Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)

Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)
Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)
Download Catalog
Get Quotation

What is the Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)

  • The Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat) is a revolutionary component designed to enhance the performance and durability of the gearbox in Sitrak vehicles. With its innovative design and high – quality materials, this support system offers a reliable solution for reducing vibrations and ensuring smooth operation of the gearbox.
  • The Connection plate serves as the foundation for the entire support system. It is precisely engineered to provide a stable and secure connection between the gearbox and the vehicle’s frame. The connection plate is made from high – strength steel, which can withstand the significant forces and stresses generated during vehicle operation.
  • To effectively absorb vibrations and shocks, the support system features a Rubber shock absorbing block. This block is made from a special rubber compound with excellent elasticity and damping properties. It helps to isolate the gearbox from the vehicle’s frame, reducing the transmission of vibrations and noise, and improving the overall driving comfort.
  • The Pipe Bend with a diameter of 40 is a key part of the new structure. It is carefully designed to fit the specific requirements of the G7h model. The pipe bend is not only strong but also flexible enough to accommodate the movement of the gearbox during operation. Pipe clamps are used to secure the pipe bend in place, ensuring its stability and preventing any potential loosening.
  • The Arc Pressure Plate is used in combination with other components to provide additional support and stability. It is tightened using Hexagonal flange bolts M10 and Hexagonal flange face bolts with teeth M16*1.5. The toothed design of the M16*1.5 bolts provides enhanced locking performance, preventing the bolts from loosening due to vibrations.
  • Hexagon head bolts and Self – locking nuts are used throughout the support system for fastening various components. Flat washers are placed between the bolts and the components to distribute the clamping force evenly and prevent damage to the surfaces. All – metal hexagonal flange face lock nuts are also used to provide a mroe secure locking mechanism, especially in critical areas.
  • The Spacer Plate is used to adjust the distance between different components, ensuring proper alignment and clearance. It helps to optimize the performance of the support system and extends the service life of the gearbox.
  • In summary, the Sitrak New Structure Bend Tube Gearbox Auxiliary Support is a well – thought – out and reliable solution for Sitrak G7h vehicles. Its combination of high – quality components, such as the connection plate, rubber shock absorbing block, pipe bend, and various fasteners, ensures effective vibration reduction, enhanced stability, and improved gearbox performance. Whether on rough roads or during high – speed driving, this support system can provide the necessary support and protection for the gearbox, making it an essential part of the vehicle.

Product Parameters of Sitrak New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)

AC93255900661 New Structure Bend Tube Gearbox Auxiliary Support (Bend Tube Diameter 40/G7h/New Rubber Seat)
Serial No.  Drawing No. Name Quantity
1 WG9325590221 Connection plate 1
2 WG9325590222 Rubber shock absorbing block 1
3 WG9325590224 Pipe Bend 1
4 WG9325590220 Pipe clamps 2
5 WG9325590223 Arc Pressure Plate 1
6 ZQ1841025 Hexagonal flange bolts M10 4
7 ZQ1811630TF6 Hexagonal flange face bolts with teeth M16*1.5 2
8 Q151B1685 Hexagon head bolts 2
9 Q33216 Self-locking nuts 2
10 Q40116 Flat washers 2
10 Q40116 Flat washers 2
11 Q33010T13F3 All-metal hexagonal flange face lock nuts 4
12 WG9725590309 Spacer Plate 2
AC99255500134 Fuel Gas Heater Oil System (Ebeh/K48/T7-8×4)
Serial No.  Drawing No. Name Quantity
1 WG9715115029 Oil Pump 1
2 WG9925550811 Oil pump bracket (right side forward) 1
3 WG9715115015 Oil Pump Fixing Clamp 1
4 ZQ1811445TF6 Hexagonal flange bolts with teeth M14*1.5 2
5 ZQ32514T13F6 Hexagonal flange nut M14*1.5 2
6 ZQ1800625 Hexagonal flange bolts with teeth M6 1
7 ZQ32406 Hexagonal flange with toothed nut M6 1
8 WG9715115024 Transition hose (11×3) (tank to pump) 2
9 WG9715115025 Clamps (tank to pump hose) 4
10 WG9715115017 Polyamide hose colorless transparent 6*1 PA11W D74324 (with corrugated protective sleeve) 150
11 WG9715115023 Transition hose (9.5×3) (oil pump to heater) 3
12 WG9715115026 Clamp (oil pump to heater hose) 6
13 WG9715115018 Polyamide tube colorless transparent 4*1 PA11W D74324 (with corrugated protective sleeve) 520
14 WG9715115018 Polyamide tube Colorless transparent 4*1 PA11W D74324 (with corrugated protective sleeve) 300
