Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)

Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)
Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)
Download Catalog
Get Quotation

What is the Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)

  • The Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five) is a sophisticated and efficient heating solution designed specifically for C7 vehicles with Wp10h engines, catering to both wide body and medium wide body cabs with an 80 – mm raised profile and meeting National Five emissions standards. This system is engineered to provide a comfortable and consistent warm air supply within the cab, ensuring driver comfort even in cold weather conditions.
  • The system consists of a series of interconnected components that work in harmony to transfer heat from the engine to the cab. The Warm air cab water inlet hose and Warm air cab return hose play a crucial role in this process. These hoses are designed to efficiently transport the heated coolant from the engine to the cab’s heating unit and back, ensuring a continuous circulation of warm air. The Gasket plate is used to create a tight seal between various components, preventing any leakage of coolant or air, which could compromise the system’s efficiency.
  • To secure the hoses and pipes in place, a variety of fasteners and clamps are utilized. Double hose clamp(φ18) and Heating air hose single clamp are used to tightly secure the hoses, preventing any movement or disconnection. These clamps are made from durable materials that can withstand the pressure and temperature fluctuations within the system. Hexagonal flange bolts in different sizes, such as M8, M6, and M10, along with their corresponding Hexagonal flange nuts, are used to fasten various components together. For example, the Hexagonal flange bolt M8 and Hexagonal flange nut M8 are used to secure the Warm air engine outlet pipe and other related components. The Large washer is used in conjunction with the bolts to distribute the clamping force evenly, preventing damage to the components.
  • The Single pipe clamp(φ15) is used to hold the Warm air engine return pipe in place, ensuring its stability and preventing any vibrations that could cause wear or damage. The Wave spring clamp is also employed in the system, providing a secure and reliable connection for hoses and pipes. Its unique design allows for easy installation and adjustment, while maintaining a tight seal.
  • The Heater hose bracket is an essential component that provides support and stability for the hoses, ensuring they are properly positioned and protected. It is fastened using Hexagonal flange bolts M10 and Hexagonal flange nut M10. Additionally, the Plastic fastening tape 7.6×368 is used to neatly bundle and secure the hoses, preventing them from getting tangled or damaged.
  • In summary, the Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five) is a well – designed and reliable heating solution that offers commercial vehicle operators a comfortable driving experience in cold weather. Its efficient heat transfer mechanism, secure fastening system, and durable components make it an ideal choice for vehicles equipped with C7 engines and wide body cabs. Whether for long – haul transportation or local deliveries, this warm air system ensures that the cab remains warm and comfortable, enhancing driver productivity and safety.

Product Parameters of Sitrak Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)

712-#05W0-0101 Warm Air System (C7/Wp10h/Wide Body/Medium Wide Body Cab Raised 80 Shared/National Five)
Serial No.  Drawing No. Name Quantity
1 ZQ32008 Hexagonal Flange Face Nut M8 2
2 YG9625530025 Warm air cab water inlet hose 1
3 YG9625530026 Warm air cab return hose 1
4 712W97488-0001 Gasket plate 1
5 712W61941-0002 Double hose clamp(φ18) 2
6 ZQ1840845 Hexagonal flange bolt M8 2
7 712W61960-0051 Warm air engine water outlet hose 1
8 712W61960-0050 Warm air engine return hose 1
9 712W96301-0111 Warm air engine return pipe 1
10 ZQ1840625 Hexagonal flange bolt M6 1
11 Q40206 Large washer 1
12 WG9000365401 Single pipe clamp(φ15) 1
13 ZQ32006 Hexagonal flange nut M6 1
14 ZQ1841025 Hexagonal flange bolt M10 2
15 712W61941-0001 Heater hose bracket 1
16 ZQ32010 Hexagonal flange nut M10 2
17 811W97401-0631 Plastic fastening tape 7.6×368 2
18 712W96301-0110 Warm air engine outlet pipe 1
19 ZQ1840820 Hexagonal flange bolts M8 1
20 WG9925535003 Heating air hose single clamp 1
21 YG9003981627 Wave spring clamp 4
21 YG9003981627 Wave spring clamp 4
