What is the Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • The Sitrak C7 Mid – Width Body Extended Cab Toolbox, with the option of a 1000w power supply, is a remarkable addition to the vehicle, offering both functionality and durability. This toolbox is designed to meet the diverse needs of users, providing a secure and organized storage space for various tools and equipment.
  • The core components of this toolbox include the Right Toolbox Assembly and the C7 Medium Wide Body Extended Cab Left Toolbox (1000W Inverter). The right toolbox assembly is precisely engineered to fit seamlessly on the right side of the vehicle, while the left toolbox, equipped with a 1000W inverter, provides the convenience of powering electrical tools when needed.

  • Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • A variety of fasteners are used to ensure the stability and integrity of the toolbox. Hexagon head bolts are employed in multiple locations. They are paired with large washers to distribute the load evenly and prevent damage to the toolbox surface. Blind Rivet Nut M8 is another important fastening element. These blind rivet nuts are used to create a strong and reliable connection, especially in areas where traditional nuts and bolts may not be suitable.
  • The Toolbox side cover assembly is an essential part of the toolbox. It comes with a Tool box side cover sealing strip, which effectively prevents dust, water, and debris from entering the toolbox, keeping the contents clean and dry. The Gas spring assembly (upper M6 lower M8) is used to support the opening and closing of the toolbox side cover, providing smooth and effortless operation.

  • Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • Screw type ball pins for automobile are used in the toolbox for a more secure and flexible connection. Blind Rivet Nuts are also used in different parts of the assembly to enhance the overall strength. The Ball Hexagonal Bolt(M8X13)/85953020001, along with flat washers, ensures a tight and stable fit.
  • Hinges are installed to allow the toolbox side cover to open and close smoothly. Pull Tape is used to provide a convenient way to open the toolbox, and large washers are used in combination with other fasteners to reinforce the connection. Clips and plugs like Plug/85960020008 are used to secure various components and prevent them from coming loose.

  • Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • The Lock assembly (mask, tool box) is crucial for the security of the toolbox. It includes the Left Locking Pin Assembly and the Right locking pin assembly (symmetrical to left piece), which ensure that the toolbox remains locked and the contents are safe. A Bracket is used to support and position different parts of the toolbox.
  • The Opening handle assembly provides an easy – to – use interface for opening the toolbox. Cross recessed pan head screws are used throughout the assembly, often paired with cotter rings, sleeves, and different types of washers. For example, Cross recessed pan head screws and flat washers assemblies, Cross recessed pan head screws with spring washers and large washers (Ref. Q2140620), and Cross recessed pan head screw spring washers and large washers assemblies (Ref. Q2140620) are used to ensure a tight and stable connection.

  • Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

  • Toolbox Protector I and Toolbox Protector II are added to protect the toolbox from scratches and damage. Rubber end caps are used to provide a soft and protective finish, reducing the risk of damage to the toolbox and the vehicle.
  • Finally, the Right tool box wire pull assembly (narrow body) and Left tool box puller assembly (narrow body) are designed to provide additional functionality, making it easier to access and organize the contents of the toolbox. In summary, the Sitrak C7 Mid – Width Body Extended Cab Toolbox is a well – designed and reliable storage solution for vehicles, with the added advantage of an optional 1000w power supply.

Product Parameters of Sitrak C7 Mid-Width Body Extended Cab Toolbox (Optional 1000w Power Supply)

712-#0520-0007 C7 mid-width body extended cab toolbox (optional 1000W power supply)
No. Part Number Part Name English  Quantity
1 712W66912-6100 Right Toolbox Assembly 1
2 712W66912-6209 C7 Medium Wide Body Extended Cab Left Toolbox (1000W Inverter) 1
3 Q150B0820F31 Hexagon head bolts 8
4 Q40208F31 Large Washer 8
4 Q40208F31 Large Washers 4
5 MQ6W13169-0020 Blind Rivet Nut M8 8
6 MQ6W13169-0021 Blind rivet nut M8 4
7 Q150B0830F31 Hexagon head bolts 4
8 810W66912-5288 Toolbox side cover assembly 2
9 810W66912-0228 Tool box side cover sealing strip 2
10 810W97006-0033 Gas spring assembly (upper M6 lower M8) 2
11 Q74506 Screw type ball pins for automobile 2
12 MQ6W13169-0022 Blind Rivet Nuts 2
13 AZ1635770042 Ball Hexagonal Bolt(M8X13)/85953020001 2
14 Q40106F31 Flat Washer 2
15 810W97201-0332 Hinges 4
16 810-96805-0001 Pull Tape 2
19 Q40206F31 Large washers 8
20 810W96002-0554 Clip 8
21 AZ1608430011 Plug/85960020008 12
22 810W97122-0028 Lock assembly (mask, tool box) 2
23 810W97122-6113 Left Locking Pin Assembly 1
24 810W97122-6112 Right locking pin assembly (symmetrical to left piece) 1
25 810W97122-0031 Bracket 2
26 812W66912-6207 Opening handle assembly 2
27 Q2140520F31 Cross recessed pan head screws 2
28 Q43660F31 Cotter ring 2
29 810W96001-0527 Sleeve 2
30 710W66912-6110 Toolbox Protector I 1
31 710W66912-6111 Toolbox Protector II 1
32 810W96001-0424 Rubber end caps 4
33 Q2300616F31 Cross recessed pan head screws and flat washers assemblies 2
34 WG1642930620 Cross recessed pan head screws with spring washers and large washers (Ref. Q2140620) 16
34 WG1642930620 Cross recessed pan head screw spring washers and large washers assemblies (Ref. Q2140620) 4
35 Q2140610F31 Cross recessed pan head screws 4
36 812W95501-0234 Right tool box wire pull assembly (narrow body) 1
37 812W95501-0235 Left tool box puller assembly (narrow body) 1
