in specific areas to ensure a custom – fit and reliable connection. The lower plug cover helps to keep out dirt and moisture, protecting the internal components of the rear wing. Small washers are used in conjunction with cross recessed pan head tapping screws. These screws are used to fasten smaller parts and details, providing a precise and secure fit.
  • In conclusion, the Sitrak Rear Wing (C5h2376/850 – 865 Frame) (Certified) is a well – designed and durable component. Its use of high – quality fasteners and carefully engineered assemblies ensures that it can withstand the rigors of daily use while maintaining its functionality and appearance. Whether for performance or aesthetic purposes, this certified rear wing is an excellent addition to any Sitrak vehicle.

Product Parameters of Sitrak Rear Wing (C5h2376/850-865 Frame) (Certified)

812-#0481-0162  Rear Wing (C5h2376/850-865 Frame) (Certified)
No. Part Number Part Name English  Quantity
1 812W61210-0635 Left rear wing panel bracket assembly 1
2 ZQ1811240TF6 Hexagonal flange bolts with teeth M12*1.25 4
2 ZQ1811240TF6 Hexagonal flange surface with teeth bolts M12*1.25 4
3 ZQ32512T13F6 Hexagonal flange nut with teeth M12*1.25 4
3 ZQ32512T13F6 Hexagonal flange nut with teeth M12*1.25 4
4 812W61210-0651 Rear wing panel 1
4 812W61210-0651 Rear wing panel 1
5 Q1840825F31 Hexagonal flange bolt 4
5 Q1840825F31 Hexagonal Flange Screw 4
6 Q40208F31 Large washer 4
6 Q40208F31 Large Washers 4
7 Q33408 Type 1 all-metal hexagonal locknut 4
7 Q33408 Type 1 all-metal hexagonal locknut 4
8 812W61210-0638 Right Rear Fender Bracket Assembly 1
9 812W61210-0663 Inner fender 2
10 810W90685-0448 Special Nut 12
11 AZ1664230205 Lower Plug Cover 2
12 Q40006 Small washers 12
13 Q2716332F31 Cross recessed pan head tapping screws 12
