FAW Level 1 Pedal & Decorative Cover Assembly

FAW Level 1 Pedal & Decorative Cover Assembly
FAW Level 1 Pedal & Decorative Cover Assembly
Download Catalog
Get Quotation

What is the FAW Level 1 Pedal & Decorative Cover Assembly

  • FAW Level 1 Pedal & Decorative Cover Assembly
    This integrated assembly combines essential driver control with refined cabin aesthetics for FAW trucks. It securely houses the primary accelerator pedal within a robust structural framework, while providing a visually cohesive and protective decorative cover. Designed for durability, safety, and ease of maintenance, it ensures reliable pedal operation and enhances the cab’s interior finish.
  • FAW Front Lowerguard & Pedal Bracket Assembly
    Serving as the critical structural foundation, the Front Lowerguard & Pedal Bracket Assembly provides a rigid mounting platform. This heavy-duty component anchors the Level 1 Pedal mechanism securely to the cab floor and firewall, ensuring precise pedal positioning, minimizing flex during operation, and protecting sensitive components located behind the pedal area from debris and impact. Its design is integral to driver control precision and long-term reliability.
  • FAW Level 1 Pedal
    The core functional element is the Level 1 Pedal. Engineered for precise throttle response and driver comfort, this pedal features an ergonomic design and durable construction. It interfaces directly with the vehicle’s throttle control system, translating driver input into acceleration commands. Its mounting within the bracket assembly guarantees consistent operation and resistance to wear under constant use.
  • FAW Decorative Cover System (Right & Left)
  • Right Pedal Decorative Cover & Left Pedal Decorative Cover: These panels form the primary visible exterior of the assembly. Made from high-quality, scratch-resistant plastics or composites, they seamlessly integrate with the FAW cab interior trim, concealing the pedal mechanism and wiring for a clean appearance. They are designed for easy cleaning and long-term aesthetic appeal.
  • Fixing Bracket-Small Door of Pedal Decorative Cover: Provides a secure mounting point specifically for the access panel.
  • Small Door of Pedal Decorative Cover: A dedicated, removable access panel within the main decorative cover(s). Facilitates quick inspection or servicing of pedal linkages, sensors, or wiring behind the cover without full removal.
  • Limit Clip-Small Door of Pedal Decorative Cover: A simple yet vital component that securely retains the Small Door when closed, preventing rattles or accidental opening during vehicle operation, while allowing easy tool-free access when needed.
  • Critical Fastening & Security Components
  • Hexagon Flange Bolt Thick Rod (Standard Type): Used for high-stress structural connections within the Front Lowerguard & Pedal Bracket Assembly and pedal mounting. The thick rod offers superior shear strength, while the flange distributes load and resists loosening.
  • Hexagon Flange Bolt & Hexagon Flange Lock Nut: Provide robust, vibration-resistant fastening for various assembly points. The flange aids load distribution, and the lock nut (featuring a prevailing torque design) ensures critical joints remain secure over time.
  • Hexagon Flange Lock Nut: Specifically used where maximum vibration resistance is required on flange bolts.
  • Large Washer: Employed under bolt heads or nuts to distribute clamping force over a wider area, preventing damage to softer materials and ensuring joint integrity.
  • Cross Recessed Button Head Screw: Used specifically for attaching the Small Door of Pedal Decorative Cover to its Fixing Bracket. The button head provides a low-profile, visually clean finish, while the cross recess allows for standard screwdriver installation/removal during service access.
  • This assembly exemplifies FAW’s commitment to functional design, driver ergonomics, and cabin refinement, ensuring both operational reliability and a professional interior environment.

Product Parameters of FAW Level 1 Pedal & Decorative Cover Assembly

Order Part NO. Part Name And Standards Oty
Level 1 Pedal & Decorative Cover  Assembly 1
1 5103010-1063 Front  Lowerguard & Pedal Bracket Assembly 1
2 CQ32718 Hexagon Flange Lock Nut 6
3 Q1851890T Hexagon Flange Bolt Thick Rod (Standard  Type) 2
4 2801012-1063 Hexagon Flange Bolt 4
5 Q40220 Large Washer 4
6 5103022-1063 Right  Pedal Decorative Cover 1
7 5103031-1063 Level 1 Pedal 2
8 5103053-1063 Fixing Bracket-Small Door  of Pedal  Decorative Cover 2
9 5103052-1063 Small Door of Pedal Decorative  Cover 1
10 Q2360620F32 Cross Recessed Button Head  Screw 8
11 Q2360612 Cross Recessed Button Head  Screw 2
12 5103061-1063 Limit Clip-Small Door of Pedal  Decorative Cover 2
13 5103021-1063 Left  Pedal Decorative Cover 1
