Shacman X6000 Air Compessor Outer Line/6×4 13l

Shacman X6000 Air Compessor Outer Line/6×4 13l
Shacman X6000 Air Compessor Outer Line/6×4 13l
Download Catalog
Get Quotation

What is the Shacman X6000 Air Compessor Outer Line/6×4 13l？

  • The Shacman X6000 Air Compressor Outer Line/6×4 13L is a high-performance pneumatic system designed to efficiently transfer compressed air from the compressor to the vehicle’s brake system, air suspension, and auxiliary components. Engineered for heavy-duty 6×4 trucks with 13-liter engines, this outer line assembly combines durable materials and precision components to withstand high pressure, vibration, and harsh environmental conditions. Below is a detailed breakdown of its key components:​
  • 1. Nozzle & Seal Ring​
  • Nozzles serve as critical connection points for air intake and output, machined from corrosion-resistant aluminum alloy to ensure smooth airflow and minimal pressure loss. Their flared design aligns with hose fittings, creating a secure mechanical interface.​
  • Paired with Seal Rings (made from heat-resistant NBR rubber), these nozzles form leak-proof seals in high-pressure joints. The rings feature a double-lip design to prevent moisture and debris ingress, maintaining airtight integrity even at extreme temperatures (-40°C to +120°C).​
  • 2. Pipe & Stainless Steel Hose​
  • Steel Pipes (cold-drawn seamless steel, 6mm inner diameter) form the rigid backbone of the system, engineered to handle up to 16 bar of pressure. Their galvanized coating resists rust and chemical corrosion, ideal for long-term exposure to road salt and moisture.​
  • Stainless Steel Hoses provide flexible connections in high-vibration areas, such as between the compressor and chassis. Braided with 304-grade stainless steel, these hoses offer superior abrasion resistance and bend fatigue life, ensuring reliable performance without kinking or cracking.​
  • 3. Pipe Clamp & Bracket​
  • Pipe Clamps (stamped steel with EPDM rubber inserts) secure rigid pipes to the chassis, reducing vibration-induced wear. The rubber lining absorbs shocks and prevents metal-to-metal contact, extending pipe service life.​
  • Mounting Brackets (formed from high-strength steel) provide structural support for hoses and components, featuring pre-drilled holes for easy alignment with vehicle frame points. Their powder-coated finish enhances resistance to chipping and rust.​
  • 4. Hex.screw & Nut​
  • Zinc-plated Hex.screws (M8×25mm, 10.9-grade tensile strength) fasten brackets and clamps to the chassis, offering superior vibration resistance. Their hexagon head design allows easy torque adjustment (50-60Nm) with standard tools.​
  • All-metal Locknuts (Type 2, M8 thread) secure screw connections, featuring a nylon insert to prevent loosening under dynamic loads. These nuts comply with ISO 7042 standards, ensuring long-term reliability in high-stress environments.​
  • 5. System Integration & Performance​
  • The outer line assembly optimizes air flow for the 13L engine’s high-output compressor, minimizing pressure drops and ensuring rapid response for brake applications. Rigid pipes are routed along the chassis with precision-bent angles to avoid sharp turns, while flexible hoses accommodate suspension movement without compromising airflow. Each component is leak-tested at 1.5x operating pressure to meet SAE J1401 and GB/T 20022 standards, guaranteeing safety and compliance with international regulations.​
  • The Shacman X6000 Air Compressor Outer Line/6×4 13L delivers unmatched durability and performance, essential for maintaining the pneumatic system’s efficiency in heavy-duty truck operations. Regular inspection of seal rings for wear, hose integrity for cracks, and fastener torque for looseness will ensure optimal functionality and extend the assembly’s service life. Trust in OEM-quality components to keep your vehicle’s air system running smoothly, even under the most demanding conditions.​

Product Parameters of Shacman X6000 Air Compessor Outer Line/6×4 13l

NO Part.No Name Quantity
1 DZ9100360434 Nozzle 1
2 190003098031 Seal ring 1
3 DZ9X189360011 Pipe 1
4 Q68620 Pipe clamp 6
5 DZ9L149360025 Bracket 1
6 Q33006 Nut 4
7 Q1840616 Hex.screw 4
8 DZ93319360018 Stainless steel hose 1
9 DZ9M189365068 Bracket 2
10 Q1811440TF3 Hex.screw 2
11 06.11251.2005 Nut 2
12 DZ9X259369017 Pipe 1
13 DZ9H319470406 Bracket 1
14 Q341B14T13F3 Nut 1
15 Q150B1430 Hex.screw 1
16 DZ9100360428 Nozzle 1
17 Q351B22T15 Nut 1
18 168000250092 Seal ring 1
