Sitrak C7 Dashboard Assembly (Narrow Body - Nano-Quad)

Sitrak C7 Dashboard Assembly (Narrow Body - Nano-Quad)
Sitrak C7 Dashboard Assembly (Narrow Body - Nano-Quad)
Download Catalog
Get Quotation

What is the Sitrak C7 Dashboard Assembly (Narrow Body - Nano-Quad)

  • The Sitrak C7 Dashboard Assembly (Narrow Body – Nano – Quad) is a comprehensive and intricately designed component that combines functionality and aesthetics to enhance the driving experience.
  • Key Components
  • Instrument Panel Assemblies: It includes the Instrument Panel Left Assembly (Narrow Body – Square Position) and Instrument Panel Right Assembly – Narrow Body, which house various gauges and indicators to provide the driver with essential information about the vehicle’s status. The Instrument cover assembly protects the instruments from dust and damage.
  • Fasteners and Hardware: Multiple sets of Cross recessed pan head tapping screws and flat washers assemblies are used throughout the dashboard assembly for secure attachment. There are also Hexagon head bolts, spring washers and flat washers assemblies, Cross recessed pan head screws, flat washers, spring washers, and self – tapping screws that play crucial roles in holding different parts together.
  • Switch and Interface Components: The Switch Panel Assembly allows the driver to control various functions of the vehicle, while the Diagnostic Interface Cover Pad protects the diagnostic interface.
  • Storage and Utility Components: The Narrow Body Long Storage Box with its Long Storage Box Pad provides convenient storage space for small items. The Ashtray Assembly caters to smokers.
  • Interior Trim and Guards: Components like the Left Side End Panel Assembly, Right Side End Panel Assembly, Trim Cover, and various guard assemblies such as the Lower Left Guard Assembly – Narrow Body, Center Shield Assembly, and Right Lower Shield Assembly – Narrow Body enhance the interior’s visual appeal and protect the dashboard.
  • Ventilation Components: The Left Front Defroster Grille Assembly and Right Front Defroster Grille Assembly (Narrow Body) help in defrosting the windshield. There are also numerous ducts for air circulation, including the Driver’s Side Exterior Door Duct – Narrow Body, Driver’s Side Interior Door Duct, and various foot ducts.
  • Mounting Brackets: A variety of mounting brackets such as the Passenger Side Instrument Panel Bracket, Driver’s Side Instrument Panel Bracket, Driver’s Side Upper Mounting Bracket (Narrow Body), and Dashboard Rear Mounting Bracket Assembly (Narrow Body) ensure the proper installation and stability of the dashboard.
  • Other Components: The Front Cabin Handle provides easy access to the front cabin. The Plastic Push Pin and Circlip are used for specific attachment purposes. The A – Pillar Boarding Armrest and B – Pillar Armrest – Narrow offer comfort to the driver and passengers. The Center Air Outlet Assembly and Foot Outlet ensure proper air distribution. The Clutch Cover – Narrow and Brake and Throttle Cover – Narrow Body protect the clutch, brake, and throttle areas. The Foam Cushion adds comfort and reduces noise and vibration.
  • In conclusion, the Sitrak C7 Dashboard Assembly (Narrow Body – Nano – Quad) is a well – crafted and multi – functional component that meets the diverse needs of drivers and passengers in terms of functionality, comfort, and aesthetics.

Product Parameters of Sitrak C7 Dashboard Assembly (Narrow Body - Nano-Quad)

812-#0511-0021  C7 Dashboard Assembly (Narrow Body – Nano-Quad)
No. Part Number Part Name English  Quantity
1 812W61701-6325 Instrument Panel Left Assembly (Narrow Body – Square Position) 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 3
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 8
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 5
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 5
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 7
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 6
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 8
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 4
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 4
2 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
3 812W61701-0197 Front Cabin Handle 1
4 812W61701-0236 Instrument cover assembly 1
5 812W61701-0242 Switch Panel Assembly 1
6 812W61701-0250 Diagnostic Interface Cover Pad 1
7 812W61701-6205 Instrument Panel Right Assembly-Narrow Body 1
8 812W61701-0153 Left Side End Panel Assembly 1
9 812W61701-0154 Right Side End Panel Assembly 1
10 812W61701-0253 Narrow Body Long Storage Box 1
11 812W61701-8529 Long Storage Box Pad 1
12 812W61701-6271 Sliding Block 2
13 812W61700-8352 Ashtray Assembly 1
14 812W61701-6295 Instrument Panel Center Upper Skeleton Assembly 1
15 812W61470-0025 Lower Left Guard Assembly-Narrow Body 1
16 812W61701-0195 Plastic Push Pin 1
16 812W61701-0195 Plastic Push Pin 4
17 812W61470-0032 Center Shield Assembly 1
18 812W61942-6004 Center Lower Shield Assembly-Narrow Body 1
19 812W61470-0015 Right Lower Shield Assembly-Narrow Body 1
20 812W61950-0301 Right center shield assembly (narrow body) 1
21 812W61940-0122 Trim Cover 1
22 812W61950-0273 Left Front Defroster Grille Assembly 1
23 812W61950-0275 Right Front Defroster Grille Assembly (Narrow Body) 1
24 812W96020-0432 Circlip 6
25 812W61950-0361 Driver’s Side Exterior Door Duct – Narrow Body 1
26 812W61950-0347 Driver’s Side Interior Door Duct 1
27 812W61950-0280 Passenger Side Interior Door Duct – Narrow Body 1
28 812W61950-0365 Driver’s Side Exterior Side Duct – Narrow Body 1
29 812W61950-0284 Driver’s Side Interior Side Duct 1
30 812W61950-0285 Passenger Side Interior Side Duct – Narrow Body 1
31 812W61950-0287 Left interior footwell duct 1
32 812W61950-0288 Right side interior foot duct 1
33 812W61950-0317 Driver’s side center foot duct-narrow body 1
34 812W61950-0318 Driver’s Side Exterior Foot Duct Assembly-Narrow Body 1
35 812W61950-0310 Passenger Side Exterior Foot Duct Assembly 1
36 812W61950-6061 Center Air Outlet Assembly 1
37 812W61950-0342 Foot Outlet 1
38 812W61430-0057 Clutch Cover-Narrow 1
39 812W61430-0059 Brake and Throttle Cover-Narrow Body 1
40 812W62430-0116 Passenger Side Instrument Panel Bracket 1
41 812W62430-0030 Driver’s Side Instrument Panel Bracket 1
42 812W61701-0283 Driver’s Side Upper Mounting Bracket (Narrow Body) 1
43 812W62430-0065 Driver’s side lower mounting bracket assembly (narrow body) 1
44 812W62430-0041 Driver’s Side Wiring Harness Access-Narrow Body 1
45 812W62430-0032 Front Dashboard Mounting Bracket (Narrow Body) 1
46 812W62430-0034 Center Harness Channel Assembly 1
47 812W61701-0271 Left Center Guard Assembly 1
48 812W96002-0468 Plug 1
49 812W97001-5095 A-Pillar Boarding Armrest 1
50 812W97001-5091 A-Pillar Armrest-Right 1
51 812W97001-5096 B-Pillar Armrest-Narrow 1
52 812W97001-5092 B-pillar handrail-narrow body-right 1
53 Q2204825 Cross recessed pan head tapping screws and flat washers assemblies 1
53 Q1460825F31 Hexagon head bolts, spring washers and flat washers assemblies 2
53 Q1460825F31 Hexagon head bolts, spring washers and flat washers assemblies 2
53 Q1460825F31 Hexagon head bolts, spring washers and flat washers assemblies 2
53 Q1460825F31 Hexagon head bolts, spring washers and flat washers assemblies 2
54 Q2140820F31 Cross recessed pan head screws 3
54 Q2140820F31 Cross recessed pan head screws 3
54 Q2140820F31 Cross recessed pan head screws 3
54 Q2140820F31 Cross recessed pan head screws 3
55 Q40108F31 Flat washers 3
55 Q40108F31 Flat washers 3
55 Q40108F31 Flat washers 3
55 Q40108F31 Flat Washers 3
56 Q40310F31 Spring Washers 1
56 Q40310F31 Spring Washers 1
56 Q40310F31 Spring Washers 3
56 Q40310F31 Spring Washers 3
57 Q2204219F31 Self-tapping screws 1
57 Q2204219F31 Self-Tapping Screws 1
58 812W62701-6217 Dashboard Rear Mounting Bracket Assembly (Narrow Body) 1
59 812W61441-0001 Foam Cushion 2
