Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)

Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)
Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)
Download Catalog
Get Quotation

What is the Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)

  • The Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor) is a high – performance system designed to provide optimal comfort in the vehicle’s cab. It combines advanced technology with a well – thought – out assembly of components, ensuring efficient operation and long – lasting durability.
  • Heating and Control Components
  • The Heater System Assembly (Narrow Body) from the Rubber & Plastic Division is a key part of the air – conditioning setup. It is fastened using cross recessed pan head screws along with large washers and spring washers to ensure a secure and stable installation. The control panel assembly allows the driver to adjust the temperature, fan speed, and other settings with ease. The cover plate and cover plate assembly protect the internal components from dust and damage. Cross recessed pan head tapping screws and flat washers assemblies are used to attach various parts of the control panel and cover plate.
  • Water and Circulation Components
  • The water valve assembly, along with its inlet pipe, regulates the flow of water in the system. Hose clamps are used to secure the pipes, preventing any leaks. The internal and external circulation damper steering guard helps in controlling the airflow direction. Plug covers are used to seal openings and prevent the entry of dirt and moisture.
  • Sensor and Pipe Components
  • The indoor temperature sensor assembly constantly monitors the temperature inside the cab, allowing the air conditioner to adjust its operation accordingly. The drip pipe and steam pipe cab section are essential for the proper functioning of the cooling system. Hexagon socket head cap screws and hexagon head bolts, combined with spring washers and flat washers assemblies, are used to fasten these pipes securely. The filter system assembly ensures that the air entering the cab is clean and free from contaminants.
  • Cooling and Refrigeration Components
  • The cold steam pipe assembly and pressure cooling tube assembly play a vital role in the refrigeration process. The condenser is responsible for dissipating heat, and pipe clamps are used to hold the pipes in place. The Water Valve Assembly Upper Shroud from the Rubber & Plastic Division provides additional protection to the water valve. Plastic fastening tape A5*280 and assembled clamp reinforcement (top, T30REC4A, t = 1 – 3) are used for further securing and reinforcing the components. The steel band type elastic hose clamping hoop ensures a tight seal for the refrigerant lines.
  • The refrigerant (R134a) is the working fluid that enables the cooling effect. Hexagon head bolts, spring washers and flat washers assemblies are used throughout the system to fasten various components, and hexagon nuts type 1 are used to secure the bolts. The air conditioner label provides important information about the system, such as its specifications and operating instructions.
  • In summary, the Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor) is a sophisticated and reliable system that offers a comfortable and controlled environment inside the vehicle’s cab. Its well – designed components and secure assembly make it a great choice for Sitrak vehicles.

Product Parameters of Sitrak Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)

711-#0531-0016  Narrow Body Cab Air Conditioner (C5h, D08, Left Side Of Compressor)
No. Part Number Part Name English  Quantity
1 711W61900-7290 Heater System Assembly (Narrow Body) (Rubber & Plastic Division) 1
2 Q2140825F31 Cross recessed pan head screws 2
3 Q40208F31 Large washers 2
4 Q40308F31 Spring washers 2
5 712W61942-0008 Control panel assembly 1
6 810-61942-0083 Cover plate 1
7 810-61942-6004 Cover plate assembly 1
8 Q2204825F31 Cross recessed pan head tapping screws and flat washers assemblies 2
9 190003989340 Hose clamps 2
10 712W61967-0030 Water valve assembly 1
11 812W61960-0007 Water valve inlet pipe 1
12 Q2300616F31 Cross recessed pan head screws and flat washers assemblies 3
13 Q340B06F31 Hexagon nuts 1
14 711W61900-7154 Filter system assembly 1
15 711-61942-0047 Plug cover 1
16 711-61942-0048 Internal and external circulation damper steering guard 1
17 Q1460835F31 Hexagon head bolts, spring washers and flat washers assemblies 4
18 WG1630820313 Indoor temperature sensor assembly 1
20 810W61940-0122 Drip pipe 1
21 712W61942-0014 Steam pipe cab section 1
22 Q218B0625 Hexagon socket head cap screws 1
23 Q1460850 Hexagon head bolts, spring washers and flat washers assemblies 1
24 Q340B08 Hexagon nuts type 1 1
26 712W61942-0016 Steam pipe frame section 1
27 Q2360620F31 Cross recessed pan head screws, spring washers and flat washers assemblies 1
28 Q2360620 Cross recessed pan head screws, spring washers and flat washers assemblies 1
29 712W61942-0018 Cold steam pipe assembly 1
30 Q1460835 Hexagon head bolts, spring washers and flat washers assemblies 1
30 Q1460835 Hexagon head bolts, spring washers and flat washers assemblies 1
31 712W61942-0012 Pressure cooling tube assembly 1
32 712W61942-0080 Condenser 1
33 YG1600822205 Pipe clamp 1
34 AZ1664840050 Water Valve Assembly Upper Shroud (Rubber & Plastic Division) 1
35 WG9003171356 Plastic fastening tape A5*280 2
36 711W97470-1001 Assembled clamp reinforcement (top, T30REC4A, t=1-3) 4
37 Q673C20 Steel band type elastic hose clamping hoop 1
38 AZ9007310012 Refrigerant (R134a) 60
39 Q1460820 Hexagon head bolts, spring washers and flat washers assemblies 1
39 Q1460820 Hexagon head bolts, spring washers and flat washers assemblies 1
40 712W61942-0076 Air conditioner label 1
711W61900-7290 Heater system assembly (narrow body) (Rubber & Plastic Division)
No. Part Number Part Name English  Quantity
1 711-61900-7292 Heater system assembly (narrow body, C5H) 1
711-61900-7292 Heater system assembly (narrow body, C5H)
No. Part Number Part Name English  Quantity
1 711W61942-0033 Radiator assembly 1
2 712-25458-6001 Air Conditioning Wiring Harness (Replacement of Evaporator Temperature Sensor) 1
3 811-61900-6396 Heater assembly 1
4 811W61942-0002 Blower assembly 1
5 812W61942-0002 Mode steering gear 1 1
6 812W61942-0003 Mode Steering Gear 2 1
7 812W61942-0004 Bypass vent door steering gear 1
8 812W61942-0009 Air conditioning electronic control system list (C7 narrow) 1
9 812W61942-0063/3 CAM disk 1
10 WG1664820025/1 Evaporator temperature sensor (waterproof) (Nanjing Aolian) 1
11 WG1664821018/1 Speed control module assembly (waterproof plug) (Nanjing Aolian) 1
712W61967-0030 Water valve assembly
No. Part Number Part Name English  Quantity
1 712W61967-0030/1 Water Valve Assembly (Interior Parts Factory) 1
712W61967-0030/1 Water Valve Assembly (Interior Parts Factory)
No. Part Number Part Name English  Quantity
1 712W61967-0032/1 Water Valve (Interior Parts Plant) 1
2 810W61967-0012/1 Water valve bracket (Rubber & Plastic Division) 1
3 AZ1664840024 Cover 1
4 Q2733913 Cross recessed large semi-circular head tapping screws 4
5 WG1642840017/1 Cross recessed pan head tapping screws (Interior Parts Factory) 3
6 WG1664820280/1 Water valve motor (Nanjing Aolian) 1
711W61900-7154 Filter System Assembly
No. Part Number Part Name English  Quantity
1 711-61900-7153 Filter System Assembly (Huizhongda Evaporator) 1
2 711-61900-7380 Filter System Assembly (Shanghai Yida Evaporator) 1
711-61900-7153 Filter system assembly (Huizhongda evaporator)
No. Part Number Part Name English  Quantity
1 711-61942-0045 Filter assembly 1
2 711W61900-0050 Air conditioner filter assembly 1
3 712W61942-0044/1 Evaporator assembly (Jinan Huizhongda) 1
4 812W61942-0041 Outdoor temperature sensor 1
5 812W61942-0043 Internal and External Circulation Damper Steering 1
711-61900-7380 Filter System Assembly (Shanghai Yida Evaporator)
No. Part Number Part Name English  Quantity
1 711-61942-0045 Filter assembly 1
2 711W61900-0050 Air Conditioner Filter Assembly 1
3 712W61942-0044/2 Evaporator assembly (Shanghai Yida) 1
4 812W61942-0041 Outdoor Temperature Sensor 1
5 812W61942-0043 Internal and External Circulation Damper Steering 1
712-#0570-0002 C7H Chinese language vehicle nameplate (tipper)
No. Part Number Part Name English  Quantity
1 AZ1632955012 Whole Vehicle Marking Plate (for Dump and Cargo Vehicles) 1
2 WG1632950061 Commercial Vehicle Company Shanteka Plate Tail Marker 1
3 WG9003900025 Nameplate Pin 2
4 AZ9100360358 Brake Placard-Commercial Vehicle 1
