What is the Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)

  • XCMG Aluminum Cylinder Unit (Pressure Retaining Cylinder 799 Mounted Longitudinal Beam)
  • The XCMG Aluminum Cylinder Unit, with its Pressure Retaining Cylinder 799 Mounted Longitudinal Beam, is a key component designed for optimal performance and reliability in various applications.
  • 1. Structural Components
    The unit features a Tank Holder Assembly (φ246) that provides a stable base for the Aluminum Tank Assembly Φ246/20L. This assembly is crucial for securely holding the cylinder in place. The use of high-quality materials ensures durability and resistance to various operating conditions.
  • 2. Sealing and Fastening Elements
    Elastic Element NG12, Circlip NG12, and Nut Holder NG12 work together to create a tight seal and secure connection. This not only prevents leaks but also ensures the integrity of the system under pressure. The Plug NG12-M22X1.5 further enhances the sealing, protecting the internal components from contaminants.
  • 3. Mounting and Tightening
    Hexagonal Flange Face Nut M10 and Hexagonal Flange Face Bolt M10 are used for mounting the cylinder unit. Their design provides a strong and reliable connection to the longitudinal beam. The Tank Tightening Strap Assembly (Φ246) with Tensioning Pins adds an extra level of security, ensuring that the cylinder remains firmly in place even during vibrations or sudden movements.
  • 4. Maintenance and Drainage
    The inclusion of a Water Drain Valve allows for easy maintenance. It enables the removal of any accumulated water or moisture, which is essential for maintaining the performance and longevity of the cylinder unit. The use of Hexagonal Socket Cheese Head Cap Screws ensures that all components are easily accessible for inspection and servicing.
  • In conclusion, the XCMG Aluminum Cylinder Unit is a well-engineered product that combines functionality, durability, and ease of maintenance. Its design and components make it suitable for a wide range of applications where reliable pressure retention and storage are required.

Product Parameters of Sitrak Aluminum Cylinder Unit (Pressure Retaining Cylinder 799 Mounted Longitudinal Beam)

712-#0334-3904 Aluminum Cylinder Unit (Pressure Retaining Cylinder 799 Mounted Longitudinal Beam)
Serial No. Drawing No.  Name Quantity
1 WG9100360111 Tank holder assembly (φ246) 1
2 WG9000360799 Aluminum tank assembly Φ246/20L 1
3 WG9000361007 Elastic element NG12 2
4 WG9000361008 Circlip NG12 2
5 WG9000361009 Nut holder NG12 2
6 WG9000361012 Plug NG12-M22X1.5 1
7 ZQ32010T13F6 Hexagonal flange face nut M10 4
8 ZQ1841035TF6 Hexagonal flange face bolt M10 4
9 WG9700360003 Tank tightening strap assembly (Φ246) 2
10 WG09  190017 Tensioning pin 2
11 WG700 550013 Tensioning pin 2
12 Q218B0880 Hexagonal socket cheese head cap screws 2
13 WG9000361402 Water drain valve 1
AC91003600001 GB7258 Brake Part Requirement Item (Brake Placard / Reservoir Test Connector)
Serial No. Drawing No.  Name Quantity
1 AZ9100360358 Brake Plates-Commercial Vehicles 1
2 WG9000361406 T-joint body NW9/NG12/TEST 4
2 WG9000361406 T-joint body NW9/NG12/TEST 2
3 WG9000361408 T-joint body NG12/TE 2
