Shacman X6000 Windscreen Rinse System/Left

Shacman X6000 Windscreen Rinse System/Left
Shacman X6000 Windscreen Rinse System/Left
Download Catalog
Get Quotation

What is the Shacman X6000 Windscreen Rinse System/Left？

  • Shacman X6000 Left Windscreen Rinse System: Engineered for All-Weather Visibility​
  • Designed to maintain clear windshields in the harshest conditions, the Shacman X6000 Left Windscreen Rinse System integrates a high-torque Wiper motor, precision Wiper Linkage Assembly, and robust fluid delivery components—Water Container, Hoses, and Distributors—to deliver consistent cleaning performance, vibration resistance, and easy maintenance. Built for heavy-duty trucks and construction machinery, this system combines durable engineering with intelligent design, ensuring optimal driver safety and operational efficiency.​
  • Core Mechanical Components: Wiper System Precision​
  • The Wiper motor (12V DC, 25W output) serves as the system’s power hub, featuring a copper-wound armature that generates 8 N·m of torque—20% more than standard motors—to drive the Wiper Linkage Assembly at 45 cycles per minute (CPM) in high-speed modes. Mounted on a galvanized steel Wiper motor bracket (3mm thickness, yield strength ≥ 250 MPa), it is secured with Hex flange Bolts (grade 8.8, M8 x 20mm, torqued to 20–25 N·m), resisting 20G vibrations (ISO 16750-3 compliant) to prevent misalignment. A waterproof rubber cover (IP67-rated) shields the motor from water and dust, extending service life to 10,000+ operating hours.​
  • Wiper Blade & Arm Assembly: Adaptive Cleaning Performance​
  • The Main Wiper Arm Swf and Auxiliary Wiper Arm Swf (aluminum alloy 6061-T6, 2mm thickness) feature aero-dynamic profiles that reduce wind lift by 15% at 120 km/h, ensuring constant blade contact with the windshield. Fitted with Wiper Blades (natural rubber with graphite coating, shore hardness 65A), they conform to curved glass surfaces (radius: 500–800mm), delivering streak-free cleaning even at 60° angles. Wiper Arm covers (UV-stabilized ABS plastic) protect pivot points from debris, while quick-release adapters enable blade replacement in 30 seconds—ideal for roadside maintenance.​
  • Fluid Delivery System: Pressure-Guided Cleaning​
  • A 5L Water Container (HDPE plastic, -40°C to +85°C tolerance) is supported by a dual Water Container bracket (cold-rolled steel, zinc-nickel plated), secured with Hex Bolts (M6 x 14mm) and Big Washers (6mm-thick galvanized steel) to withstand 30N of pulling force. The container feeds fluid through a network of reinforced hoses:​
  • HoseⅠ (EPDM rubber with polyester braiding) connects to the Water Container motor (12V, 3.5L/min flow rate), while HoseⅡ/Ⅲ/Ⅳ (same material) route fluid to DistributorⅡ/Ⅲ/T, which split flow to 4 nozzles (spray angle: 120°), covering a 1.5m² windshield area.​
  • A Unilateralism valve prevents backflow, ensuring consistent pressure (80kPa) even when the container is 90% full, compliant with SAE J2805 for washer system performance.​
  • Mounting & Sealing: Vibration-Resistant Design​
  • Fastening components ensure secure installation:​
  • Hex flange Bolt- increase (M10 x 30mm, grade 10.9) anchors the motor bracket to the vehicle frame, paired with lock washers that maintain 95% clamping force after 100,000 vibration cycles.​
  • Hex Nut (DIN 934) and Big Washer combinations distribute load evenly across mounting surfaces, preventing indentation on the cab’s metal panels.​
  • Material Excellence & Environmental Resilience​
  • The system prioritizes durability through advanced materials:​
  • Corrosion Resistance: Steel brackets undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), ideal for coastal or winter fleets, while hose connectors feature FKM fluoroelastomer seals (IP65-rated) to resist oil and coolant exposure.​
  • Abrasion Resistance: Wiper blades include a Teflon-infused edge that reduces friction by 30%, extending service life to 500,000 wiping cycles—2x longer than generic blades.​
  • Temperature Performance: The water container’s anti-freeze additive compatibility (-35°C rating) and motor’s thermal cutoff (60°C activation) ensure functionality in arctic and desert climates.​
  • Compliance & Performance Benefits​
  • Key features enhance safety and operational efficiency:​
  • Regulatory Adherence: Meets UN ECE R43 windshield cleaning standards, with nozzle spray patterns achieving ±5% uniformity—critical for legal operation in global markets.​
  • Maintenance Ease: Modular design allows replacement of Hoses, Distributors, or Wiper Linkage Assembly in 90 minutes using standard tools, with color-coded fittings (blue for fluid lines, yellow for electrical) reducing installation errors.​
  • Cost Savings: Durable components and vibration-resistant fasteners lower maintenance costs by 30% compared to aftermarket systems, with a 5-year warranty on motor and linkage assembly.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Water Ingress Test: Maintains zero leakage when exposed to 60kPa water pressure (equivalent to high-pressure car washes), compliant with IEC 60529 IP65.​
  • Vibration Fatigue Test: After 500 hours of 10–2,000 Hz vibration, all fasteners and hoses remain secure, with no cracks in the wiper linkage detected via non-destructive testing (NDT).​
  • Wiper Performance Test: Cleans 99% of mud and dust from the windshield at 80 km/h, exceeding SAE J903 standards for commercial vehicle visibility systems.​
  • Conclusion: All-Weather Visibility Solution for Heavy-Duty Fleets​
  • The Shacman X6000 Left Windscreen Rinse System, featuring a high-torque Wiper motor, precision Linkage Assembly, and robust Fluid Delivery System, sets a benchmark for reliability and performance in commercial vehicle windshield maintenance. By combining durable materials, intelligent engineering, and SEO-optimized technical detail, Shacman ensures this system delivers uncompromising visibility—exemplifying the brand’s commitment to driver safety and fleet operational efficiency in the most challenging environments.​

Product Parameters of Shacman X6000 Windscreen Rinse System/Left

NO Part.No Name Quantity
1 DZ16231740031 Wiper motor 1
2 DZ16231740032 Wiper motor bracket 1
3 Q1840825 Hex flange Bolt 4
4 DZ16251740040 Wiper Linkage Assembly 1
5 DZ16251740110 Waterproof cover 2
6 DZ16231740012 Wiper Blade 2
7 DZ16251740011 Main Wiper Arm Swf 2
8 DZ16231740060 Wiper Arm cover 1
9 DZ16231740109 HoseⅣ 2
10 DZ14251740036 DistributorⅡ 1
11 DZ16231740105 HoseⅢ 1
12 DZ16231740106 DistributorⅢ/T 1
13 DZ16231740104 HoseⅡ 1
14 DZ16251740021 Auxiliary Wiper Arm Swf 1
15 Q1860820 Hex flange Bolt- increase 5
16 DZ16231740114 Water Container bracket 1
17 DZ16231740101 Water Container 1
18 DZ16231740107 Unilateralism valve 1
19 Q150B0835 Hex Bolt 3
20 Q402B08 Big Washer 3
21 Q32008 Hex Nut 2
22 DZ16231740116 Water Container bracket 1
23 DZ16231740102 Water Container motor 1
24 DZ16231740103 HoseⅠ 1
