Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)

Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)
Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)
Download Catalog
Get Quotation

What is the Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)

  • Introduction to XCMG Brake System Energy Supply Unit
  • The XCMG Brake System Energy Supply Unit, specifically designed for the WP10.5H Engine Section, is a critical component engineered to deliver reliable compressed air for heavy machinery braking systems. This unit ensures optimal brake performance by maintaining consistent air pressure, even under extreme operational conditions. With a focus on durability, efficiency, and seamless integration, the system combines high-grade materials and precision engineering to meet the rigorous demands of construction, mining, and industrial applications.
  • Core Components for Reliable Air Supply
  • At the heart of the system lies the Air Compressor/Hose (National 6), compliant with the latest emission standards and designed to generate compressed air efficiently. The Pipe 16 Assembly and Bellows/Straight components form a robust pipeline network, ensuring smooth air flow from the compressor to the braking system. These components are reinforced with Hexagonal Flange Face Bolts M14*1.5 and Hexagonal Flange Face Nuts M6, providing secure connections that resist vibration and pressure fluctuations.
  • Mounting and Structural Support
  • The Bracket and Coil Hose Bracket (Fan Lower Crossbeam) offer stable mounting points for the system, ensuring proper alignment and reducing stress on hoses and pipes. The use of Hexagonal Flange Face Bolts M10 and Hexagonal Flange Face Nuts M10 ensures robust fastening, while the Large Washer distributes load evenly, preventing damage to mounting surfaces. The Three Hose Clamp (Φ 15) and Single Hose Clamp (φ15) secure hoses firmly, minimizing the risk of leaks and ensuring consistent air pressure delivery.
  • High-Performance Hoses and Fittings
  • The system features premium-grade hoses designed for durability and flexibility. The Rubber Hose (Inner Diameter φ25/470mm) and Rubber Hose with Braided Layer offer excellent resistance to abrasion, heat, and pressure, ensuring long service life even in harsh environments. The Tube Body with Straight-Through Fitting provides a seamless connection between components, while the Hose Clamp and Hexagonal Flange Face Bolts M6 ensure leak-proof joints, maintaining system efficiency.
  • Engineering Excellence for Heavy-Duty Applications
  • Every component of the XCMG Brake System Energy Supply Unit is rigorously tested to meet XCMG’s high standards for performance and reliability. The integration of National 6-compliant technology reduces environmental impact while enhancing operational efficiency. The use of flange face fasteners and precision-engineered brackets ensures easy installation and maintenance, minimizing downtime and reducing total cost of ownership. This makes the unit an ideal choice for heavy machinery manufacturers and operators seeking dependable braking solutions.
  • Conclusion: Trusted Energy Supply for Critical Braking Systems
  • The XCMG Brake System Energy Supply Unit (WP10.5H/Engine Section) delivers unmatched performance, durability, and compatibility for heavy machinery. By combining advanced air compression technology with robust structural components, XCMG ensures that braking systems operate safely and efficiently in the most demanding conditions. Trust XCMG’s expertise to power your equipment’s critical functions with precision-engineered solutions.

Product Parameters of Sitrak Brake System Energy Supply Unit (Wp10.5h/Engine Section)

711-#03X0-0237 Brake System Energy Supply Unit (Wp10.5h/Engine Section)
Serial No. Drawing No.  Name Quantity
1 WG9718360834 Brake system energy supply unit (WP10.5H/engine part) Pipe 16 assembly Air compressor/hose (National 6) 1
2 WG9318360023 Bracket 1
3 ZQ1851435TF6 Hexagonal flange face bolt M14*1.5 1
4 WG9000365401 Single hose clamp (φ15) 1
5 ZQ32006 Hexagonal flange face nut M6 1
5 ZQ32006 Hexagonal flange face nut M6 8
6 WG9718360835 Pipe 16 assembly Bellows/straight 1
7 712W51715-0136 Coil hose bracket (fan lower crossbeam) 1
8 ZQ1841030 Hexagonal flange face bolt M10 2
9 ZQ32010T13F6 Hexagonal flange face nut M10 2
10 WG9738470315 Three hose clamp (Φ 15) 8
11 ZQ1840645 Hexagonal flange face bolts 8
12 Q80316 Tube body with straight-through fitting 1
13 WG9100360237 Rubber hose (inner diameter φ25/470mm) 1
14 190003989304 Hose clamp 2
15 Q40206 Large washer 1
16 ZQ1840620 Hexagonal flange face bolts M6 1
17 812W54059-0007 Rubber hose with braided layer 1
