Sitrak Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)

Sitrak Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)
Sitrak Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)
Download Catalog
Get Quotation

What is the Sitrak Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)

  • XCMG Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)
  • The XCMG Front License Plate Mounting Plate And Pedal is an essential part of the vehicle’s front-end assembly, designed to provide a secure and functional mounting solution for the license plate while also incorporating an anti-skid pedal for added safety.
  • 1. Structural Components
    The assembly includes a U-tube assembly that forms the main structure of the license plate mounting plate. This provides a stable base for attaching the license plate and other components. The clip is used to hold the U-tube assembly in place, ensuring a secure fit.
  • 2. Fastening Elements
    Flat washers, hexagon nuts type 1, and spring washers are used to fasten the various components together. These elements help to distribute the load evenly and prevent loosening due to vibrations. The cross recessed pan head tapping screw and flat washer assembly provide additional security for the license plate mounting plate.
  • 3. Anti-Skid Pedal
    The anti-skid pedal is a crucial feature of this assembly. It provides a safe and stable surface for the driver to step on when getting in or out of the vehicle. The pedal is designed with a non-slip surface to prevent accidents and ensure the driver’s safety.
  • 4. License Plate Mounting
    The front license plate plate mounting plate assembly consists of the upper brackets on the left and right sides of the license plate mounting plate. These brackets are used to attach the license plate to the vehicle. Hexagon socket head cap screws, sleeves, and hexagon flange face screws are used to secure the brackets in place.
  • 5. Additional Components
    The assembly also includes a tool kit protection strip, which helps to protect the tool kit from damage. Flat washers and spring washers are used to fasten the protection strip in place. The hexagonal flange face nuts are used to secure the license plate to the mounting plate.
  • In conclusion, the XCMG Front License Plate Mounting Plate And Pedal is a well-designed and functional assembly that provides a secure and safe mounting solution for the license plate while also incorporating an anti-skid pedal for added safety. The use of high-quality components and fasteners ensures the durability and reliability of the assembly.

Product Parameters of Sitrak Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)

712-#2460-0005  Front License Plate Mounting Plate And Pedal (Metal Bumper, Fixed Front License Plate)
Serial No. Drawing No.  Name Quantity
1 810W41615-4013 U-tube assembly 1
2 810W06201-0018 Clip 2
3 Q40105 Flat washer 4
4 Q340B05 Hexagon nut type 1 4
5 Q40305 Spring washer 4
6 810W41615-2147 Anti-skid pedal 1
7 Q2206316F31 Cross recessed pan head tapping screw and flat washer assembly 4
8 Q218B1245 Hexagon socket head cap screw 2
9 810W93030-0258 Sleeve 2
10 Q40012 Small washer 4
11 Q33212F31 Hexagon lock nut type 2 all-metal 2
11 Q33212F31 Hexagon lock nut type 2 all-metal 2
12 712W42940-2060 Front license plate plate mounting plate assembly 1
13 712W42940-2061 Upper bracket on the left side of the license plate mounting plate 1
14 712W42940-2062 Upper bracket on the right side of the license plate mounting plate 1
15 Q218B1270 Hexagon socket head cap screw 2
16 810W93030-0259 Sleeve 2
17 Q1840620 Hexagon flange face screw 4
17 Q1840620 Hexagon flange face screw 2
18 Q32006 Hexagon flange face nut Face nut 4
18 Q32006 Hexagonal flange face nut 2
19 Q40106 Flat washer 4
20 Q40306 Spring washer 2
21 710W66912-6214 Tool kit protection strip 1
