Shacman X6000 Spare Wheel Carrier-Parts Catalog

Shacman X6000 Spare Wheel Carrier-Parts Catalog
Shacman X6000 Spare Wheel Carrier-Parts Catalog

What is the Shacman X6000 Spare Wheel Carrier-Parts Catalog?

  • The Shacman X6000 Spare Wheel Carrier Parts Catalog provides OEM-grade components designed to safely store and deploy spare wheels on heavy-duty trucks, ensuring reliability and ease of access in demanding operational environments. Engineered with robust materials and precision fasteners, this catalog includes essential parts to maintain the carrier’s structural integrity and functionality. Below is a detailed breakdown of key components:
  • 1. Spare Wheel Carrier
  • The Spare Wheel Carrier serves as the core structural component, constructed from high-strength steel alloy to withstand dynamic loads and road vibrations. Its powder-coated finish resists corrosion from moisture, salt, and debris, while the modular design allows adjustable mounting for different wheel sizes (e.g., 315/80R22.5). The carrier features a locking mechanism to secure the spare wheel during transit and a smooth pivot system for easy lowering/raising, minimizing effort during tire changes.
  • 2. High-Tensile Bolts
  • Mounting Bolts (M12×50mm, 10.9-grade steel) attach the carrier to the truck’s frame or undercarriage, engineered with a zinc-plated coating to resist rust. Their hexagon head design enables precise torque application (80-100Nm), ensuring secure fastening even under heavy suspension movement.
  • Wheel Retaining Bolts (M14×35mm) secure the spare wheel to the carrier, featuring a tapered seat to align with wheel hub holes and prevent lateral play. These bolts undergo heat treatment for enhanced shear resistance, critical for maintaining wheel stability during transport.
  • 3. Self-Locking Nuts & Flange Nuts (Self-locking Nuts & Flange Nuts)
  • Self-locking Nuts (M12, Type 2) are used on carrier-to-frame connections, with a nylon insert that creates friction to prevent loosening from vibrations. Compliant with ISO 7042 standards, they eliminate the need for additional lock washers, simplifying installation.
  • Flange Nuts (M14, serrated underside) secure wheel retaining bolts, distributing clamping force over a larger surface area to prevent damage to the carrier’s mounting plate. Their serrated design grips surfaces to resist rotational slippage in high-vibration environments.
  • 4. flat washer (Flat Washers)
  • Flat Washers (12mm and 14mm 内径) are placed between bolt heads/nuts and mating surfaces to evenly distribute pressure, reduce surface wear, and enhance joint integrity. Made from corrosion-resistant steel, they ensure uniform load transfer across critical connections, such as the carrier bracket to the chassis, minimizing the risk of fastener fatigue.
  • System Integration & Performance
  • The spare wheel carrier assembly is designed for quick, tool-free installation, with all components precision-engineered to match Shacman X6000’s chassis geometry. The combination of high-tensile bolts, vibration-resistant nuts, and load-distributing washers ensures the carrier remains securely attached, even on rough terrain. Regular maintenance—including torque checks for bolts and lubrication of pivot points—will extend the carrier’s service life and ensure reliable spare wheel access when needed most.
  • The Shacman X6000 Spare Wheel Carrier Parts Catalog delivers a comprehensive solution for maintaining your truck’s spare wheel system, with each component tested for durability, corrosion resistance, and compatibility. Trust in OEM-quality parts to keep your vehicle prepared for any road challenge, ensuring minimal downtime and maximum safety for your fleet.

Product Parameters of Shacman X6000 Spare Wheel Carrier-Parts Catalog

NOPart.NoNameQuantity
106.11251.2003Nut2
2Q402B12Washer2
3Q341C12T2F3Nut2
4Q1811250TF3Bolt2
506.11251.2005Nut4
6DZ9X259860002Spare wheel carrier2
7Q1811435TF3Bolt4
