SANY Rear Axle Installation Assembly

What is the SANY Rear Axle Installation Assembly

  • The SANY Rear Axle Installation Assembly is a critical subsystem designed to ensure structural integrity, stability, and load-bearing performance in heavy-duty machinery. This assembly integrates several precision components to facilitate secure mounting and optimal functionality. The rear axle serves as the primary load-carrying element, transferring torque and supporting vertical loads. To restrict excessive movement and maintain alignment, a limit block is strategically positioned, working in tandem with the middle axle limit support to enhance lateral stability and minimize operational stress.
  • Fastening is achieved through high-strength bolt systems, complemented by a WASHER-HARD to distribute clamping force and prevent surface deformation. Additional washer elements provide secondary support and corrosion resistance, while a locking nut ensures threaded fasteners remain secure under dynamic conditions. A specialized screw is employed for auxiliary adjustments, further reinforced by a flat washer to maintain tension integrity. Finally, the tyre assembly is mounted to complete the system, enabling traction and mobility.
  • The SANY Rear Axle Installation Assembly exemplifies engineering precision, leveraging robust materials and meticulous design to endure extreme operational environments. Each component plays a vital role in ensuring safety, durability, and performance, reflecting SANY’s commitment to reliability and innovation in heavy equipment manufacturing.

Parameters of SANY Rear Axle Installation Assembly

No. Part No. Description Qty
1 131401020098A Rear axle 1
2 131499000006A limiit block 2
3 14354041 Middle axle limit support 2
4 A210111000023 Bolt 8
5 A210405000011 WASHER-HARD 8
6 A210401000001 Washer 8
7 A210307000017 Nut 8
8 A210204000158 Screw 4
9 A210405000003 Washer 4
10 ODT004586542 Tyre assembly 4
