Front Left ABS Valve With Pipe Connector Assembly / Front Right ABS Valve With Pipe Connector Assembly: These wheel-specific modules house the ABS Solenoid Valve Assembly. They receive signals from wheel speed sensors and rapidly modulate hydraulic brake pressure to individual wheels during incipient lockup. Pre-assembled pipe connectors ensure leak-proof integration into the brake lines.
ABS Solenoid Valve Assembly: The electronically controlled valves inside each module that open/close to release/reapply brake pressure cyclically during ABS activation.
Threaded Sleeve (M22) With Seal Ring Assy: Robust sealed fittings connecting the ABS valve modules to the main brake hydraulic lines.
Special Shaped Seal Ring(Φ 15.2): Precision seal within the M22 sleeve, creating a high-pressure barrier against brake fluid leaks.
Hydraulic and Pneumatic Rubber O-ring / Seal Threaded Sleeve: Additional seals ensuring fluid integrity at pipe joints and internal valve interfaces.
Elbow: Angled pipe fittings enabling compact routing of hydraulic lines to/from the ABS valves.
Circlip(Φ 12): Internal retaining ring securing critical components within the valve assemblies.
| Order | Part NO. | Part Name And Standards | Oty |
| ABS Device Assembly | |||
| 1 | CQ1501435 | Hexagon Head Bolt | 4 |
| 2 | Q40314 | Spring Washer | 6 |
| 3 | CQ34014 | Hexagon Nut | 6 |
| 4 | CQ1500880 | Hexagon Head Bolt | 4 |
| 5 | Q40108 | Washer | 4 |
| 6 | Q40308 | Spring Washer | 4 |
| 7 | CQ34008 | Hexagon Nut | 4 |
| 8 | 3550317A40A | Bracket-Front Left ABS Valve | 1 |
| 9 | 3550315-1500W | Front Left ABS Valve With Pipe Connector Assembly | 1 |
| 10 | CQ7342212E | Hydraulic and Pneumatic Rubber O-ring | 2 |
| 11 | 3550310-50A | ABS Solenoid Valve Assembly | 2 |
| 12 | 3511012-1H | Seal Threaded Sleeve | 2 |
| 13 | 3550311B109 | Elbow | 2 |
| 15 | 3513407-1500 | Circlip(Φ 12) | 7 |
| 16 | 3513410-1500 | Threaded Sleeve (M22) With Seal Ring Assy | 7 |
| 17 | 3513403-1500 | Special Shaped Seal Ring(Φ 15.2) | 7 |
| 18 | 3550318A40A | Bracket-Front Left ABS Valve | 1 |
| 19 | 3550320-1500W | Front Right ABS Valve With Pipe Connector Assembly | 1 |
