Secure every critical assembly on your heavy-duty truck with the genuine BY90011400043 Hex Flange Bolt, a premium-grade fastener engineered to meet the rigorous demands of SHACMAN commercial vehicles. This integral component provides superior clamping force and vibration resistance for essential connections, including wheel hubs, suspension components, engine mounts, and driveline assemblies. As a dedicated supplier of Shacman truck parts, we understand that a single failed bolt can lead to catastrophic component separation, costly damage, and serious safety risks.
The BY90011400043 is manufactured from high-strength alloy steel and processed to SHACMAN’s exact OEM specifications, ensuring perfect thread pitch, head dimensions, and precise torque characteristics. Its integrated flange design distributes clamping load over a wider area, enhancing joint stability and preventing loosening under extreme stress. Selecting the authentic BY90011400043 Hex Flange Bolt is a fundamental decision for maintaining structural integrity, ensuring operational safety, and preventing unexpected downtime in the most demanding transportation environments.
Hex Flange Bolt
High-Strength Alloy Steel Construction: The BY90011400043 bolt is forged from premium alloy steel, typically Grade 10.9 or higher, providing exceptional tensile strength, yield strength, and resistance to shear forces under heavy loads and shock impacts.
Integrated Washer Flange Design: Features a seamlessly integrated, circular flange under the hex head. This eliminates the need for a separate washer, provides a larger bearing surface, distributes clamp load evenly, and helps prevent embedding into softer materials.
Precision-Rolled Threads: Manufactured with cold-rolled threads that enhance fatigue resistance and provide smoother engagement with nuts or tapped holes. This process creates a more uniform grain structure compared to cut threads, significantly increasing durability.
Anti-Corrosion Zinc Plating: Finished with a high-quality zinc plating or zinc-flake coating that offers excellent corrosion resistance. This protective layer safeguards the bolt from rust and oxidation caused by road salt, moisture, and harsh weather conditions, extending its service life.
The table below provides detailed technical specifications for the BY90011400043 Hex Flange Bolt. This data is essential for verifying correct application, strength grade, and compatibility.
| Parameter | Value / Description |
|---|---|
| OEM Part Number | BY90011400043 |
| Product Name | Hex Flange Bolt |
| Brand | SHACMAN |
| Material | Medium Carbon Alloy Steel |
| Strength Grade | 10.9 (Commonly used for high-stress applications) |
| Surface Finish | Zinc Plated (Yellow Chromate or similar for corrosion resistance) |
| Thread Pitch | Standard Metric Coarse (e.g., M12 x 1.75) – Application Specific |
| Head Style | Hexagon with Integrated Flange |
| Drive Type | Hex Socket (Allen) or External Hex – Model Specific |
| Flange Diameter | Varies with bolt size; larger than standard hex head for load distribution |
| Torque Specification | Refer to SHACMAN service manual for exact values based on size and grade |
| Compatible Applications | Chassis, suspension, engine mounts, transmission, wheel hubs on F2000, F3000, X3000 series |
Always use the correct torque specification for the BY90011400043 bolt as per SHACMAN’s service documentation to ensure joint integrity and prevent failure.
The BY90011400043 Hex Flange Bolt is a versatile and critical fastener used across numerous high-stress systems on SHACMAN trucks. Its primary function is to create a rigid, secure, and reliable clamped joint between two or more components.
Common applications include securing wheel hub assemblies to axles, fastening suspension control arms and brackets, mounting engine and transmission components, and assembling frame crossmembers. The integrated flange acts as a built-in washer.
This design provides a larger contact area on the clamped surface, which reduces surface pressure and helps prevent loosening caused by vibration, a common challenge in heavy-duty vehicles. For fleet technicians, the BY90011400043 ensures consistent fastening quality.
Using the correct OEM bolt guarantees that the joint will behave as engineered, maintaining proper preload and alignment. For safety, these bolts are crucial in dynamic systems where failure could lead to loss of vehicle control or component detachment.
The BY90011400043 is specified for applications where standard hex head bolts with separate washers may not provide sufficient bearing surface or vibration resistance. Its use is a key factor in achieving the designed durability and safety margins of the vehicle.
During assembly or repair, using the genuine bolt ensures that the clamping force is accurately translated through the joint without compromising the fastened materials.
1. Ensure the threaded hole or nut is clean, undamaged, and free of old thread locker, dirt, or corrosion. Chase threads if necessary.
2. Inspect the new BY90011400043 bolt for any shipping damage or defects. Do not use a bolt with damaged threads, a marred head, or a cracked flange.
3. If specified by SHACMAN procedure, apply the recommended thread-locking compound or anti-seize lubricant to the bolt threads. Avoid contaminating the bearing surface of the flange.
4. Insert the bolt by hand to ensure smooth, non-binding thread engagement. Do not force the bolt if it does not start easily.
5. Using the correct size socket or wrench, tighten the bolt initially to seat the flange firmly against the workpiece.
6. Final tightening must be performed with a calibrated torque wrench. Tighten in a gradual, controlled manner to the exact torque value specified in the SHACMAN service manual for the BY90011400043 application.
7. For critical joints with multiple bolts, follow the specific tightening sequence (e.g., star pattern) to ensure even clamping and prevent distortion.
• During routine maintenance inspections, visually check critical fasteners, including the BY90011400043, for signs of looseness, corrosion, or head deformation.
• Use a torque wrench to periodically check the torque on safety-critical bolts, especially after the first few hundred miles following installation or repair.
• Look for signs of fretting or wear around the flange contact area, which could indicate movement and loss of preload.
• Never reuse stretch bolts or bolts that have been tightened past their yield point (common in some cylinder head or connecting rod applications). Always replace with new genuine bolts as specified.
• If a bolt is removed, inspect its threads and the mating threads for damage. Replace the BY90011400043 bolt if threads are galled, stripped, or corroded.
• Keep a log of critical fastener replacements as part of the vehicle’s permanent maintenance record.
Proper torque is non-negotiable. Under-torquing can lead to joint loosening and fatigue failure, while over-torquing can stretch the bolt beyond its elastic limit, causing it to lose clamping force or fracture.
Choosing the genuine BY90011400043 Hex Flange Bolt guarantees material integrity, dimensional accuracy, and certified mechanical properties. SHACMAN sources fasteners with precise chemical compositions and heat treatment processes.
This ensures consistent hardness, tensile strength, and fatigue resistance across every batch. Aftermarket bolts may claim the same grade but often have inconsistent heat treatment or inferior raw materials.
These deficiencies can lead to premature failure under cyclic loading. The genuine BY90011400043 has controlled thread dimensions and root radii that optimize stress distribution, reducing the risk of crack initiation.
Its plating thickness and quality are also controlled to provide reliable corrosion protection without adversely affecting torque-tension relationships. Using the authentic bolt ensures the joint performs as engineered for safety and longevity.
Master technicians emphasize that the BY90011400043 bolts provide consistent feel during torquing and reliable clamp load retention. Their precise manufacturing minimizes the risk of thread galling or seizing during installation.
Fleet maintenance managers report fewer incidents of fastener-related failures, such as wheel stud or suspension bolt breakages, when standardizing on genuine SHACMAN fasteners like the BY90011400043.
This reliability is crucial for minimizing unscheduled road calls and enhancing overall fleet safety records. Operators in off-road and heavy-haul applications note that critical assemblies remain tight even after enduring severe vibration and shock loads.
The performance feedback consistently highlights that while a bolt seems like a simple commodity, the engineering and quality behind the genuine BY90011400043 make it a vital component for dependable vehicle operation.
The BY90011400043 Hex Flange Bolt contributes to vehicle safety and environmental responsibility by ensuring component integrity. A failed fastener can lead to the loss of a wheel, suspension collapse, or engine mount failure.
These scenarios pose immediate dangers to the driver, other road users, and can cause secondary environmental damage through spills or accidents. The bolt’s corrosion-resistant plating reduces the need for frequent replacement.
This minimizes waste and the environmental impact associated with manufacturing and disposing of inferior fasteners. Using a bolt that maintains proper preload also ensures that sealed joints (e.g., in axles or gearboxes) do not leak fluids.
This prevents soil and water contamination. From a workshop safety perspective, the consistent quality of the genuine BY90011400043 reduces the risk of tool slippage or bolt failure during installation, protecting technicians from injury.
Each production batch of BY90011400043 bolts is subject to rigorous quality control. This includes testing for hardness, tensile strength, proof load, and dimensional conformity to international standards (e.g., ISO, DIN).
As an authentic SHACMAN component, the BY90011400043 is covered by the manufacturer’s warranty against defects in material and workmanship. This provides assurance of its reliability in critical applications.
Purchasing from authorized supply channels guarantees you receive genuine, warrantied parts. It also ensures access to accurate technical data regarding proper installation torque and application guidelines.
Counterfeit fasteners pose a significant safety risk and are not subject to any meaningful quality control. They can fracture unexpectedly, with devastating consequences. Always verify the part number and source.
The initial cost of a genuine BY90011400043 bolt is insignificant compared to the potential cost of a failure. Replacing a broken wheel bolt is cheap; recovering a vehicle after a wheel detachment and repairing the collateral damage is extremely expensive.
Its superior corrosion resistance means it can be removed and reinstalled during servicing without seizing, saving labor time and preventing damage to other expensive components.
For fleets, standardizing on OEM fasteners like the BY90011400043 simplifies inventory, ensures repair consistency, and provides predictable performance, reducing overall maintenance costs and improving vehicle uptime.
Investing in the correct fastener minimizes the total cost of ownership by preventing catastrophic failures, reducing liability, and extending the service life of the assemblies it secures.
The BY90011400043 Hex Flange Bolt is designed for specific locations and load requirements on SHACMAN trucks. Compatibility depends on the vehicle model, model year, and the specific component being fastened.
Using the exact OEM number BY90011400043 is critical. Bolts may have the same thread size and head style but differ in length, strength grade, flange diameter, or material composition.
Using an incorrect bolt can compromise joint integrity. Always verify the application using your truck’s VIN, an official SHACMAN parts catalog, or a detailed workshop manual.
Correct fitment ensures the bolt develops the proper clamping force without bottoming out, over-extending, or interfering with other components. Never substitute a fastener without confirming all specifications match.
The BY90011400043 Hex Flange Bolt is a fundamental element in the structural and mechanical integrity of your SHACMAN truck. Its role in maintaining secure, reliable connections cannot be overstated.
Choosing the genuine BY90011400043 is an investment in safety, reliability, and performance. Trust SHACMAN’s engineering to provide the fastening solution that meets the extreme demands of heavy-duty transport.
For your next repair, rebuild, or preventative maintenance, specify the authentic BY90011400043 Hex Flange Bolt. Ensure every joint is secured to perfection, and drive with the confidence that comes from uncompromised quality.
