Shacman X6000 Controller Bracket

Shacman X6000 Controller Bracket
Shacman X6000 Controller Bracket
Download Catalog
Get Quotation

What is the Shacman X6000 Controller Bracket？

  • The Shacman X6000 Controller Bracket is a modular mounting solution engineered to securely position and protect the vehicle’s Electronic Control Unit (ECU), ensuring stable operation and reliable connectivity in demanding commercial environments. Crafted with high-strength materials and precision-fit components, this bracket system integrates seamlessly with the truck’s chassis, minimizing vibration-induced stress on the ECU while facilitating easy installation and maintenance. Below is a detailed breakdown of its key components:​
  • 1. ECU Bracket 1 (Body)​
  • The ECU Bracket 1 (Body) serves as the primary structural foundation, fabricated from lightweight yet durable aluminum alloy to withstand harsh engine bay temperatures and corrosive elements. Its contoured design features reinforced ribs for enhanced rigidity, strategically placed mounting points to align with the ECU’s form factor, and pre-drilled holes for precise chassis integration. The bracket’s surface is treated with a thermal-conductive coating to dissipate heat efficiently, protecting the ECU from overheating during prolonged operation.​
  • 2. ECU Bracket 3 & ECU Bracket 4​
  • ECU Bracket 3 acts as a lateral support arm, connecting the primary bracket to the vehicle’s frame to eliminate side-to-side movement. Made from high-tensile steel with a powder-coated finish, it features adjustable slots that allow minor positional adjustments to accommodate different ECU configurations.​
  • ECU Bracket 4 functions as a vertical stabilizer, reinforcing the top or bottom of the ECU to prevent vertical displacement during heavy acceleration, braking, or off-road vibrations. Its L-shaped design fits snugly against the ECU’s corners, with rubberized mounting pads to isolate electrical components from direct metal contact and reduce noise interference.​
  • 3. Screw Bolts & Mounting Hardware​
  • High-strength Bolts (M6×20mm, zinc-plated steel) secure the brackets to the chassis and ECU, featuring a hexagon head for easy torque application (20-25Nm) and a self-locking thread design to resist loosening from continuous vibrations.​
  • Complementary Lock Washers and Flange Nuts are included to enhance joint stability, with serrated washers gripping mating surfaces to prevent rotational slippage and flange nuts distributing clamping force evenly across bracket interfaces.​
  • System Design & Performance Benefits​
  • The modular design of the Controller Bracket allows for quick, tool-free ECU installation and removal, simplifying diagnostic access and component replacement. By separating load-bearing functions across Bracket 1, 3, and 4, the system ensures balanced stress distribution, reducing the risk of fatigue damage to both the ECU and bracket components. All hardware meets ISO 898-1 strength standards, while the brackets comply with IP67 environmental ratings for dust and water resistance, making them ideal for long-haul trucks operating in diverse climates.​
  • The Shacman X6000 Controller Bracket delivers a robust, OEM-grade solution for securing critical electronic controls, combining structural integrity with installation flexibility. Each component is rigorously tested for vibration resistance, thermal stability, and dimensional precision, ensuring seamless compatibility with Shacman X6000 models. Regular inspection of bolt torque and bracket alignment is recommended to maintain optimal ECU performance and extend the system’s service life, ensuring reliable operation mile after mile.​

Product Parameters of Shacman X6000 Controller Bracket

NOPart.NoNameQuantity
1DZ9L149585210ECU bracket 1 (body)1
2Q341B08screw bolt2
3Q150B0616bolt1
4DZ9L149585204ECU bracket 41
5Q2300616bolt4
6DZ9L149585203ECU bracket 31
