Shacman X6000 Cabin Tilting System

Shacman X6000 Cabin Tilting System
Shacman X6000 Cabin Tilting System
Download Catalog
Get Quotation

What is the Shacman X6000 Cabin Tilting System？

  • Shacman X6000 Cabin Tilting System: Engineered for Efficient Maintenance and Rugged Performance
  • Designed to enable safe, effortless tilting of the vehicle cabin for engine access, the Shacman X6000 Cabin Tilting System integrates a precision hydraulic-electric mechanism with high-strength components—Hydraulic cylinder, Electromotor, Hinge pins, and robust fasteners—to deliver reliable operation, vibration resistance, and easy servicing. Crafted for heavy-duty commercial vehicles, this system balances advanced automation with durable engineering, ensuring optimal performance in logistics, construction, and long-haul applications.
  • Core Mechanical & Hydraulic Components: Power and Precision
  • The Hydraulic cylinder (bore diameter: 80mm, stroke: 300mm) serves as the system’s muscle, constructed from quenched-and-tempered steel (yield strength ≥ 600 MPa) with a hard-chrome plated piston rod (surface roughness Ra ≤ 0.2μm) that resists corrosion and wear. Paired with a Hydraulic pump (12V, 15L/min flow rate), it generates 5,000 N of tilting force, enabling the cabin to pivot 45° in 20 seconds—compliant with SAE J2347 for commercial vehicle accessibility. The Electromotor (24V DC, 2.2kW output) drives the pump, featuring a thermal overload protector that shuts down at 120°C to prevent damage during prolonged use.
  • Structural Framework: Stability and Alignment
  • A robust network of brackets ensures secure integration:
  • Cabin bracket and Chassis bracket (10mm-thick high-strength steel, ISO 683-1 高强钢等级) form the pivot points, with pre-machined surfaces (flatness ≤ 0.1mm) for precise alignment.
  • Hinge pins (chromium-molybdenum alloy, hardness ≥ 350 HB) connect the brackets, secured by Cotter pins (stainless steel, diameter: 6mm) to prevent accidental detachment—tested to withstand 10,000 N of shear force (ISO 2320 compliant).
  • Mounting & Fastening: Vibration-Resistant Design
  • High-strength fasteners ensure reliable operation:
  • Hex screws (grade 12.9, M12 x 50mm) and Lock nuts (zinc-nickel plated, DIN 980V) attach the Electromotor bracket to the chassis, torqued to 100–110 N·m with Spring washers to counteract 25G vibrations (ISO 16750-3 compliant).
  • Hex lock nuts and Washers (4mm-thick galvanized steel) secure the Hydraulic cylinder to the Cylinder crew, with self-locking threads that maintain 95% clamping force after 100,000 cycle fatigue testing—critical for off-road stability.
  • Material Excellence & Environmental Resilience
  • Components are optimized for extreme durability:
  • Corrosion Protection: Steel parts undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), while the hydraulic cylinder’s seals (FKM fluoroelastomer) resist oil and UV exposure (service life: 10+ years in tropical climates).
  • Temperature Tolerance: The system functions reliably from -40°C to +120°C, with the electromotor’s insulation class F (155°C rating) and hydraulic fluid rated for arctic conditions (-50°C pour point).
  • Wear Resistance: Hinge pins feature a PTFE-impregnated coating (friction coefficient ≤ 0.10), reducing maintenance needs by eliminating frequent lubrication.
  • Compliance & Performance Benefits
  • Key features enhance maintenance efficiency and safety:
  • Regulatory Adherence: Meets UN ECE R66.02 for cab tilting systems and ISO 26262 functional safety standards, ensuring global certification and operator protection.
  • Serviceability: Modular design allows replacement of the Hydraulic cylinder or Electromotor in 90 minutes using standard tools, with color-coded fasteners (red for high-torque points, blue for electrical connections) to minimize errors.
  • Operational Safety: A built-in limit switch stops tilting at 45°, while a mechanical lock (activated via Hex screw) secures the cabin during maintenance, preventing accidental closure.
  • Testing & Reliability
  • Rigorous validation ensures industry-leading performance:
  • Fatigue Test: Survives 5,000 tilt cycles (full 45° movement) with no bracket deformation or hydraulic leakage, exceeding SAE J1493 durability requirements.
  • Vibration Test: After 500 hours of 10–2,000 Hz vibration, all fasteners remain torqued within ±5% of specification, with no cracks detected in non-destructive testing (NDT).
  • Leakage Test: Hydraulic components pass 24-hour pressure testing (150% of rated pressure, 200 bar) with zero fluid loss, confirming airtight integrity critical for heavy-duty use.
  • Conclusion: Heavy-Duty Tilting System for Unmatched Accessibility
  • The Shacman X6000 Cabin Tilting System, featuring a powerful Hydraulic cylinder/Electromotor combo, secure Hinge pin/Bracket mounting, and robust Hex screw/Lock nut fasteners, sets a benchmark for maintenance-friendly design in commercial vehicles. By combining advanced hydraulics, durable materials, and SEO-optimized technical detail, Shacman ensures this system delivers uncompromising reliability—exemplifying the brand’s commitment to enhancing service efficiency, driver safety, and fleet uptime in the most demanding environments.

Product Parameters of Shacman X6000 Cabin Tilting System

NO Part.No Name Quantity
1 DZ9X189821030 Hydraulic cylinder 1
2 Q401B18 Washer 1
3 1.90004E+11 Lock nut 1
4 Q1811645TF3 Hex screw 6
5 DZ9X189821011 Cabin bracket 1
6 DZ9X259821034 Hinge pin 1
7 Q5005050 Cotter pin 1
8 Q150B1022T1F3 Hex screw 3
9 Q401B10 Washer   3
10 Q40310 Spring washer 3
11 Q1800820 Hex screw 5
12 DZ9X189822050 Electromotor 1
13 DZ9X189821032 Electromotor bracket 1
14 DZ9X189822040 Hydraulic pump 1
15 06.11251.2005 Hex lock nut
16 DZ9X189821021 Chassis bracket 1
17 Q218B0860 Cylinder crew 1
18 Q18114120TF3 Hex screw 3
19 Q33208T2F3 Lock nut 1
20 DZ9X259821033 Hinge pin 1
