Sitrak 400L Aluminum Tank Fuel System (G7 6×4 K36 8X4 K25 MC11 MC13 300 Frame 700×700 Fuel Tank Right Side Straight Side Installation Heated Suction and Return Oil)

Sitrak 400L Aluminum Tank Fuel System (G7 6×4 K36 8X4 K25 MC11 MC13 300 Frame 700×700 Fuel Tank Right Side Straight Side Installation Heated Suction and Return Oil)
Sitrak 400L Aluminum Tank Fuel System (G7 6×4 K36 8X4 K25 MC11 MC13 300 Frame 700×700 Fuel Tank Right Side Straight Side Installation Heated Suction and Return Oil)
Download Catalog
Get Quotation

What is the Sitrak 400L Aluminum Tank Fuel System (G7 6×4 K36 8X4 K25 MC11 MC13 300 Frame 700×700 Fuel Tank Right Side Straight Side Installation Heated Suction and Return Oil)

  • Sitrak 400L Aluminum Tank Fuel System: High-Efficiency Fuel Management for Heavy-Duty Vehicles​
  • Engineered for Sitrak G7 models in 6×4/K36 and 8X4/K25 configurations, compatible with MC11/MC13 engines and 300-frame chassis, the 400L Aluminum Tank Fuel System combines durability, precision, and innovative heating technology to deliver reliable fuel storage and delivery. With a 700×700mm right-side straight-mount aluminum tank and heated suction/return oil capabilities, this system is optimized for extreme conditions, ensuring consistent performance in cold climates and heavy-duty operations.​
  • Core Components for Reliable Fuel Storage​
  • The 400L aluminum alloy square oil tank body(700×700) is the foundation of the system, crafted from lightweight yet robust aluminum alloy to resist corrosion and withstand impact. Its 700×700mm dimensions offer ample fuel capacity while fitting seamlessly into the vehicle’s frame. The Oil level sensor (700×700 oil tank/quick-insertion type/heating suction return oil) provides real-time fuel level monitoring with a quick-insertion design for easy maintenance, integrated with heating functionality to prevent fuel gelling in low temperatures, ensuring smooth suction and return oil flow.​
  • Secure Mounting and Structural Stability​
  • The fuel tank is securely anchored using a Fuel tank bracket and Plate, fastened with Hexagonal flange bolts with teeth M14*1.5 and Hexagonal flange nut with teeth M14*1.5. The toothed design of these fasteners ensures vibration-resistant locking, critical for maintaining stability during rough terrain operation. The Tension belt and cushion belt (big square fuel tank/TPV/70 inner width) and Fuel tank belt further stabilize the tank, supported by Tension pin(Tension belt), Flat Washers, and Cotter pins to prevent lateral movement. A Bracket gasket (large square tank/TPV) provides a tight seal between the bracket and tank, reducing noise and protecting against moisture.​
  • Precision Fuel Line System​
  • The fuel delivery network features Polyamide tube colorless transparent 16*2 PA11W D74324—used three times for consistent fuel flow—known for its chemical resistance and clarity for easy leak detection. These tubes connect via Joint(M16x1.5/Long), Fitting(M16x1.5/short), and Pipe connector(16X2 oil pipe/straight), all equipped with Composite sealing washer 16 QZZ21052 to ensure leak-proof, high-pressure connections. Rubber protection sleeve 80x45x8 shields vulnerable tube sections from abrasion, while Plastic Clamping Tape and Plastic clamping band secure routing, minimizing vibration damage.​
  • Heating Technology for Cold Weather Performance​
  • The system’s heated suction and return oil design prevents fuel viscosity issues in freezing conditions, maintaining optimal flow to the engine. The quick-insertion oil level sensor integrates seamlessly with the heating mechanism, ensuring reliable operation even at sub-zero temperatures. Hexagon socket head cap screws and Pins secure auxiliary components, with All-metal hexagonal flange face lock nuts providing additional anti-loosening protection in high-stress points.​​
  • Model Specificity: Clearly lists compatible vehicle configurations (G7/6×4/K36/8X4/K25) and engine types (MC11/MC13) for precise keyword targeting.​
  • Technical Details: Highlights material (aluminum alloy), dimensions (700×700), and heating technology to address user needs for durability and cold-weather performance.​
  • Component Integration: Emphasizes secure mounting (tension belts, toothed bolts) and leak-proof connections (composite washers, polyamide tubes) to build trust in reliability.​
  • In summary, the Sitrak 400L Aluminum Tank Fuel System is a premium solution for heavy-duty vehicles, combining a robust aluminum tank, advanced heating capabilities, and a precision-engineered fuel line system. Its straight-side installation, secure mounting, and cold-weather resilience make it ideal for fleets and operators requiring consistent fuel management in the most demanding environments. Trust in this system to deliver efficiency, longevity, and peace of mind, mile after mile.

Product Parameters of Sitrak 400L Aluminum Tank Fuel System (G7 6×4 K36 8X4 K25 MC11 MC13 300 Frame 700×700 Fuel Tank Right Side Straight Side Installation Heated Suction and Return Oil)

YC96255500087 400L Aluminum Tank Fuel System (G7/6×4/K36/8X4/K25/MC11/MC13/300 Frame/700×700/Fuel Tank Right Side/Straight Side Installation/Heated Suction and Return Oil)
Serial No.  Drawing No. Name Quantity
1 WG9925550001 400L aluminum alloy square oil tank body(700×700) 1
2 WG9925550221 Oil level sensor (700×700 oil tank/quick-insertion type/heating suction return oil) 1
3 AZ9003090016 Composite sealing washer 16 QZZ21052 2
4 WG9725550165 Joint(M16x1.5/Long) 1
5 WG9725550166 Fitting(M16x1.5/short) 1
6 WG9725550206 Pipe connector(16X2 oil pipe/straight) 2
7 WG9925550060 Fuel tank bracket 2
8 WG9925550017 Plate 2
9 ZQ1811445TF6 Hexagonal flange bolts with teeth M14*1.5 2
10 ZQ1811440TF6 Hexagonal flange bolts with teeth M14*1.5 4
11 ZQ32514T13F6 Hexagonal flange nut with teeth M14*1.5 6
12 WG9925551062 Tension belt and cushion belt (big square fuel tank/TPV/70 inner width) 2
13 WG9925550061 Fuel tank belt 2
14 810W97461-0014 Tension pin(Tension belt) 2
15 WG9925550064 Tension pin 2
16 WG9925550365 Hexagon socket head cap screws 2
17 Q5101675 Pins 2
18 Q40116 Flat Washers 2
19 Q5004025 Cotter pins 2
20 WG9925551063 Bracket gasket (large square tank/TPV) 2
21 AZ9725550121 Polyamide tube colorless transparent 16*2 PA11W D74324 220
21 AZ9725550121 Polyamide tube colorless transparent 16*2 PA11W D74324 75
21 AZ9725550121 Polyamide tube colorless transparent 16*2 PA11W D74324 200
22 AZ9112550121 Polyamide tube 50
23 190003171697 Plastic Clamping Tape 6
23 190003171697 Plastic clamping band 6
24 WG9100360027 Rubber protection sleeve 80x45x8 2
25 811W98181-0001 Pipe connector (16×2 oil pipe) 2
