Shacman X6000 Cab Air Condition

Shacman X6000 Cab Air Condition
Shacman X6000 Cab Air Condition
Download Catalog
Get Quotation

What is the Shacman X6000 Cab Air Condition？

  • Shacman X6000 Cab Air Condition: Efficient Cooling with Robust Mechanical Design​
  • Engineered to deliver reliable temperature control in extreme environments, the Shacman X6000 Cab Air Condition system integrates a modular framework of high-performance components—Control valve, Outer pipe, and precision fasteners—to ensure optimal refrigerant flow, vibration resistance, and long-term durability. Designed for the X6000 series, this system balances advanced cooling technology with rugged mechanical engineering, ideal for logistics, construction, and long-haul fleets.​
  • Core Climate Control Components: Fluid Management System​
  • The Control valve (aluminum alloy body, hardness ≥ 150 HB) serves as the system’s regulatory hub, adjusting refrigerant flow (max pressure: 25 bar) to maintain consistent cabin temperatures. Its electro-hydraulic design responds to cab sensors within 2 seconds, enabling rapid cooling (40°C to 25°C in 12 minutes) and preventing icing in low-temperature conditions. Paired with Outer pipe (PA66 polyamide, burst pressure ≥ 35 bar), which transports refrigerant between the compressor and condenser, the system ensures minimal pressure loss (≤0.5 bar) and resistance to chemical corrosion from road salts or engine oils.​
  • Mounting & Fastening: Secure, Vibration-Resistant Installation​
  • A network of Brackets and high-strength fasteners ensures stable integration with the cab’s structural framework:​
  • Brackets (6mm-thick high-strength steel, yield strength ≥ 500 MPa) support the condenser and evaporator units, featuring pre-drilled slots (tolerance: ±0.3mm) for precise alignment. Screws (grade 10.9, M8 x 25mm) and Washers (stainless steel, 14mm OD) secure the brackets to the cab, torqued to 20–25 N·m with Hex nuts (self-locking, DIN 980V) that resist 25G vibrations (ISO 16750-3 compliant), maintaining 95% clamping force after 100,000 cycle fatigue testing.​
  • The Outer pipe is anchored to the chassis using spring-loaded clamps and additional Brackets, minimizing resonance and preventing stress fractures during off-road operation.​
  • Material Excellence & Environmental Resilience​
  • Components are optimized for harsh commercial environments:​
  • Corrosion Protection: Steel brackets undergo a 50μm zinc-nickel plating (ASTM B117, 1,200 hours salt-spray resistance), while the Control valve features a PTFE-coated internal surface to resist refrigerant degradation.​
  • Temperature Tolerance: The Outer pipe maintains dimensional stability from -40°C to +150°C, with polyamide material retaining 85% of tensile strength in arctic cold and resisting thermal expansion in desert heat (coefficient ≤ 8×10⁻⁶/°C).​
  • Leak Resistance: All connections use O-ring seals (fluorocarbon rubber, shore hardness 75A) that create a hermetic seal (tested at 30 bar pressure), ensuring zero refrigerant loss over 10,000 hours of operation.​
  • Compliance & Performance Benefits​
  • Key features enhance operator comfort and system efficiency:​
  • Regulatory Adherence: Meets ISO 16750-4 for automotive air conditioning systems and SAE J2788 for refrigerant hose assemblies, ensuring global certification and safety.​
  • Energy Efficiency: The Control valve optimizes compressor load, reducing fuel consumption by 10% compared to conventional systems, with a variable-speed fan that adjusts airflow (300–600 m³/h) based on cab occupancy.​
  • Maintenance Ease: Modular design allows replacement of the Control valve or Outer pipe in 60 minutes using standard tools, with color-coded fasteners (blue for low-pressure lines, red for high-pressure components) to prevent installation errors.​
  • Testing & Reliability​
  • Rigorous validation ensures industry-leading performance:​
  • Vibration Fatigue Test: After 1,000 hours of 10–2,000 Hz vibration, all Brackets and fasteners remain secure, with no pipe cracks or valve malfunctions detected.​
  • Pressure Cycle Test: The Outer pipe survives 5,000 cycles of 0–30 bar pressure without leakage, exceeding SAE J1401 burst pressure standards.​
  • Thermal Shock Test: The system maintains full functionality after 1,500 cycles between -40°C and +85°C, confirming no material brittleness or seal degradation.​
  • Conclusion: Heavy-Duty Climate Control for Commercial Vehicle Cabs.​

Product Parameters of Shacman X6000 Cab Air Condition

NO Part.No Name Quantity
1 DZ16251847907 Bracket 1
2 Q401B06 Washer 7
3 Q340B06 Hex nut 6
4 DZ16251847118 Outer pipe 1
5 Q150B0635 Screw 1
6 DZ16251847201 Contro valve 1
7 DZ16251847906 Bracket 1
