Sitrak L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)

Sitrak L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)
Sitrak L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)
Download Catalog
Get Quotation

What is the Sitrak L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)

  • The Sitrak L32 Cab Coil Spring Cab Suspension (L32 – 850 – High Steering) is a sophisticated and reliable system engineered to provide a smooth and stable ride for the Sitrak L32 cab. This suspension setup is a combination of high – quality components that work in harmony to ensure optimal performance and durability.
  • At the front of the cab, the Cab front suspension arm right transition bracket (T5G) and the Cab front suspension arm left transition bracket (T5G) play a vital role in connecting the suspension arms to the cab structure. The T5G Cab Front Suspension Arm Left Bracket Assembly (237 Frame) and the T5 Cab Front Suspension Arm Assembly Assembly are carefully designed to handle the dynamic forces during driving. These components are fastened securely using a variety of bolts and nuts.
  • Hexagonal flange face bolts with teeth M141.5 are extensively used in the assembly. Their toothed design provides a better grip and prevents loosening due to vibrations. Type 2 hexagonal nut M161.5 and hexagonal flange nuts with teeth M141.5 and M121.25 are used in conjunction with the corresponding bolts to ensure a tight and stable connection. The embedded lock washer (M16) and limit washer also contribute to the overall security of the joints.
  • The L32/40 series cab rear suspension coil spring damper assembly and the L32 series cab front suspension coil spring damper assembly are responsible for absorbing shocks and vibrations. They work together to provide a comfortable driving experience. The Cab Rear Suspension Right Upper Bracket Welding Assembly (T5G long cab) (symmetrical with left part) and the Cab Rear Suspension Left Upper Bracket Welding Assembly (T5G long cab) are crucial for mounting the rear suspension components. The T5 cab rear suspension bracket assembly (850 frame) further enhances the stability of the rear suspension.
  • In addition, the cab front suspension damper left upper bracket and the cab front suspension damper right upper bracket are used to position the front suspension dampers accurately. The slotted bracket provides flexibility and adjustability in the suspension system.
  • The hydraulic lock assembly ensures that the cab remains in a stable position during maintenance or when the lift cylinder is in use. The front suspension limit plate restricts the movement of the front suspension to prevent over – travel. The noise reduction block/81962100462 helps in reducing the noise generated by the suspension system during operation.
  • Hexagon head bolts such as Hexagon head bolt M16*1.5, Hexagon head flange bolts (MAN222 – M12X1,5X25H – MK14X4 – 10.9 – MAN183 – B1), and Hexagon head bolts with flange (MAN222 – M12X1,5X70H – MK18 – 10.9 – MAN183 – B1) are also used in different parts of the suspension for secure fastening. The Lift Cylinder Replacement Warning Sign is an important safety feature that alerts users during lift cylinder replacement.
  • Overall, the Sitrak L32 Cab Coil Spring Cab Suspension (L32 – 850 – High Steering) is a well – engineered system with a wide range of components, including various bolts, nuts, brackets, and dampers, all working together to provide a safe, comfortable, and reliable driving experience.

Product Parameters of Sitrak L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)

711-#05E0-0502  L32 Cab Coil Spring Cab Suspension (L32-850-High Steering)
No. Part Number Part Name English  Quantity
1 ZQ1811430TF6 Hexagonal flange face bolts with teeth M14*1.5 4
2 712W41720-2786 Cab front suspension arm right transition bracket (T5G) 1
3 ZQ361B16T13F6 Type 2 hexagonal nut M16*1.5 2
4 850W90710-0015 Limit washer 4
5 712W41720-2785 Cab front suspension arm left transition bracket (T5G) 1
6 711W41701-0050 T5G Cab Front Suspension Arm Left Bracket Assembly (237 Frame) 1
7 810W41701-0078 Slotted bracket 2
8 711W41701-5027 Cab Rear Suspension Right Upper Bracket Welding Assembly (T5G long cab) (symmetrical with left part) 1
9 811W41722-6032 L32/40 series cab rear suspension coil spring damper assembly 2
10 711W41701-5025 Cab Rear Suspension Left Upper Bracket Welding Assembly(T5G long cab) 1
11 711W41701-0040 T5 cab rear suspension bracket assembly (850 frame) 2
12 ZQ1811240TF6 Hexagonal flange face bolt with teeth M12*1.25 6
13 711-41701-0013 T5 Cab Front Suspension Arm Assembly Assembly 1
14 WG9000310016 Embedded lock washer(M16) 4
15 ZQ151B16120TF6 Hexagon head bolt M16*1.5 2
16 811W41722-6022 L32 series cab front suspension coil spring damper assembly 2
17 810W97812-2320 Lift Cylinder Replacement Warning Sign 1
18 810W41720-0147 Cab front suspension damper left upper bracket 1
19 810W41720-0148 Cab front suspension damper right upper bracket 1
20 MQ6-02836-4558 Hexagon head flange bolts(MAN222-M12X1,5X25H-MK14X4-10.9-MAN183-B1) 4
20 MQ6-02836-4558 Hexagon head flange bolts(MAN222-M12X1,5X25H-MK14X4-10.9-MAN183-B1) 6
21 MQ6-02836-4568 Hexagon head bolts with flange(MAN222-M12X1,5X70H-MK18-10.9-MAN183-B1) 4
22 Q1801655TF6 Hexagon head flange face bolts with teeth M16 4
23 ZQ1811455TF6 Hexagonal flange bolts with teeth M14*1.5 5
24 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 5
24 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 4
24 ZQ32514T13F6 Hexagonal flange nut with teeth M14*1.5 2
24 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 2
25 ZQ1811230TF6 Hexagonal flange bolts with teeth M12*1.25 8
26 ZQ32512T13F6 Hexagonal flange nuts with teeth M12*1.25 8
26 ZQ32512T13F6 Hexagonal flange nuts with teeth M12*1.25 6
26 ZQ32512T13F6 Hexagonal flange nuts with teeth M12*1.25 2
26 ZQ32512T13F6 Hexagonal flange nuts with teeth M12*1.25 2
27 ZQ1811480TF6 Hexagonal flange bolts with teeth M14*1.5 4
27 ZQ1811480TF6 Hexagonal flange bolts with teeth M14*1.5 2
27 ZQ1811480TF6 Hexagonal flange bolts with teeth M14*1.5 2
28 850-41740-0002 Front suspension limit plate 2
29 810W61851-6030 Hydraulic lock assembly 2
30 ZQ18112100TF6 Hexagonal flange bolts with teeth M12*1.25 2
30 ZQ18112100TF6 Hexagonal flange bolts with teeth M12*1.25 2
31 AZ1608440032 Noise reduction block/81962100462 2
32 ZQ1841020TF6 Hexagonal flange bolts M10 2
33 ZQ1811470TF6 Hexagonal flange bolts with teeth M14*1.5 2
810W61851-6030 Hydraulic lock assembly
No. Part Number Part Name English  Quantity
1 810W61851-6030/1 液压锁总成（丹阳恒泰） 1
2 810W61851-6030/3 液压锁总成（济南金翼） 1
810W61851-6030/1 Hydraulic lock assembly (Danyang Hengtai)
No. Part Number Part Name English  Quantity
1 810W61851-6030+001/1 液压锁传感器（丹阳恒泰） 1
