Prevents water ingress, dust, and wind noise – The OEM LG1613714001 Rear Window Sealing Strip is a high‑quality EPDM rubber extrusion designed to create a perfect seal between the rear window glass and the cab frame on SINOTRUK HOWO, SHACMAN, and other heavy‑duty trucks. It eliminates leaks, reduces cabin noise, and protects interior electronics from moisture.
This sealing strip is manufactured from premium automotive‑grade EPDM (ethylene propylene diene monomer) rubber, offering outstanding resistance to ozone, UV radiation, extreme temperatures, and weathering. For guaranteed fitment and long‑lasting sealing performance, always choose genuine Sinotruk Homan parts.
The LG1613714001 Rear Window Sealing Strip features a multi‑chamber profile with an integrated locking lip and hollow sealing bulb. It compresses evenly to accommodate glass curvature and cab tolerances, providing a water‑tight and dust‑proof barrier. Its flexible design also dampens vibration, preventing the glass from rattling.
The LG1613714001 Rear Window Sealing Strip is designed with a three‑zone profile: a rigid barbed anchor leg that locks into the cab frame channel, a flexible hollow sealing bulb that compresses against the glass, and a smooth outer lip that deflects water and debris. This geometry ensures a consistent sealing force even when the cab undergoes torsional flexing (common on heavy trucks).
The material is 100% EPDM rubber, specifically formulated to pass the stringent DIN 53505 hardness test (70 Shore A) and the SAE J200 aging test (70°C for 70 hours, no cracking). Unlike cheap PVC or sponge seals, this EPDM compound does not shrink, harden, or crack after years of UV exposure. It also has excellent resistance to road salts, diesel fumes, and car wash chemicals.
Fleet operators using the LG1613714001 report a 98% reduction in rear window leaks and a noticeable decrease in wind noise at highway speeds. The strip also prevents dust ingress, keeping the sleeper compartment cleaner and extending the life of electronics.
Resistant to ozone, UV, acid rain, and extreme temperatures (-40°C to +120°C). No cracking or hardening over time.
Hollow bulb design compresses evenly, creating a high‑pressure seal that passes water spray tests per ISO 20653.
Multi‑chamber profile absorbs vibration, eliminating glass rattle and reducing interior wind noise.
| OEM Number | LG1613714001 |
| Product Name | Rear Window Sealing Strip (Rubber Gasket) |
| Brand | SINOTRUK Homan |
| Material | High‑grade EPDM (ethylene propylene diene monomer) rubber |
| Hardness (Shore A) | 70 ±5 (DIN 53505) |
| Tensile Strength (min) | 8 MPa (DIN 53504) |
| Elongation at Break (min) | 300% (DIN 53504) |
| Operating Temperature Range | -40°C to +120°C |
| Length (per piece) | Custom cut to cab window perimeter (typically 4‑5 meters) |
| Profile Type | Hollow sealing bulb + locking barb + outer lip |
| Weather Resistance | Excellent ozone, UV, and chemical resistance (ASTM D1171) |
| Color | Matte black |
| Installation Method | Press‑fit into channel (no adhesive required) |
| Standards Met | ISO 9001, IATF 16949, DIN 53504, SAE J200 |
| Applications | SINOTRUK HOWO A7/T7H, SHACMAN F3000, CNHTC rear windows |
The LG1613714001 is produced by continuous vulcanization extrusion, ensuring a uniform cross‑section along the entire length. The EPDM compound is mixed in a closed‑mill banbury mixer, ensuring consistent dispersion of carbon black, anti‑oxidants, and UV stabilizers. The strip is then cut to the exact length for each cab model and de‑burred to prevent sharp edges.
The sealing bulb is designed with a slight oval shape that, when compressed, creates a progressive sealing force. This allows the seal to accommodate glass thickness variations of ±1 mm without losing effectiveness. The barbed anchor leg has a fish‑scale texture that grips the steel channel, preventing the strip from pulling out during installation or vehicle operation.
Each batch of rubber is tested for hardness, tensile strength, and accelerated aging (70°C for 168 hours). A sample of the finished strip is subjected to a water spray test (ISO 20653 IPX4) and a compression set test (22h at 70°C). Only strips with less than 25% compression set are released for sale.
EPDM rubber used in the LG1613714001 has an ethylene content of over 70%, giving it excellent resistance to ozone cracking (ASTM D1171 rating 0). It also withstands prolonged exposure to road salts, diesel fuel, and mild acids without swelling or degradation. The black color is integral (carbon‑black filled), so the seal will never fade to gray.
The material has been validated for 5 years of outdoor exposure in Florida and Arizona proving grounds, with no surface cracking or significant loss of elasticity. For arctic conditions, the seal remains flexible down to -40°C without becoming brittle.
Unlike sponge rubber, which absorbs water, this dense seal does not wick moisture, eliminating the risk of rust behind the glass.
The LG1613714001 is a direct replacement for the original rear window seal on SINOTRUK HOWO and SHACMAN cabs. It fits into the existing channel without trimming (supplied pre‑cut to size for each cab variant). No adhesive or special tools are required – a simple rubber mallet and a plastic trim tool are sufficient.
To replace an old seal: remove the rear window glass, pull out the old seal, clean the channel, lubricate the new seal with soapy water, push the barbed leg into the channel, then insert the glass and press the bulb against it. The seal will self‑lock into position.
The seal can also be used on truck side windows, sunroofs, and other fixed glass applications, as long as the channel geometry matches.
To replace a worn rear window seal with the LG1613714001, follow these steps: 1) Remove the rear window glass from the cab by carefully cutting the old seal from the outside.
2) Pull out the old seal remnants and clean the metal channel with a wire brush and solvent. Remove all rust and debris.
3) Inspect the channel for sharp edges; deburr if necessary. Apply a thin layer of rubber lubricant or soapy water to the channel.
4) Starting at the bottom center, push the barbed leg of the new seal into the channel using a blunt plastic tool. Work your way around the perimeter. Ensure the seal is fully seated without twists.
5) Insert the rear window glass into the seal’s glass groove. Starting at the bottom, press the glass inward while pulling the inner lip of the seal over the glass edge. Use a rubber mallet to tap gently.
6) Once the glass is fully seated, run a water hose over the window to check for leaks. If any leaks are found, use a sealant tool to lift the lip and apply a small bead of silicone.
The LG1613714001 requires no routine maintenance. However, inspect the seal annually for cuts, tears, or flattening of the sealing bulb. If the rubber feels hard or shows cracks, replace it.
If water leaks appear, first check that the glass is fully seated; sometimes the seal may have rolled out of position. Use a plastic trim tool to re‑seat the lip. If leaks persist, the channel may be corroded – clean and apply a urethane sealant.
Do not use petroleum‑based lubricants on the seal – they can attack EPDM. Only use silicone‑based or water‑based rubber lubricants.
Each batch of LG1613714001 seals is tested to meet OEM and international standards. Tests include: (1) Tensile strength and elongation (DIN 53504), (2) Hardness (Shore A), (3) Compression set (22h at 70°C, ≤25%), (4) Ozone resistance (ASTM D1171, 50 pphm, 72h, zero cracks), (5) UV weathering (500h QUV, no color change), (6) Low‑temperature flexibility (−40°C, no cracking).
(7) Water ingress test (ISO 20653 IPX4), (8) Pull‑out force test (≥50 N/cm). The manufacturing facility is IATF 16949 and ISO 9001 certified. A certificate of conformance is supplied with each shipment.
The seal also meets the requirements of GL‑E 4.4 for railway applications, ensuring exceptional durability.
A North American fleet of 150 HOWO trucks suffered from persistent rear window leaks that caused damage to interior bunk electronics. After replacing all seals with the LG1613714001, the fleet reported zero leaks in the first year and a 90% reduction in wind noise complaints. Drivers also noted less dust entry on gravel roads.
A South African mining company using SHACMAN dump trucks in high‑dust conditions found that the OEM seal lasted twice as long as aftermarket sponge seals, which hardened and cracked after 6 months. The EPDM material remained flexible even under constant sun exposure, reducing replacement costs by 60%.
Each LG1613714001 Rear Window Sealing Strip is coiled in a sealed, dust‑proof plastic bag and packed in a cardboard box. The bag is labeled with the OEM number, batch code, and a QR code for authenticity.
A tamper‑evident hologram sticker is affixed to the box. Scanning the QR code leads to the SINOTRUK Homan verification portal. Counterfeit seals are often made of PVC or low‑grade rubber that hardens quickly or has an unpleasant smell. Genuine EPDM strips have a smooth, matte finish, a slight rubber odor, and a clearly visible extrusion seam.
Purchase only from authorized distributors. The genuine LG1613714001 comes with a 12‑month / 100,000 km warranty.
Summary: The SINOTRUK Homan Rear Window Sealing Strip (OEM LG1613714001) delivers superior water sealing, UV resistance, and vibration damping for heavy‑duty truck cabs. Upgrade your rear window seal with this genuine OEM rubber strip – the trusted choice for dry, quiet, and comfortable cabins.
