What is the SANY TCGP-BASIC

  • The SANY TCGP-BASIC represents the fundamental torque converter assembly that forms the heart of SANY’s transmission system, engineered for exceptional power transfer efficiency and durability. This sophisticated assembly integrates numerous precision components including the IMPELLER and TURBINE which work in harmony to convert and multiply engine torque through hydraulic fluid dynamics. The system is secured with multiple fastening elements such as BOLT-SOCKETHEAD, BOLT-HEXHEAD, and BOLT-HEXSOCKET components, along with Washer and WASHER-HARD elements for vibration-resistant connections.
  • The SANY TCGP-BASIC incorporates advanced sealing technology through components like SEAL-O-RINGO, RING-SEAL, and RING-SEALMETAL that ensure perfect fluid containment. The assembly features critical bearing surfaces with BEARING-THRUST and RACE-BRGTHRUST components that manage axial loads, while the CARRIER-STATOR and STATOR-CONVERTER provide stationary reaction elements for torque multiplication. The SANY TCGP-BASIC also includes the HUB-IMPELLER and HUB-TURBINE for power transmission, along with DOWEL pins for precise alignment.
  • The clutch system within the SANY TCGP-BASIC consists of PISTON-CLUTCH, DISC-FRICTION, and PLATE-BACKING elements, while the freewheel mechanism employs CAM-FREEWHEEL, ROLLER-FREEWHEEL, and SPRING-FREEWHEEL components. Additional elements like RING-SNAP, RING-RETAINING, and RETAINER provide secure component retention, and the ADAPTER-DRIVE and COUPLINGAS ensure proper power transfer interfaces. The entire assembly is housed within the HOUSINGAS and includes PLATE-SIDE and PLATE-SPLINED components for structural integrity, with PLUG-LDSTOR providing access points for maintenance.
  • Every aspect of the SANY TCGP-BASIC demonstrates meticulous engineering precision, ensuring reliable performance and longevity in the most demanding operating conditions, reflecting SANY’s commitment to transmission excellence.

Parameters of SANY TCGP-BASIC

No. Part No. Description Qty
1 130202000093A272 RING-SNAP 3
2 130202000093A273 PLATE-SIDE 2
3 130202000093A274 ADAPTER-DRIVE 1
4 130202000093A275 SEAL-O-RINGO 1
5 130202000093A276 IMPELLER 1
6 130202000093A277 DOWEL 2
7 130202000093A278 RING-RETAINING 1
8 130202000093A279 HUB-IMPELLER 1
9 130202000093A280 WASHER-HARD 8
10 130202000093A281 BOLT-SOCKETHEAD 8
11 130202000093A282 RACE-BRGTHRUST 3
12 130202000093A283 BEARING-THRUST 2
13 130202000093A284 CARRIER-STATOR 1
14 130202000093A285 BEARING-THRUST 2
15 130202000093A286 STATOR-CONVERTER 1
16 130288000778A COUPLINGAS 1
17 130202000093A287 BOLT-HEXHEAD 20
18 130202000093A288 RING-SEALMETAL 1
19 130202000093A289 RETAINER 1
20 130202000093A290 SEAL-ORINGO 1
21 130202000093A291 PLUG-LDSTOR 1
22 130202000093A292 BOLT-HEXSOCKET 1
23 130202000093A293 BOLT 24
24 130202000093A038 Washer 24
25 130202000093A294 HOUSINGAS 1
26 130202000093A295 RING-SEAL 1
27 130202000093A296 PISTON-CLUTCH 1
28 130202000093A297 RING-SEAL 1
29 130202000093A298 SEAL-O-RINGO 3
30 130202000093A299 PLATE-SPLINED 1
31 130202000093A300 PLATE 2
32 130202000093A301 DISC-FRICTION 2
33 130202000093A302 PLATE-BACKING 1
34 130202000093A303 TURBINE 1
35 130202000093A304 HUB-TURBINE 1
36 130202000093A305 RACE-THRUST 1
37 130202000093A306 CAM-FREEWHEEL 1
38 130202000093A307 ROLLER-FREEWHEEL 11
39 130202000093A308 SPRING-FREEWHEEL 11
