Sitrak T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)

Sitrak T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)
Sitrak T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)
Download Catalog
Get Quotation

What is the Sitrak T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)

  • The Sitrak T5g Cooling System, specifically designed for the D08 – 6 Cylinder Engine with a 270 – 280 frame and capable of 300 Hp or more, is a vital component that plays a crucial role in maintaining the engine’s temperature within the optimal range. This cooling system is engineered with precision and a combination of high – quality components to ensure efficient heat dissipation and reliable performance.
  • The MC07 Large Cooling Module is the heart of the system. It is responsible for transferring the heat generated by the engine to the surrounding air. The Radiator Left Bracket and Radiator Right Bracket provide sturdy support for the radiator, holding it firmly in place. Rubber shock absorber blocks are installed between the radiator and the brackets to reduce vibrations and prevent damage caused by road bumps and engine movement.
  • The Air shield is designed to direct the airflow through the radiator, enhancing the cooling efficiency. The Radiator inlet hose and Radiator Outlet Hose are used to circulate the coolant between the engine and the radiator. Similarly, the Intercooler inlet hose and Intercooler outlet hose facilitate the flow of air through the intercooler, which cools the compressed air before it enters the engine.
  • The Expansion Tank Assembly serves as a reservoir for the coolant. The Expansion tank return hose allows the coolant to flow back into the system when needed. The Engine Drain Hose and Radiator Drain Hose are used for draining the coolant during maintenance or repair work. The Return air baffle helps in optimizing the airflow within the system, ensuring that the air is properly utilized for cooling.
  • Hexagonal Flange Bolt M10 and Hexagonal flange nuts M10 are used for heavy – duty fastening, providing a secure connection between major components. Hexagonal flange bolts M8 are also employed in various places to hold different parts together. Wave spring clamps and Wave Spring Clamps are used to secure hoses tightly, preventing coolant leakage. Power Clamps and Flexible Hose Clamps offer reliable hose connections with different levels of flexibility and strength.
  • Insulation Foam is used to reduce heat transfer and noise. Large Washers are placed under the bolt heads and nuts to distribute the load evenly and prevent damage to the components. Hexagonal Flange Nut M6 and Hexagonal flange bolts M6 are used for smaller – scale fastening applications. P – type clamps, Clamps, and Angle brackets are used to secure hoses, pipes, and other components in place.
  • Quick connectors provide a convenient and leak – free way to connect hoses and pipes. The Insect Screen is installed to prevent insects and debris from entering the radiator, which could otherwise block the airflow and reduce the cooling efficiency. The Bracket and Casing are used to support and protect various components of the cooling system.
  • Finally, a Wave spring clamp is used for additional hose security, and the Oil dipstick bracket is an important part that holds the oil dipstick in place, ensuring easy access for checking the engine oil level.
  • In conclusion, the Sitrak T5g Cooling System (D08 – 6 Cylinder Engine, 270 – 280 Frame, 300 Hp Or More) is a well – designed and reliable system that combines a wide range of components to effectively cool the engine. Whether it’s for long – haul transportation or heavy – duty operations, this cooling system ensures that the engine operates at its best, minimizing the risk of overheating and extending the engine’s lifespan.

Product Parameters of Sitrak T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)

752-#0270-0006 T5g Cooling System (D08-6 Cylinder Engine, 270-280 Frame, 300 Hp Or More)
No. Part Number Part Name English  Quantity
1 752W06100-0006 MC07 Large Cooling Module 1
2 752W06100-0004 Radiator Left Bracket 1
3 752W06100-0005 Radiator Right Bracket 1
4 752W96200-0002 Rubber shock absorber block 8
5 WG9725531360 Air shield 1
6 752W96301-0003 Radiator inlet hose 1
7 WG9725531802 Radiator Outlet Hose 1
8 752W96300-0002 Intercooler inlet hose 1
9 752W96300-0003 Intercooler outlet hose 1
10 752W06101-0001 Expansion Tank Assembly 1
11 WG9725531801 Expansion tank return hose 1
12 752W96303-0001 Engine Drain Hose 1
13 752W96303-0002 Radiator Drain Hose 1
14 WG9725531805 Return air baffle 1
15 ZQ1841055TF6 Hexagonal Flange Bolt M10 4
16 ZQ32010T13F6 Hexagonal flange nuts M10 4
17 ZQ1840816 Hexagonal flange bolts M8 6
17 ZQ1840816 Hexagonal flange bolts M8 4
18 YG9003984060 Wave spring clamp 2
18 YG9003984060 Wave Spring Clamps 2
19 WG9003980090 Power Clamps 2
20 752W98100-0002 Flexible Hose Clamps 2
21 WG9725536001 Insulation Foam 1
22 Q40206 Large Washers 4
23 ZQ32006 Hexagonal Flange Nut M6 4
24 WG9325531810 P-type clamps 3
25 YG9003981220 Clamps 2
25 YG9003981220 Clamps 2
26 WG9000362186 Angle bracket 1
27 752W06101-0003 Quick connectors 1
28 WG9725531650 Insect Screen 1
29 ZQ1840616 Hexagonal flange bolts M6 4
30 WG9725531306 Bracket 1
31 752W96000-0001 Casing 4
32 YG9003981627 Wave spring clamp 2
33 WG9725512076 Oil dipstick bracket 1
752W06100-0006 MC07 Large Cooling Module
No. Part Number Part Name English  Quantity
1 752W06100-0006/1 MC07 Large Cooling Module(Taian Dingxin) 1
2 752W06100-0006/3 MC07 Large Cooling Module(Liaocheng Detong) 1
752W06100-0006/1 MC07 Large Cooling Module(Taian Dingxin)
No. Part Number Part Name English  Quantity
1 752W06100-0007/1 Radiator Assembly(Taian Dingxin) 1
2 752W06100-0008/1 Intercooler assembly(Taian Dingxin) 1
752W06100-0007/1 Radiator Assembly(Taian Dingxin)
No. Part Number Part Name English  Quantity
1 WG9925530186+001/2 Drain screw plug(Taian Dingxin) 1
752W06100-0006/3 MC07 Large Cooling Module(Liaocheng Detong)
No. Part Number Part Name English  Quantity
1 752W06100-0007/3 Radiator Assembly(Liaocheng Detong) 1
2 752W06100-0008/3 Intercooler Assembly(Liaocheng Detong) 1
752W06101-0001 Expansion Tank Assembly
No. Part Number Part Name English  Quantity
1 752W06101-0001/2 Expansion tank assembly (Shandong Huatong) 1
752W06101-0001/2 Expansion tank assembly (Shandong Huatong)
No. Part Number Part Name English  Quantity
1 752W06101-0004/2 Filling cap assembly (Shandong Huatong) 1
2 752W06101-0005/2 Pressure cover assembly (Shandong Huatong) 1
3 752W06101-0006/2 Box assembly (Shandong Huatong) 1
4 752W06101-0002/2 Liquid level sensor (Shandong Huatong) 1
