| NO | PART NO. | PART NAME | Q’TY |
| 1 | ZL50G2-07001 | M22x1.5 Joint | 4 |
| 2 | ZL50G2-07002 | Tee Fitting | 1 |
| 3 | ZL50G2-07003 | Joint | 7 |
| 4 | ZL50G2-07004 | Joint | 3 |
| 6 | DG956W 11 -07006 | Intake-tube for Air Reservoir | 1 |
| 7 | DG956W 11 -07005 | Exit Pipe for Air Compressor | 1 |
| 8 | ZL50G2-07009A | Air Reservoir | 1 |
| 9 | 08958-07010 | Plug | 1 |
| 10 | ZL50G2-07011 | Bracket for Rear Braking Pump | 1 |
| 11 | ZL50G2-07013 | M12x1.25×45 Link Bolt | 4 |
| 12 | ZL50G2-07014 | Braking Pipe | 4 |
| 12A | ZL50G2-07014B | Braking Pipe (Match Feicheng Axle) | 4 |
| 13 | ZL50G2-07015 | M12x1.25 Link Bolt | 4 |
| 14 | ZL50G2-07016A | Tee Fitting | 1 |
| 15 | ZL50G2-07017 | Braking Pipe of Axle | 2 |
| 15A | ZL50G2-07017B | Braking Pipe of Axle (Match Feicheng Axle) | 2 |
| 16 | ZL50G2-07018 | Tee Fitting | 1 |
| 17 | ZL50G2-07019 | Joint | 1 |
| 18 | ZL50G2-07020 | Joint | 1 |
| 19 | ZL50G2-07021A | Bracket for Air Reservoir | 2 |
| 20 | ZL50G2-07022A | Air Reservoir Hoop | 2 |
| 21 | ZL50G2-07024 | Plug | 1 |
| 22 | ZL50G2-07025 | Joint | 1 |
| 23 | 08965-07026 | Barometer Tube | 1 |
| 24 | ZL50G2-07027 | Hose.Rear Air Boosting Pypm to Rear Axle | 1 |
| 25 | DG958-07028 | Hose,Hand Brake Valve to Cut-0ff Valve | 1 |
| 26 | DG958-07030 | Hose，Front Braking Pump to Foot Brake Valve | 1 |
| 27 | ZL50G2-07031 A | Hose,Front Braking Pump to Rear Axle | 1 |
| 28 | ZL50G2-07032 | Hose,Air Reservoir to Foot Brake Valve | 1 |
| 29 | 08958-07034 | Hose,Ex1t Canister to Hand Brake Valve | 1 |
| 30 | ZL50G2-07035 | Hose.Cut-0ff Valve to Shut-off Valve | 1 |
| 31 | ZL50G2-07036 | Hose,Cut-0ff Valve to Brake Air-chamber | 1 |
| 32 | ZL50G2-07037 | Hose,Foot Brake Valve to Rear Pump | 1 |
| 33 | ZL50G3-07014 | Joint | 1 |
| 34 | ZL50G3-07015 | Joint | 1 |
| 35 | ZL50G3-07046 | Pump Device | 1 |
| 36 | ZL50G2-07043 | Jomt | 1 |
| 37 | ZL50G2-07044 | Joint | 1 |
| （1） | GB6170-86,M12 | Nut | 4 |
| （2） | GB93-87,12 | Washer | 6 |
| （3） | GB5781-86,M12x30 | Bolt | 4 |
| （4） | XM60C-3214005 | Air Brake Valve (With Pedal) | 1 |
| （5） | GB5781-86,M8x30 | Bolt | 4 |
| （6） | GB93-87,8 | Spring Washer | 4 |
| （7） | QZSOA-3526001 | Mannual Control Brake Valve | |
| （8） | QZ50A-3516002 | Air Control Cut-off Valve | 1 |
| （9） | XZ60A-3510001 | Air Reinforce Pump | 2 |
| （12） | GB5781-86,M10x25 | Bolt | 6 |
| （13） | GB93-87,10 | Spring Washer | 12 |
| （14） | SH380A-3511002 | Oil-water Separator Combination Valve | 1 |
| （15） | GB6170-86,M10 | Nut | 6 |
| （16） | GB5781-86,M10x70 | Bolt | 2 |
| （17） | JB982-77,22 | Combined Washer | 3 |
| （18） | HHSOA-3507002 | Parking Brake Air-chamber | 1 |
| （19） | JB982-77,12 | Combined Washer | 18 |
| （20） | JN150-372001 | Braking Light Switch | 1 |
| （21） | GB5781-86,M10x30 | Bolt | 4 |
| （22） | 35360070010 | Automatic Drain Water Valve | 1 |
| （23） | GB5781-86,M12x25 | Bolt | 2 |
| （24） | JB982-77,14 | Combined Washer | 2 |
| （25） | GB95-85,16 | Flat Washer | 2 |
| （26） | ZD200x8 | Clip | 6 |
| （27） | SH-40-TSK-L 1/2″ | Pneumatic Celerity Joint | 1 |
