What is the Sitrak Narrow Body Cab Air Conditioner(Shanteka,Wp10,New Wheel System,2020)

  • Sitrak Narrow Body Cab Air Conditioner(Shanteka,Wp10,New Wheel System,2020): Precision Climate Control for Commercial Vehicles​
  • The Sitrak Narrow Body Cab Air Conditioner, tailored for Shanteka models with Wp10 engines and integrated into the new wheel system from 2020, represents a pinnacle of automotive climate control engineering. Engineered to meet the rigorous demands of commercial vehicle operations, this air conditioning system combines advanced technology, robust components, and meticulous craftsmanship to ensure a comfortable and efficient driving experience, regardless of external weather conditions.​
  • At the heart of the system is the Air Conditioner Assembly (Shanteka Narrow Body), a comprehensive unit designed by Shanghai Yida. This assembly integrates multiple subsystems, including the Evaporator Assembly (Shanghai Yida), which efficiently cools the air by absorbing heat from the cab’s interior. The Defrost Damper Actuator (Shanghai Yida), Heating & Cooling Damper Actuator (Shanghai Yida), and Face – blowing Damper Actuator (Shanghai Yida) work in harmony to precisely control the direction and temperature of the airflow, ensuring optimal comfort for the driver. The Warm air core assembly (Shanghai Yida) provides additional warmth during colder months, while the Air Conditioning Wiring Harness Assembly (Shanghai Yida) and Relay (Shanghai Yida) ensure seamless electrical operation and power management.​
  • The Filter system assembly, available from both Shanghai Yida and Jinan Autinka, plays a crucial role in maintaining air quality within the cab. The Air Conditioner Filter Element Assembly (Shanghai Yida) effectively traps dust, pollen, and other contaminants, preventing them from circulating in the air and ensuring a clean and healthy environment for the driver.​
  • The Control panel assembly offers intuitive and user – friendly controls, allowing drivers to easily adjust the temperature, fan speed, and airflow mode. The Cover Plate Assembly and Cover Plate not only protect the internal components but also enhance the aesthetic appeal of the air conditioner. Fixed Clips are used to securely hold these covers in place, ensuring a snug fit that prevents any rattling or vibration.​
  • A complex network of pipes and hoses, including the Hot Water Pipe, Cold Water Pipe, Water Valve Inlet Pipe, and Water Valve Outlet Pipe, facilitates the transfer of coolant and refrigerant throughout the system. Pipe Clamps, Single pipe clamp (φ18), Wave spring clamps, and Plastic fastening tape A5*280 are employed to secure these pipes, preventing leaks and ensuring a stable flow. The Water valve assembly, covered by the Water Valve Assembly Upper Shroud, regulates the flow of coolant, enabling precise temperature control.​
  • To ensure a secure installation, a variety of fastening components are utilized. Hexagonal flange face nuts, Hexagonal flange face screws, Cross recessed pan head screws, Ⅰ type hexagon nuts, Hexagon head bolts, and their corresponding washers, such as Large washers, Spring washers, and Flat washers, are used to attach various parts of the air conditioner to the cab. Sheet metal bracket (Shanghai Yida) and Bracket assembly provide sturdy support, ensuring the system remains stable even during the vibrations of heavy – duty driving.​
  • The Condenser core assembly is a vital component responsible for dissipating heat from the refrigerant, while the Cold – vapor tube assembly, Steam Pressure Pipe Assembly, and Pressure – cooled pipe assembly work together to circulate the refrigerant efficiently. These components are held in place by Hexagonal flange bolts and Hexagonal flange nuts, ensuring a leak – proof and reliable connection. The Cold and steam pipe frame section provides additional structural support, enhancing the overall durability of the system.​
  • Additional components, such as the Indoor temperature sensor (Shanghai Yida), Outdoor Temperature Sensor (Shanghai Yida), and Speed Control Module Assembly (Shanghai Yida), enable intelligent climate control, automatically adjusting the air conditioning settings based on ambient conditions. The Air conditioner housing assembly (Shanghai Yida) protects the internal components from dust, moisture, and physical damage, while the Air Conditioning Label provides essential information about the system’s specifications and operation.​
  • In the realm of vehicle identification and safety, the Vehicle Plate (for Dump and Truck), Commercial Vehicle Company Shanteka Plate Tail Marker, Nameplate Pin, and Brake Plate – Commercial Vehicle ensure compliance with regulatory requirements and enhance the visibility and safety of the vehicle on the road.​
  • In conclusion, the Sitrak Narrow Body Cab Air Conditioner(Shanteka,Wp10,New Wheel System,2020) is a highly reliable and efficient climate control solution for commercial vehicles. With its advanced components, secure installation, and intelligent control features, it offers drivers a comfortable and productive driving environment, making it an essential addition to any Shanteka – based commercial fleet.

Product Parameters of Sitrak Narrow Body Cab Air Conditioner(Shanteka,Wp10,New Wheel System,2020)

YC16008222016  Narrow Body Cab Air Conditioner(Shanteka,Wp10,New Wheel System,2020)
Serial No.  Drawing No. Name Quantity
1 YG1600822202 Air Conditioner Assembly (Shanteka Narrow Body) 1
2 711W61900-7132 Filter system assembly 1
3 712W61942-0630 Control panel assembly 1
4 810-61942-6004 Cover Plate Assembly 1
5 810-61942-0083 Cover Plate 1
6 810-61910-0022 Fixed Clip 2
7 810-61960-0739 Hot Water Pipe 1
8 810-61960-0740 Cold Water Pipe 1
9 810-97450-0039 Pipe Clamps 1
10 810-25441-5386 Bracket assembly 1
11 812W61960-0007 Water Valve Inlet Pipe 1
12 YG1600821252 Water valve assembly 1
13 812W61960-0009 Water Valve Outlet Pipe 1
14 712W61942-0644 Plug cover 1
15 712W61967-0042 Water Valve Assembly Upper Shroud 1
16 WG1630820313/5 Indoor temperature sensor (Shanghai Yida) 1
17 WG9000365402 Single pipe clamp (φ18) 2
18 Q32006 Hexagonal flange face nut 2
18 Q32006 Hexagonal flange face nut 1
19 Q2140825F31 Cross recessed pan head screws 2
19 Q2140825F31 Cross recessed pan head screws 1
20 Q40208F31 Large washers 2
21 Q40308F31 Spring washers 2
22 Q2204825F31 Cross recessed pan head tapping screws and flat washers assemblies 2
23 Q2714822F31 Cross recessed pan head tapping screws 2
24 Q340B06F31 Ⅰ type hexagon nuts 1
24 Q340B06F31 Ⅰ type hexagon nuts 1
25 Q40106F31 Flat washers 1
26 Q40108F31 Flat washers 1
27 YG9003982032 Wave spring clamps 2
28 Q2300616F31 Cross slot pan head screws and flat washers assemblies 3
29 Q1460835F31 Hexagon head bolts, spring washers and flat washers assemblies 4
30 WG9003171356 Plastic fastening tape A5*280 2
31 Q1840816 Hexagonal flange bolts 2
32 AZ9007310012 Refrigerant (R134a) 60
33 YG1600821220 Condenser core assembly 1
34 Q1840830 Hexagonal flange face screws 4
35 YG1600822132 Cold-vapor tube assembly 1
36 Q1840620 Hexagonal flange bolts 1
36 Q1840620 Hexagonal flange bolts 1
37 Q1840850 Hexagonal flange bolts 1
38 Q32008 Hexagonal flange nuts 1
38 Q32008 Hexagonal Flange Nuts 1
39 Q1840840 Hexagonal flange bolts 1
40 YG1600822134 Steam Pressure Pipe Assembly 1
41 YG1600822133 Pressure-cooled pipe assembly 1
42 Q1840625 Hexagonal flange bolts 1
43 Q1840820 Hexagonal flange bolts 1
44 YG1600822135 Cold and steam pipe frame section 1
45 Q150B0825 Hexagon head bolts 1
46 Q1460816 Hexagon head bolts spring washers and flat washers assemblies 1
47 712W61942-0649 Air Conditioning Label 1
48 712W61942-0818/5 Sheet metal bracket (Shanghai Yida) 1
YG1600822202 Air Conditioner Assembly (Shanteka Narrow Body)
Serial No.  Drawing No. Name Quantity
1 YG1600822202/5 Air Conditioner Assembly(Shanteka Narrow Body)(Shanghai Yida) 1
YG1600822202/5 Air Conditioner Assembly (Shanteka Narrow Body)(Shanghai Yida)
Serial No.  Drawing No. Name Quantity
1 812W61942-0047/5 Evaporator Assembly (Shanghai Yida) 1
2 812W61942-0093/5 Defrost Damper Actuator (Shanghai Yida) 1
3 812W61942-0094/5 Heating & Cooling Damper Actuator (Shanghai Yida) 1
4 812W61942-0095/5 Face-blowing Damper Actuator (Shanghai Yida) 1
5 812W61942-0096/5 Warm air core assembly (Shanghai Yida) 1
6 812W61942-0102/5 Air Conditioning Wiring Harness Assembly (Shanghai Yida) 1
7 WG1642822084/5 Relay (Shanghai Yida) 1
8 YG1600822219/5 Air conditioner housing assembly (Shanghai Yida) 1
711W61900-7132 Filter System Assembly
Serial No.  Drawing No. Name Quantity
1 711W61900-7132/5 Filter System Assembly (Shanghai Yida) 1
2 711W61900-7132/2 Filter System Assembly (Jinan Autinka) 1
711W61900-7132/5 Filter System Assembly (Shanghai Yida)
Serial No.  Drawing No. Name Quantity
1 711W61900-0051/5 Air Conditioner Filter Element Assembly (Shanghai Yida) 1
2 811W61942-0003/5 Blower Assembly (Shanghai Yida) 1
3 812W61942-0092/5 Internal and External Circulation Actuator (Shanghai Yida) 1
4 812W61942-0097/5 Outdoor Temperature Sensor (Shanghai Yida) 1
5 WG1664821019/5 Speed Control Module Assembly (Shanghai Yida) 1
712-#0570-0002 C7H Chinese nameplate for complete vehicle (dump)
Serial No.  Drawing No. Name Quantity
1 AZ1632955012 Vehicle Plate (for Dump and Truck) 1
2 WG1632950061 Commercial Vehicle Company Shanteka Plate Tail Marker 1
3 WG9003900025 Nameplate Pin 2
4 AZ9100360358 Brake Plate-Commercial Vehicle 1
