Sitrak Combined Pedal Control Mechanism (/Differential Pressure 0.3 Bar/0150 Bracket)
Sitrak Combined Pedal Control Mechanism (/Differential Pressure 0.3 Bar/0150 Bracket)
2025-05-14
Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)
Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)
2025-05-14

Sitrak Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)

Sitrak Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)
Sitrak Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)
Download Catalog
Get Quotation

What is the Sitrak Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)

  • Introduction to XCMG Combination Pedal Manipulator Assembly
    The XCMG Combination Pedal Manipulator Assembly, featuring a Differential Pressure of 0.3 bar and the robust 0150 Bracket, is an integrated control solution engineered for heavy machinery, delivering precision, durability, and operator comfort. Designed to streamline braking, acceleration, and clutch operations, this assembly combines advanced hydraulic components with ergonomic design, ensuring optimal performance in construction, mining, and industrial applications. Below is a detailed breakdown of its key components and their roles in enhancing operational efficiency.
  • Core Hydraulic and Mechanical Components
  • At the heart of the assembly lies the Brake Master Cylinder (Δp=0.3), calibrated to provide consistent braking force with minimal pedal effort, thanks to its precise 0.3 bar differential pressure. The Combination Pedal with Foam Seal integrates braking and throttle functions into a single unit, while the foam seal protects internal components from dust, moisture, and debris. Supporting these functions are the Elastic Element NG6, Circlip NG6, and Nut Holder NG6, which ensure smooth pedal movement, secure fastenings, and vibration dampening for enhanced operator control.
  • Precision Fasteners and Sealing Solutions
  • The assembly incorporates high-quality fasteners and sealing components to maintain integrity under extreme conditions. Hexagonal Flange Face Nuts M8 provide secure mounting for critical components, while Plug M10X1 and Plug NG8-M16×1.5 seal hydraulic ports to prevent leaks. The Elastomer Clamp (2819764002731) ensures tight connections in fluid systems, and the Split Retaining Ring and Spring Holder maintain proper tension in moving parts, minimizing wear and extending component life.
  • Ergonomic Design and Operator Comfort
  • Operator comfort is prioritized through components like the Pedal Rubber Cover, which reduces fatigue during extended use, and the Throttle Pedal Assembly, engineered for smooth, responsive acceleration control. The Needle Roller Bearing without Inner Ring (2819340100441) and Arbor enable low-friction movement in pivot points, while the Tappet and Pressure Spring provide precise feedback for intuitive pedal modulation. The Brake Light Switch ensures safety by activating warning signals immediately upon braking.
  • Integrated Clutch and Lubrication Systems
  • The Clutch Operating Part (C7H new) offers enhanced performance with improved engagement and disengagement, reducing operator effort and enhancing drivetrain protection. Multi-function Grease is applied throughout the assembly to minimize friction in moving parts, extending service intervals and reducing maintenance costs. The Hexagonal Head Bolt and Hexagonal Head Flat Head Slotted Screw provide secure, corrosion-resistant fastening for all components, ensuring long-term reliability in harsh environments.
  • Conclusion: Advanced Control for Heavy Machinery
  • The XCMG Combination Pedal Manipulator Assembly with 0.3 bar Differential Pressure and 0150 Bracket represents the pinnacle of integrated control systems for heavy machinery. By combining precision hydraulic components, robust fasteners, and ergonomic design, XCMG delivers a solution that enhances operator safety, reduces fatigue, and improves overall equipment productivity. Ideal for demanding applications where reliability and performance are critical, this assembly sets a new standard for control systems in the construction and industrial sectors.

Product Parameters of Sitrak Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)

752-48200-6383 Combination Pedal Manipulator Assembly (Differential Pressure 0.3bar/0150 Bracket)
Serial No. Drawing No.  Name Quantity
1 712-48220-5158 Combination pedal with foam seal 1
2 WG9000361001 Elastic element NG6 2
3 WG9000361002 Circlip NG6 2
4 WG9000361003 Nut holder NG6 2
5 WG9719360005 Brake master cylinder (Δp=0.3) 1
6 WG9000361010 Plug M10X1 2
7 WG9000361011 Plug NG8-M16×1.5 2
8 ZQ32008 Hexagonal flange face nut M8 4
9 810W48235-5078 Brake pedal assembly 1
10 WG9123360051 Needle roller bearing without inner ring (2819340100441) 2
11 710W48210-0040 Arbor 1
12 711W48240-0403 Tappet 1
13 AZ9123230222 Split retaining ring 2
14 810-97602-0908 Pressure spring 1
15 810W48220-0159 Spring holder 1
16 WG9123230226 Pedal rubber cover 1
17 Q150B0830 Hexagonal head bolt 1
18 WG9123360067 Plug ( 2819602003691) 1
19 WG9123360054 Elastomer clamp (2819764002731) 1
20 811W25970-6103 Throttle pedal assembly 1
21 MQ6-09089-0017 Hexagonal head flat head slotted screw 4
22 811W25503-0001 Brake light switch 1
23 09150010009 Multi-function grease 5
24 AZ9925230081 Clutch operating part (C7H new) 1
AZ9925230081 Clutch maneuvering part (C7H new)
Serial No. Drawing No.  Name Quantity
1 811W25503-0003 Clutch switch 1
2 AZ9123230050 Threaded pin 1
3 AZ9719230232 Return spring 1
4 MQ6W56639-0017 Seal 1
5 Q150B0835 Hexagon head bolt 2
6 Q218B0610 Hexagon socket head screw 2
7 Q33210 All-metal hexagonal locknut type 2 1
8 Q340B08 Hexagonal nut type 1 2
9 Q40308 Spring washer 2
10 Q41808 Wave spring washer 2
11 Q43680 Split retaining ring 1
12 WG9123230053 Needle bearing without inner ring 1
13 WG9123230226 Pedal rubber cover 1
14 WG9123360051 Needle bearing without inner ring (2819340100441) 2
15 WG9123360054 Elastic ferrule (2819764002731) 1
16 WG9160230092 End feedthrough fitting body 1
17 WG9719230231 Spring holder 1
18 WG9925230116 Limit bolt 2
19 WG9925230825 Clutch pedal assembly 1
20 WG9925230830 Clutch master cylinder push rod 1
21 WG9925230840 Clutch master cylinder and reservoir assembly 1
22 WG9925230850 Gasket welded assembly 1


Related Sitrak Spare Parts
