Sitrak Air Dryer And Four-Circuit Assembly (1.0mpa With Energy Saving)
Sitrak Air Dryer And Four-Circuit Assembly (1.0mpa With Energy Saving)
2025-05-14
Sitrak Aluminum Cylinder Unit (Pressure Retaining Cylinder 799 Mounted Longitudinal Beam)
Sitrak Aluminum Cylinder Unit (Pressure Retaining Cylinder 799 Mounted Longitudinal Beam)
2025-05-14

Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)

Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)
Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)
Download Catalog
Get Quotation

What is the Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)

  • Introduction to XCMG Aluminum Storage Cylinder Unit
  • The XCMG Aluminum Storage Cylinder Unit, featuring a Small Battery Box (276 Diameters/782×2+786 Lifting), is a cutting-edge solution designed for heavy machinery, offering reliable compressed air storage with optimized weight and durability. Engineered for construction, mining, and industrial applications, this unit combines high-strength aluminum alloy cylinders with robust mounting components to ensure safe and efficient operation under extreme conditions.
  • Core Structural Components
  • The system is built around the Aluminum Alloy Storage Cylinder Assembly Φ276/40L, which provides ample capacity while minimizing weight through advanced alloy construction. The 2-Hole Gasket Plate and Storage Cylinder Bracket (φ276) offer secure mounting, fastened with Hexagonal Flange Face Bolts M10 and Hexagonal Flange Face Nuts M10, ensuring vibration-resistant connections. The Reservoir Bracket Assembly and Spacer further enhance stability, distributing load evenly across the structure.
  • Drainage and Sealing Systems
  • Maintenance is simplified with Drain Valves strategically positioned to remove condensate, preventing corrosion and ensuring air quality. Plugs NG12-M22X1.5 seal unused ports, while Elastomeric Elements NG12, Circlip NG12, and Nut Holder NG12 components provide reliable sealing and secure fastenings, critical for high-pressure applications. The Spring Washer and Type 2 Hexagonal Nut M10*1.25 prevent loosening due to vibration, maintaining system integrity over time.
  • Modular Reservoir Configuration
  • The unit includes a 5L Reservoir Bracket Assembly R77 and Aluminum Alloy Reservoir Bracket Assembly Φ155/5L, offering auxiliary storage for specialized pneumatic systems. Reservoir Tightening Strap Assemblies (Φ155 and Φ276) secure these components, while Flat Washers, Pins, and Cotter Pins ensure precise alignment and structural stability. The Aluminum Alloy Reservoir Bracket Assembly Φ276/30L provides additional capacity, making the system adaptable to diverse machinery requirements.
  • Lifting and Installation Features
  • Designed for easy integration, the 782×2+786 Lifting configuration facilitates safe handling during installation and maintenance. Tension Pins and Hexagon Socket Head Cap Screws secure lifting points, ensuring safe transport and positioning. The use of lightweight aluminum alloy reduces overall equipment weight, enhancing fuel efficiency and operational performance without compromising strength.
  • Conclusion: Lightweight Durability for Heavy-Duty Applications
  • The XCMG Aluminum Storage Cylinder Unit delivers a perfect balance of durability, capacity, and weight optimization. Its modular design, corrosion-resistant materials, and robust fastening systems make it ideal for demanding environments where reliability is critical. Whether for braking systems, air suspension, or auxiliary pneumatic functions, this unit provides a trusted solution for heavy machinery manufacturers and operators worldwide.

Product Parameters of Sitrak Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782x2+786 Lifting)

712-#0334-3067 Aluminum Storage Cylinder Unit . Small Battery Box (276 Diameters/782×2+786 Lifting)
Serial No. Drawing No.  Name Quantity
1 810W97486-0690 2-hole gasket plate 4
2 752W51715-0024 Storage cylinder bracket (φ276) 4
3 ZQ1841025TF6 Hexagonal flange face bolts M10 8
3 ZQ1841025TF6 Hexagonal flange face bolts M10 2
5 WG9000360782 Aluminum alloy storage cylinder assembly Φ276/40L 2
6 WG9000361402 Drain valve 2
6 WG9000361402 Drain valve 1
6 WG9000361402 Drain valve 1
7 WG9000361012 Plugs NG12-M22X1.5 2
8 WG9700360002 Storage cylinder tightening strap assembly (Φ276) 4
9 WG700 550013 Tension pin 4
9 WG700 550013 Tension pin 1
10 WG09  190017 Tension pin 4
10 WG09  190017 Tension pin 1
11 Q218B0880 Hexagon socket head cap screw 4
11 Q218B0880 Hexagon socket head cap screw 1
12 WG9000361007 Elastomeric element NG12 6
12 WG9000361007 Elastomeric element NG12 1
13 WG9000361008 Circlip NG12 6
13 WG9000361008 Circlip NG12 1
14 WG9000361009 Nut Holder NG12 6
14 WG9000361009 Nut Holder NG12 1
15 711W51715-5053 5L Reservoir Bracket Assembly R77 1
16 WG9000360789 Aluminum Alloy Reservoir Bracket Assembly Φ155/5L 1
17 WG9700360006 Reservoir Tightening Strap Assembly (Φ155) 1
18 WG9000360786 Aluminum Alloy Reservoir Bracket Assembly Φ276/30L 1
19 WG9700360007 Reservoir Tightening Strap Assembly (Φ276) 2
20 Q40110 Flat Washers 4
21 Q5101048 Pins 2
22 Q5003214 Cotter pins 2
23 ZQ32010T13F6 Hexagonal flange face nuts M10 8
23 ZQ32010T13F6 Hexagonal flange face nuts M10 4
23 ZQ32010T13F6 Hexagonal flange face nut M10 2
24 WG9118360004 Reservoir bracket assembly 2
25 WG9925360874 Spacer 4
26 ZQ1841055TF6 Hexagonal flange face bolt M10 4
27 ZQ361B10 Type 2 hexagonal nut M10*1.25 2
28 Q40310 Spring washer 2
