FAW Cigarette Lighter Logical Assembly

FAW Cigarette Lighter Logical Assembly
FAW Cigarette Lighter Logical Assembly
Download Catalog
Get Quotation

What is the FAW Cigarette Lighter Logical Assembly

  • FAW Cigarette Lighter Logical Assembly Overview
    This integrated system provides a reliable and user-friendly 12V power solution within FAW vehicle cabins. Engineered as a cohesive “logical assembly,” it seamlessly combines the socket and plug components into a single functional unit, prioritizing electrical safety, ergonomic access, and consistent power delivery for driver and passenger accessories.
  • Cigarette Lighter Socket Assembly
  • Secure Vehicle Integration: Hardwired directly into the FAW’s electrical system, featuring robust terminals for stable voltage output.
  • Thermoplastic Housing: Engineered for heat resistance and durability in high-use cabin environments.
  • Spring-Loaded Center Contact: Ensures positive electrical connection with compatible plugs while resisting wear.
  • Insulated Side Electrode Design: Prevents accidental short-circuiting for enhanced safety.
  • Flush-Mount Bezel: Provides a clean, OEM-integrated appearance on dashboards or consoles.
  • Cigarette Lighter Plug Assembly
  • Positive Engagement Tip: Features a spring-biased center pin for reliable contact with the socket electrode.
  • Dual-Spring Outer Sleeve Contact: Maintains consistent grounding connection even during vehicle vibration.
  • Heat-Resistant Handle: Ergonomically designed for safe insertion/removal after heating cycles.
  • Integrated Fuse Protection: Safeguards vehicle circuits against overloads (common in modern implementations).
  • Standard 12V Compatibility: Works universally with FAW sockets and compliant third-party accessories.
  • The “Logical” System Integration
    The assembly operates on intuitive logic: The Socket Assembly serves as the vehicle-fixed power source, while the Plug Assembly acts as the removable activation key. When inserted, the plug’s dual contact points complete the circuit through the socket’s electrodes. An auto-reset thermal fuse (if equipped) provides overload protection without user intervention. This failsafe design ensures consistent accessory power while preventing electrical hazards – a critical feature integrated into FAW’s driver-centric cabin architecture.

Product Parameters of FAW Cigarette Lighter Logical Assembly

Order Part NO. Part Name And Standards Oty
Cigarette Lighter Logical  Assembly 1
1 3725010-240 Cigarette Lighter Plug Assembly 1
2 3725020-240 Cigarette Lighter Socket Assembly 1
