Shacman X6000 Truck Parts Catalog – CHINA TRUCK AND SPARE PARTS SUPPLIER https://deruna.com We are a first-class heavy duty vehicles and spare parts supplier in China. Wed, 25 Jun 2025 09:25:15 +0000 zh-Hans hourly 1 https://deruna.com/wp-content/uploads/2024/05/cropped-deruna-logo-512-32x32.webp Shacman X6000 Truck Parts Catalog – CHINA TRUCK AND SPARE PARTS SUPPLIER https://deruna.com 32 32 Shacman X6000 Spare Wheel Carrier-Parts Catalog https://deruna.com/shacman-x6000-spare-wheel-carrier-parts-catalog.html https://deruna.com/shacman-x6000-spare-wheel-carrier-parts-catalog.html#respond Wed, 25 Jun 2025 09:22:42 +0000 https://deruna.com/?p=79862 […]]]>

Shacman X6000 Spare Wheel Carrier-Parts Catalog

Shacman X6000 Spare Wheel Carrier-Parts Catalog
Shacman X6000 Spare Wheel Carrier-Parts Catalog
Download Catalog
Get Quotation

What is the Shacman X6000 Spare Wheel Carrier-Parts Catalog？

  • The Shacman X6000 Spare Wheel Carrier Parts Catalog provides OEM-grade components designed to safely store and deploy spare wheels on heavy-duty trucks, ensuring reliability and ease of access in demanding operational environments. Engineered with robust materials and precision fasteners, this catalog includes essential parts to maintain the carrier’s structural integrity and functionality. Below is a detailed breakdown of key components:​
  • 1. Spare Wheel Carrier​
  • The Spare Wheel Carrier serves as the core structural component, constructed from high-strength steel alloy to withstand dynamic loads and road vibrations. Its powder-coated finish resists corrosion from moisture, salt, and debris, while the modular design allows adjustable mounting for different wheel sizes (e.g., 315/80R22.5). The carrier features a locking mechanism to secure the spare wheel during transit and a smooth pivot system for easy lowering/raising, minimizing effort during tire changes.​
  • 2. High-Tensile Bolts​
  • Mounting Bolts (M12×50mm, 10.9-grade steel) attach the carrier to the truck’s frame or undercarriage, engineered with a zinc-plated coating to resist rust. Their hexagon head design enables precise torque application (80-100Nm), ensuring secure fastening even under heavy suspension movement.​
  • Wheel Retaining Bolts (M14×35mm) secure the spare wheel to the carrier, featuring a tapered seat to align with wheel hub holes and prevent lateral play. These bolts undergo heat treatment for enhanced shear resistance, critical for maintaining wheel stability during transport.​
  • 3. Self-Locking Nuts & Flange Nuts (Self-locking Nuts & Flange Nuts)​
  • Self-locking Nuts (M12, Type 2) are used on carrier-to-frame connections, with a nylon insert that creates friction to prevent loosening from vibrations. Compliant with ISO 7042 standards, they eliminate the need for additional lock washers, simplifying installation.​
  • Flange Nuts (M14, serrated underside) secure wheel retaining bolts, distributing clamping force over a larger surface area to prevent damage to the carrier’s mounting plate. Their serrated design grips surfaces to resist rotational slippage in high-vibration environments.​
  • 4. flat washer (Flat Washers)​
  • Flat Washers (12mm and 14mm 内径) are placed between bolt heads/nuts and mating surfaces to evenly distribute pressure, reduce surface wear, and enhance joint integrity. Made from corrosion-resistant steel, they ensure uniform load transfer across critical connections, such as the carrier bracket to the chassis, minimizing the risk of fastener fatigue.​
  • System Integration & Performance​
  • The spare wheel carrier assembly is designed for quick, tool-free installation, with all components precision-engineered to match Shacman X6000’s chassis geometry. The combination of high-tensile bolts, vibration-resistant nuts, and load-distributing washers ensures the carrier remains securely attached, even on rough terrain. Regular maintenance—including torque checks for bolts and lubrication of pivot points—will extend the carrier’s service life and ensure reliable spare wheel access when needed most.​
  • The Shacman X6000 Spare Wheel Carrier Parts Catalog delivers a comprehensive solution for maintaining your truck’s spare wheel system, with each component tested for durability, corrosion resistance, and compatibility. Trust in OEM-quality parts to keep your vehicle prepared for any road challenge, ensuring minimal downtime and maximum safety for your fleet.​

Product Parameters of Shacman X6000 Spare Wheel Carrier-Parts Catalog

NOPart.NoNameQuantity
106.11251.2003Nut2
2Q402B12Washer2
3Q341C12T2F3Nut2
4Q1811250TF3Bolt2
506.11251.2005Nut4
6DZ9X259860002Spare wheel carrier2
7Q1811435TF3Bolt4



Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-spare-wheel-carrier-parts-catalog.html/feed 0 Shacman X6000 Controller Bracket https://deruna.com/shacman-x6000-controller-bracket.html https://deruna.com/shacman-x6000-controller-bracket.html#respond Wed, 25 Jun 2025 09:19:17 +0000 https://deruna.com/?p=79856

Shacman X6000 Controller Bracket

Shacman X6000 Controller Bracket
Shacman X6000 Controller Bracket
Download Catalog
Get Quotation

What is the Shacman X6000 Controller Bracket？

  • The Shacman X6000 Controller Bracket is a modular mounting solution engineered to securely position and protect the vehicle’s Electronic Control Unit (ECU), ensuring stable operation and reliable connectivity in demanding commercial environments. Crafted with high-strength materials and precision-fit components, this bracket system integrates seamlessly with the truck’s chassis, minimizing vibration-induced stress on the ECU while facilitating easy installation and maintenance. Below is a detailed breakdown of its key components:​
  • 1. ECU Bracket 1 (Body)​
  • The ECU Bracket 1 (Body) serves as the primary structural foundation, fabricated from lightweight yet durable aluminum alloy to withstand harsh engine bay temperatures and corrosive elements. Its contoured design features reinforced ribs for enhanced rigidity, strategically placed mounting points to align with the ECU’s form factor, and pre-drilled holes for precise chassis integration. The bracket’s surface is treated with a thermal-conductive coating to dissipate heat efficiently, protecting the ECU from overheating during prolonged operation.​
  • 2. ECU Bracket 3 & ECU Bracket 4​
  • ECU Bracket 3 acts as a lateral support arm, connecting the primary bracket to the vehicle’s frame to eliminate side-to-side movement. Made from high-tensile steel with a powder-coated finish, it features adjustable slots that allow minor positional adjustments to accommodate different ECU configurations.​
  • ECU Bracket 4 functions as a vertical stabilizer, reinforcing the top or bottom of the ECU to prevent vertical displacement during heavy acceleration, braking, or off-road vibrations. Its L-shaped design fits snugly against the ECU’s corners, with rubberized mounting pads to isolate electrical components from direct metal contact and reduce noise interference.​
  • 3. Screw Bolts & Mounting Hardware​
  • High-strength Bolts (M6×20mm, zinc-plated steel) secure the brackets to the chassis and ECU, featuring a hexagon head for easy torque application (20-25Nm) and a self-locking thread design to resist loosening from continuous vibrations.​
  • Complementary Lock Washers and Flange Nuts are included to enhance joint stability, with serrated washers gripping mating surfaces to prevent rotational slippage and flange nuts distributing clamping force evenly across bracket interfaces.​
  • System Design & Performance Benefits​
  • The modular design of the Controller Bracket allows for quick, tool-free ECU installation and removal, simplifying diagnostic access and component replacement. By separating load-bearing functions across Bracket 1, 3, and 4, the system ensures balanced stress distribution, reducing the risk of fatigue damage to both the ECU and bracket components. All hardware meets ISO 898-1 strength standards, while the brackets comply with IP67 environmental ratings for dust and water resistance, making them ideal for long-haul trucks operating in diverse climates.​
  • The Shacman X6000 Controller Bracket delivers a robust, OEM-grade solution for securing critical electronic controls, combining structural integrity with installation flexibility. Each component is rigorously tested for vibration resistance, thermal stability, and dimensional precision, ensuring seamless compatibility with Shacman X6000 models. Regular inspection of bolt torque and bracket alignment is recommended to maintain optimal ECU performance and extend the system’s service life, ensuring reliable operation mile after mile.​

Product Parameters of Shacman X6000 Controller Bracket

NOPart.NoNameQuantity
1DZ9L149585210ECU bracket 1 (body)1
2Q341B08screw bolt2
3Q150B0616bolt1
4DZ9L149585204ECU bracket 41
5Q2300616bolt4
6DZ9L149585203ECU bracket 31



Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-controller-bracket.html/feed 0 Shacman X6000 Air Compessor Outer Line/6×4 13l https://deruna.com/shacman-x6000-air-compessor-outer-line-6x4-13l.html https://deruna.com/shacman-x6000-air-compessor-outer-line-6x4-13l.html#respond Wed, 25 Jun 2025 09:15:50 +0000 https://deruna.com/?p=79850

Shacman X6000 Air Compessor Outer Line/6×4 13l

Shacman X6000 Air Compessor Outer Line/6×4 13l
Shacman X6000 Air Compessor Outer Line/6×4 13l
Download Catalog
Get Quotation

What is the Shacman X6000 Air Compessor Outer Line/6×4 13l？

  • The Shacman X6000 Air Compressor Outer Line/6×4 13L is a high-performance pneumatic system designed to efficiently transfer compressed air from the compressor to the vehicle’s brake system, air suspension, and auxiliary components. Engineered for heavy-duty 6×4 trucks with 13-liter engines, this outer line assembly combines durable materials and precision components to withstand high pressure, vibration, and harsh environmental conditions. Below is a detailed breakdown of its key components:​
  • 1. Nozzle & Seal Ring​
  • Nozzles serve as critical connection points for air intake and output, machined from corrosion-resistant aluminum alloy to ensure smooth airflow and minimal pressure loss. Their flared design aligns with hose fittings, creating a secure mechanical interface.​
  • Paired with Seal Rings (made from heat-resistant NBR rubber), these nozzles form leak-proof seals in high-pressure joints. The rings feature a double-lip design to prevent moisture and debris ingress, maintaining airtight integrity even at extreme temperatures (-40°C to +120°C).​
  • 2. Pipe & Stainless Steel Hose​
  • Steel Pipes (cold-drawn seamless steel, 6mm inner diameter) form the rigid backbone of the system, engineered to handle up to 16 bar of pressure. Their galvanized coating resists rust and chemical corrosion, ideal for long-term exposure to road salt and moisture.​
  • Stainless Steel Hoses provide flexible connections in high-vibration areas, such as between the compressor and chassis. Braided with 304-grade stainless steel, these hoses offer superior abrasion resistance and bend fatigue life, ensuring reliable performance without kinking or cracking.​
  • 3. Pipe Clamp & Bracket​
  • Pipe Clamps (stamped steel with EPDM rubber inserts) secure rigid pipes to the chassis, reducing vibration-induced wear. The rubber lining absorbs shocks and prevents metal-to-metal contact, extending pipe service life.​
  • Mounting Brackets (formed from high-strength steel) provide structural support for hoses and components, featuring pre-drilled holes for easy alignment with vehicle frame points. Their powder-coated finish enhances resistance to chipping and rust.​
  • 4. Hex.screw & Nut​
  • Zinc-plated Hex.screws (M8×25mm, 10.9-grade tensile strength) fasten brackets and clamps to the chassis, offering superior vibration resistance. Their hexagon head design allows easy torque adjustment (50-60Nm) with standard tools.​
  • All-metal Locknuts (Type 2, M8 thread) secure screw connections, featuring a nylon insert to prevent loosening under dynamic loads. These nuts comply with ISO 7042 standards, ensuring long-term reliability in high-stress environments.​
  • 5. System Integration & Performance​
  • The outer line assembly optimizes air flow for the 13L engine’s high-output compressor, minimizing pressure drops and ensuring rapid response for brake applications. Rigid pipes are routed along the chassis with precision-bent angles to avoid sharp turns, while flexible hoses accommodate suspension movement without compromising airflow. Each component is leak-tested at 1.5x operating pressure to meet SAE J1401 and GB/T 20022 standards, guaranteeing safety and compliance with international regulations.​
  • The Shacman X6000 Air Compressor Outer Line/6×4 13L delivers unmatched durability and performance, essential for maintaining the pneumatic system’s efficiency in heavy-duty truck operations. Regular inspection of seal rings for wear, hose integrity for cracks, and fastener torque for looseness will ensure optimal functionality and extend the assembly’s service life. Trust in OEM-quality components to keep your vehicle’s air system running smoothly, even under the most demanding conditions.​

Product Parameters of Shacman X6000 Air Compessor Outer Line/6×4 13l

NO Part.No Name Quantity
1 DZ9100360434 Nozzle 1
2 190003098031 Seal ring 1
3 DZ9X189360011 Pipe 1
4 Q68620 Pipe clamp 6
5 DZ9L149360025 Bracket 1
6 Q33006 Nut 4
7 Q1840616 Hex.screw 4
8 DZ93319360018 Stainless steel hose 1
9 DZ9M189365068 Bracket 2
10 Q1811440TF3 Hex.screw 2
11 06.11251.2005 Nut 2
12 DZ9X259369017 Pipe 1
13 DZ9H319470406 Bracket 1
14 Q341B14T13F3 Nut 1
15 Q150B1430 Hex.screw 1
16 DZ9100360428 Nozzle 1
17 Q351B22T15 Nut 1
18 168000250092 Seal ring 1

Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-air-compessor-outer-line-6x4-13l.html/feed 0 Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog https://deruna.com/shacman-x6000-wheel-assembly-315-80r22-5-spare-parts-catalog.html https://deruna.com/shacman-x6000-wheel-assembly-315-80r22-5-spare-parts-catalog.html#respond Wed, 25 Jun 2025 09:13:00 +0000 https://deruna.com/?p=79844

Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog

Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog
Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog
Download Catalog
Get Quotation

What is the Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog？

  • The Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog offers a comprehensive range of OEM components designed to enhance safety, durability, and operational efficiency for commercial trucks. Engineered to meet the rigorous demands of long-haul and heavy-load applications, this catalog includes precision-manufactured wheels, tires, and accessories that ensure optimal performance on diverse road conditions. Below is a detailed breakdown of key components:​
  • 1. 315/80R22.5 Tyre (Steer Tread)​
  • The Steer Tread Tyre is optimized for front-axle use, featuring a symmetrical tread pattern that delivers precise handling, reduced rolling resistance, and enhanced cornering stability. Its deep grooves (≥14mm) and silica-compound rubber resist waterlogging and provide excellent grip on wet or icy surfaces, while the reinforced casing (18-ply rating) withstands high radial loads. The 315/80R22.5 size ensures compatibility with standard commercial wheel assemblies, making it ideal for steering axles in heavy-duty trucks.​
  • 2. 315/80R22.5 Tyre (Traction Tread)​
  • Designed for drive axles, the Traction Tread Tyre features an aggressive, non-directional tread with large lateral blocks to maximize grip in off-road and low-traction environments. Its self-cleaning design prevents mud and debris buildup, while the extra-thick shoulder rubber enhances resistance to curb damage and uneven wear. The tyre’s tubeless construction (ETRTO-compliant) reduces downtime from punctures, and the 16-ply rating ensures reliability under heavy payloads.​
  • 3. 9.00×22.5 Wheel (Steel)​
  • The 9.00×22.5 Steel Wheel is a rugged, cost-effective choice for commercial applications, constructed from high-strength low-alloy (HSLA) steel to withstand impact and fatigue. Its drop-center design facilitates easy tire mounting, while the powder-coated finish resists corrosion in harsh climates. The wheel’s 10-stud configuration (500mm PCD) aligns with Shacman X6000 specifications, ensuring secure hub attachment and balanced load distribution.​
  • 4. 9.00×22.5 Aluminum Wheel​
  • For fleets prioritizing fuel efficiency and heat dissipation, the 9.00×22.5 Aluminum Wheel offers a lightweight alternative, weighing 30% less than steel counterparts without compromising strength. Cast from aerospace-grade aluminum alloy, it features a polished surface treatment to resist oxidation and a reinforced rim flange to prevent bead damage. The wheel’s modular design supports quick installation and is compatible with both steer and drive axles.​
  • 5. TPMS Sensor (A) & TPMS Sensor (B)​
  • TPMS Sensor (A) (Front-Axle Specific): Monitors tire pressure and temperature in real time for steering wheels, transmitting data via 433MHz to the vehicle’s dashboard. Its compact, weatherproof design (IP67 rating) withstands wheel well vibrations and extreme temperatures, enabling proactive maintenance to avoid blowouts and uneven wear.​
  • TPMS Sensor (B) (Drive-Axle Specific): Engineered for drive axles, this sensor features a higher-temperature tolerance and enhanced signal penetration through dual-wheel configurations. Both sensors are factory-calibrated for 315/80R22.5 tires, ensuring seamless integration with the Shacman X6000’s onboard diagnostics system.​
  • 6. Wheel Casing​
  • The Wheel Casing (wheel rim) is the structural foundation for tire mounting, available in steel or aluminum variants to match vehicle specifications. Its precision-machined bead seats ensure airtight tubeless tire installation, while the offset (ET 值) and backspace dimensions are optimized for Shacman X6000’s suspension geometry, minimizing stress on wheel bearings and improving handling.​
  • 7. Wheel Nut & Protective Cap​
  • Wheel Nut: High-tensile steel nuts (10-grade, M22×1.5 thread) secure the wheel to the hub, featuring a conical seat to align with lug bolt angles and prevent rotational slippage. Zinc-plated with a black oxide finish, they resist rust and provide up to 300Nm of torque retention.​
  • Protective Cap: A durable plastic or aluminum Wheel Nut Protective Cap shields nuts from dirt, moisture, and impact, extending their service life. Its snap-on design matches the wheel’s aesthetic, available in standard black or chrome finishes to suit fleet preferences.​
  • The Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog combines these components to deliver a cohesive solution for wheel system maintenance and upgrade. Each part is rigorously tested for load capacity, vibration resistance, and compliance with international standards (ECE R108/R109, ISO 16949), ensuring safety and reliability in commercial operations. Regular inspection of tire tread depth, wheel nut torque, and TPMS functionality is recommended to maximize performance and minimize downtime.​

Product Parameters of Shacman X6000 Wheel Assembly 315/80R22.5-Spare Parts Catalog

NO Part.No Name Quantity Remark
1 DZ9X259611102 315/80R22.5 Tyre(Steer Tread) On Demand Guide tires
DZ9X259611152 315/80R22.5 Tyre(Traction Tread) On Demand Drive tires
2 DZ93259610710 9.00×22.5 Wheel On Demand Steel wheels
DZ95009610061 9.00×22.5 Aluminum Wheel On Demand Aluminum wheels (optional)
3 DZ97189716111 TPMS Sensor（A） On Demand Matching aluminum wheels (optional)
DZ97189716112 TPMS Sensor（B） On Demand Matching steel wheels (optional)
4 DZ93259615001 Wheel Casing On Demand
5 DZ95189611300 Wheel Nut On Demand
6 DZ93259610205 Wheel Nut Protective Cap On Demand


Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-wheel-assembly-315-80r22-5-spare-parts-catalog.html/feed 0 Shacman X6000 Pull Clutch Control Device https://deruna.com/shacman-x6000-pull-clutch-control-device.html https://deruna.com/shacman-x6000-pull-clutch-control-device.html#respond Wed, 25 Jun 2025 09:09:24 +0000 https://deruna.com/?p=79835

Shacman X6000 Pull Clutch Control Device

Shacman X6000 Pull Clutch Control Device
Shacman X6000 Pull Clutch Control Device
Download Catalog
Get Quotation

What is the Shacman X6000 Pull Clutch Control Device？

  • The Shacman X6000 Pull Clutch Control Device is a high-performance hydraulic system designed to ensure precise clutch engagement, reduce driver fatigue, and enhance operational efficiency in heavy-duty trucks. Engineered with durable components that prioritize reliability and smooth operation, this assembly integrates seamlessly with the vehicle’s powertrain to deliver consistent performance under demanding conditions. Below is a detailed breakdown of its key components:​
  • 1. Combined Pedal​
  • The Combined Pedal serves as the driver interface, integrating clutch and brake functions into a single ergonomic unit for intuitive control. Constructed from forged aluminum alloy for strength and lightweight design, it features a non-slip surface and optimized pivot point to minimize leg strain during frequent use. The pedal’s precision-machined linkage ensures linear motion transfer to the clutch master cylinder, enabling responsive engagement and disengagement.​
  • 2. Clutch Main Cylinder (D26)​
  • The Clutch Main Cylinder (D26) is the hydraulic heart of the system, converting pedal force into hydraulic pressure to actuate the clutch mechanism. Built with a corrosion-resistant steel bore and a high-temperature-resistant rubber piston seal, it delivers consistent fluid displacement for smooth clutch operation. The cylinder’s D26 specification denotes a 26mm bore diameter, optimized for balanced pressure output and compatibility with heavy-duty clutch loads.​
  • 3. Hose (Clutch)​
  • The Clutch Hose is a high-pressure hydraulic line designed to transfer fluid between the main cylinder and the operating cylinder. Constructed from reinforced rubber with a braided stainless-steel outer layer, it resists abrasion, ozone, and extreme temperatures, ensuring leak-free performance even in harsh engine bay environments. The hose’s flexible design allows for natural suspension movement without compromising hydraulic integrity.​
  • 4. Operating Cylinder​
  • The Operating Cylinder converts hydraulic pressure from the main cylinder into mechanical force to pull the clutch release fork. Featuring a precision-machined piston and a dust-proof boot, it minimizes friction and prevents debris ingress, maintaining consistent actuation over long service life. The cylinder’s compact design optimizes space within the transmission housing while delivering high thrust force for reliable clutch disengagement.​
  • 5. Hex.Screw & Hexagon Nut​
  • Multiple Hex.Screws (high-tensile steel, zinc-plated for corrosion resistance) secure critical connections, such as the pedal assembly to the firewall and the cylinders to their mounting brackets. Paired with Hexagon Nuts, these fasteners provide vibration-resistant clamping force, ensuring no play in the linkage. Their standardized hex drive allows easy installation and torque adjustment with common workshop tools.​
  • 6. Gasket & Hollow Bolt​
  • A Gasket (made from heat-resistant synthetic rubber) creates a leak-proof seal between the hydraulic components, such as the main cylinder to the hose fitting. The Hollow Bolt (used in fluid connections) features a central bore to allow hydraulic fluid passage while providing a secure threaded connection. Its flanged design distributes clamping pressure evenly, preventing gasket damage and ensuring long-term sealing integrity.​
  • The Shacman X6000 Pull Clutch Control Device combines these components to deliver a responsive, durable clutch actuation system that enhances drivability in commercial vehicles. Each part is rigorously tested for fatigue resistance, fluid compatibility, and dimensional precision, adhering to international standards for heavy-duty hydraulic systems. Regular maintenance—including fluid flush, gasket inspection, and fastener torque checks—will optimize performance and extend the device’s service life, ensuring smooth gear shifts and reliable operation even under maximum load conditions.​

Product Parameters of Shacman X6000 Pull Clutch Control Device

NO Part.No Name Quantity
1 Q1800820 Hex.Screw 5
2 Q1840825 Hex.Screw 4
3 Q32008 Hexagon nut 2
4 DZ9H259230301 Combined pedal 1
5 DZ9L149230004 Clutch main cylinder（D26） 1
6 DZ9X259230400 Hose（Clutch） 1
7 Q150B0820T1F3 Hex.Screw 4
8 DZ9H259230205 Operating cylinder 2
9 Q72314T5F Gasket 2
10 190003962621 Hollow bolt 1

Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-pull-clutch-control-device.html/feed 0 Shacman X6000 Battery Spare Parts Catalog https://deruna.com/shacman-x6000-battery-spare-parts-catalog.html https://deruna.com/shacman-x6000-battery-spare-parts-catalog.html#respond Wed, 25 Jun 2025 09:06:08 +0000 https://deruna.com/?p=79829

Shacman X6000 Battery Spare Parts Catalog

Shacman X6000 Battery Spare Parts Catalog
Shacman X6000 Battery Spare Parts Catalog
Download Catalog
Get Quotation

What is the Shacman X6000 Battery Spare Parts Catalog？

  • The Shacman X6000 Battery Spare Parts Catalog offers a comprehensive range of OEM components designed to maintain, repair, and optimize the truck’s power system. Engineered for durability and safety, these parts ensure reliable battery performance in demanding commercial applications. Below is a detailed breakdown of key components and their technical specifications:
  • 1. Battery Box Assembly & Cover
  • The Battery Box Assembly forms a rugged enclosure for the battery, constructed from corrosion-resistant steel with a powder-coated finish to withstand moisture and debris. The matching Battery Box Cover features a weatherproof seal and quick-release latches, protecting the battery from external elements while enabling easy access for maintenance. Its reinforced design resists impact and ensures proper ventilation to prevent thermal buildup.
  • 2. Battery Fixing Long Bolt (260mm)
  • These 260mm-long fixing bolts secure the battery to the box, crafted from high-tensile steel with a zinc-plated coating for rust resistance. The extended length allows for secure clamping across multiple battery cells, while the hexagon head design ensures easy torque adjustment to prevent vibration-induced loosening.
  • 3. Spring Pressure Plate & U-shaped Spacer
  • The Spring Pressure Plate applies consistent downward force to the battery, preventing movement during transit. Made from heat-treated spring steel, it maintains tension over time to avoid damage from excessive vibration. Paired with the U-shaped Spacer, which provides lateral support and spacing between battery modules, this combination ensures a stable, noise-free installation.
  • 4. (Battery) Pole Guard & Maintenance-free Battery (180Ah)
  • The Pole Guard shields the battery terminals from short circuits and physical damage, constructed from flame-retardant plastic with a snap-fit design for quick installation. The catalog includes a 180Ah Maintenance-free Battery featuring calcium-alloy plates for reduced water loss and self-discharge, ideal for long-haul operations requiring minimal upkeep.
  • 5. Zinc-plated Hexagonal Head Bolts
  • Multiple zinc-plated hex bolts (varying lengths) secure battery brackets, boxes, and electrical components. Rated for high tensile strength, these bolts resist corrosion and provide reliable fastening in high-vibration environments. Their standardized hex head allows compatibility with common tools for efficient installation.
  • 6. Chassis Power Distribution Box & Electromagnetic Main Power Switch
  • The Chassis Power Distribution Box organizes electrical connections, featuring labeled terminals and circuit breakers for easy troubleshooting. The Electromagnetic Main Power Switch offers remote-controlled power cutoff, enhancing safety by isolating the battery during maintenance or emergencies. It meets IP67 standards for dust and water resistance.
  • 7. Mounting Brackets & Hardware
  • Electromagnetic Main Power Switch Mounting Bracket: Fabricated from stamped steel, this bracket positions the switch for easy access while withstanding engine bay vibrations.
  • Chassis Electrical Box Mounting Bracket: Designed for secure chassis integration, it features pre-drilled holes for precise alignment with vehicle mounting points.
  • Battery Box Connection Bracket: Links multiple battery boxes together, ensuring structural stability and electrical continuity.
  • 8. All-metal Hexagonal Locknuts (Type 2, Zinc-plated)
  • These Type 2 locknuts provide vibration-proof fastening for critical components, with a nylon insert that creates friction to prevent loosening. Zinc-plated for corrosion resistance, they are rated for heavy-duty applications and comply with ISO standards for reliability.
  • 9. Hexagonal Flange Face-bearing Surface with Toothed Bolt (Fine Thread)
  • Featuring a serrated flange to grip mating surfaces, these toothed bolts (fine thread M14×1.5) ensure non-slip installation for battery brackets and covers. The fine thread allows precise torque control, while the flange distributes load evenly to prevent surface damage.
  • 10. Hexagonal Nut M7.112.40 M14×1.5-10-MAN183B1 with Flange
  • This specialized nut meets MAN183B1 standards, offering high tensile strength (10-grade) with a serrated flange for anti-rotation security. Used in critical load-bearing connections, it ensures long-term reliability in harsh operating conditions.
  • The Shacman X6000 Battery Spare Parts Catalog integrates these components to deliver a cohesive solution for battery system maintenance. Each part undergoes rigorous testing for durability, electrical safety, and compatibility, ensuring seamless integration with the vehicle’s power architecture. Whether replacing worn components or upgrading for enhanced performance, this catalog provides OEM-quality parts that uphold Shacman’s standards for commercial vehicle reliability. Regular inspection of fasteners, terminals, and protective covers is recommended to maintain optimal battery function and extend service life.

Product Parameters of Shacman X6000 Battery Spare Parts Catalog

NO Part.No Name Quantity
1 DZ9X259760107 Battery box cover 1
2 DZ9L149760015 Battery fixing long bolt/260mm 2
3 DZ9L149760014 Spring pressure plate 2
4 DZ9X259760214 U-shaped spacer 2
5 81.25470.0035 (Battery) pole guard 4
6 DZ95189761480 Maintenance-free battery (180Ah) 2
7 Q150B0620 Hexagonal head bolts (zinc plated) 2
8 Q150B0525 Hexagonal head bolts (zinc plated) 2
9 DZ9X259712166 Chassis power distribution box 1
10 DZ97189763010 Electromagnetic main power switch 1
11 Q150B0614 Hexagonal head bolts (zinc plated) 8
12 DZ9X259760211 Electromagnetic main power switch mounting bracket 1
13 Q33205 All-metal hexagonal locknut type 2 (zinc plated) 2
14 DZ9X259712168 Chassis electrical box mounting bracket 1
15 Q1811440TF3 Hexagonal flange Face-bearing surface with toothed bolt-fine thread 4
16 06.11251.2005 Hexagonal nut M7.112.40 M14*1.5-10-MAN183B1 with flange 8
17 DZ9X259764002 Battery box connection bracket 2
18 Q1811450TF3 Hexagonal flange face-bearing surface with toothed bolt-fine thread 8
19 DZ9X259760100 Battery box assembly 1
20 Q33206 Type 2 all-metal hexagonal locknut (zinc-plated) 10


Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-battery-spare-parts-catalog.html/feed 0 Shacman X6000 Curtain Assy https://deruna.com/shacman-x6000-curtain-assy.html https://deruna.com/shacman-x6000-curtain-assy.html#respond Wed, 25 Jun 2025 09:02:20 +0000 https://deruna.com/?p=79823

Shacman X6000 Curtain Assy

Shacman X6000 Curtain Assy
Shacman X6000 Curtain Assy
Download Catalog
Get Quotation

What is the Shacman X6000 Curtain Assy？

  • The Shacman X6000 Curtain Assy is a thoughtfully designed interior solution crafted to elevate driver comfort, privacy, and cab organization in commercial trucks. Engineered with durable materials and user-friendly components, this assembly integrates seamlessly into the vehicle’s cabin, providing functional separation of spaces while maintaining a sleek, professional appearance. Below is a detailed breakdown of its key components:​
  • 1. Ring Curtain Assembly​
  • The Ring Curtain Assembly serves as the primary divider for the truck’s cabin, allowing drivers to separate the living area from the cargo or work space with ease. Composed of a heavy-duty fabric curtain reinforced with metal rings, it glides smoothly along a pre-installed track system, ensuring quiet operation and minimal friction. The rings are evenly spaced to distribute weight and prevent sagging, while the fabric is treated for resistance to fading, abrasion, and moisture—ideal for long-haul environments where durability is critical.​
  • 2. Sleeper Retainer Curtain Assembly​
  • Designed for trucks with sleeper cabs, the Sleeper Retainer Curtain Assembly creates a private, enclosed space for rest, blocking light and reducing noise transfer between the driver’s seat and sleeping area. The curtain features a reinforced top edge with integrated hooks that secure to the cab’s overhead structure, providing a stable barrier that stays in place even during vehicle movement. Its flame-retardant material meets safety standards, adding an extra layer of protection for overnight stays.​
  • 3. Rear Window Curtain Assembly​
  • The Rear Window Curtain Assembly shields the cab from sunlight, glare, and external visibility, enhancing comfort and security for the driver. Made from a thick, opaque fabric with a reflective backing, it minimizes heat absorption while allowing easy adjustment via a simple drawstring or toggle system. The curtain attaches directly to the window frame using custom brackets, ensuring a snug fit that prevents gaps and maintains aerodynamic efficiency when the cab is in motion.​
  • 4. Ring Curtain Tie Downs​
  • Included Ring Curtain Tie Downs allow drivers to secure the curtain in an open position, keeping it neatly bundled against the cab wall to maximize interior space when separation is not needed. These tie downs are constructed from elasticized webbing with durable hook-and-loop fasteners, providing a secure hold without damaging the curtain fabric. Their low-profile design ensures they do not interfere with other cab components or seating arrangements.​
  • 5. Large Washers​
  • Large Washers play a critical role in the assembly’s installation, distributing the clamping force of screws and bolts across a wider surface area to prevent damage to the cab’s interior panels. Made from corrosion-resistant steel or high-impact plastic, they are paired with self-tapping screws to create stable mounting points for curtain tracks, brackets, and retainers. The oversized design ensures even load distribution, enhancing the longevity of both the hardware and the cab’s finish.​
  • 6. Phillips Slotted Pan Head Self-Tapping Screws​
  • These self-tapping screws are the primary fasteners for attaching curtain components to the cab’s metal or composite structures. Featuring a dual-drive (Phillips and slotted) pan head for versatile tool use, they eliminate the need for pre-drilled holes, simplifying installation and reducing setup time. The screws’ sharp threads cut cleanly into materials, creating a secure bond that resists vibration-induced loosening—essential for maintaining the curtain assembly’s integrity during long journeys.​
  • The Shacman X6000 Curtain Assy combines practical design with robust construction, offering a customizable solution to transform the truck cab into a functional, comfortable living and working space. Each component is engineered to withstand the rigors of commercial use, with easy-to-clean surfaces and modular installation that accommodates different cab configurations. Whether enhancing privacy for rest, controlling light and temperature, or organizing interior spaces, this assembly delivers reliable performance and aesthetic appeal, making it an essential upgrade for Shacman X6000 drivers. Regular inspection of fasteners and fabric condition will ensure optimal functionality and extend the life of the curtain system.​

Product Parameters of Shacman X6000 Curtain Assy

NO Part.No Name Quantity
1 DZ16251590020 Ring Curtain Assembly 2
2 DZ16251590060 Sleeper Retainer Curtain Assembly 1
3 DZ16251590070 Rear Window Curtain Assembly 1
4 DZ16251590022 Ring Curtain Tie Downs 2
5 Q402B05F60 Large Washers 2
6 Q2714816F31 Phillips Slotted Pan Head Self-Tapping Screws 2

Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-curtain-assy.html/feed 0 Shacman X6000 Rear Suspension (DC9X259521204) https://deruna.com/shacman-x6000-rear-suspension.html https://deruna.com/shacman-x6000-rear-suspension.html#respond Wed, 25 Jun 2025 08:59:13 +0000 https://deruna.com/?p=79817

Shacman X6000 Rear Suspension (DC9X259521204)

Shacman X6000 Rear Suspension (DC9X259521204)
Shacman X6000 Rear Suspension (DC9X259521204)
Download Catalog
Get Quotation

What is the Shacman X6000 Rear Suspension (DC9X259521204)？

  • The Shacman X6000 Rear Suspension (DC9X259521204) is a rugged, high-performance system engineered to handle extreme loads, absorb road shocks, and deliver unmatched stability for heavy-duty trucks. Designed with precision components that prioritize durability and reliability, this suspension integrates advanced engineering to optimize ride quality and structural integrity. Below is a detailed breakdown of its key components:​
  • 1. V Rod​
  • The V Rod (vertical rod) serves as a critical linkage between the rear axle and the vehicle frame, transmitting vertical forces while maintaining proper suspension geometry. Constructed from forged high-strength steel, it features heat-treated ends to resist bending and fatigue, ensuring consistent load distribution during acceleration, braking, and cornering.​
  • 2. Hexagon Head Bolt – Fine Thread​
  • These fine-thread hexagon bolts (e.g., M14×1.5) are used for precision fastening in critical suspension joints, offering superior torque control to prevent over-tightening. The fine thread pitch reduces thread stripping risks, while the hexagon head design allows easy installation with standard tools, essential for maintaining secure connections in high-vibration environments.​
  • 3. DTF Hexagon Nut With Collar M18×1.5​
  • Engineered for heavy-duty applications, the DTF Hexagon Nut With Collar M18×1.5 features an integral collar that enhances load distribution across mating surfaces, reducing indentation and improving shear resistance. The DTF (Direct Thread Forming) technology ensures durable thread engagement, making it ideal for securing major suspension components like the axle and spring brackets.​
  • 4. Hexagon Bolt With Shoulder M7.015.01 M20×2×75-10.9-ZNPHR 3F​
  • This specialized bolt includes a precision-machined shoulder that acts as a 定位 pin, ensuring accurate alignment between components like the trunnion shaft housing and frame. Rated at 10.9 strength class with a zinc-phosphate coating (ZNPHR 3F), it offers exceptional tensile strength and corrosion resistance, vital for load-bearing joints.​
  • 5. Hexagon Flange Toothed Bolt – Fine Thread​
  • Featuring a serrated flange to grip surfaces and prevent rotation, these bolts provide vibration-resistant fastening for secondary components such as spring clamps and brackets. The fine thread design (e.g., M14×1.5) allows precise torque application, ensuring secure connections without compromising thread integrity.​
  • 6. Rear Leaf Spring Assembly​
  • The Rear Leaf Spring Assembly is the core load-bearing component, consisting of multiple layered steel springs that absorb shocks and distribute weight evenly. Heat-treated and shot-peened for enhanced fatigue resistance, it works with the rubber bolster assembly to dampen vibrations, improving cargo protection and ride comfort even on uneven terrain.​
  • 7. Trunnion Shaft Bracket & Housing​
  • The Trunnion Shaft Bracket provides a rigid mount for the trunnion shaft, while the Housing encloses the conical bearing to protect it from debris. Both components are fabricated from nodular cast iron, offering high strength and wear resistance. The shaft’s precision alignment ensures smooth suspension articulation under heavy loads.​
  • 8. Conical Bearing & Bearing Cover​
  • The Conical Bearing enables controlled rotation of the trunnion shaft, minimizing friction during suspension movement. Encased in a robust Bearing Cover, it is sealed to prevent dust and moisture ingress, extending service life. The bearing’s tapered design withstands radial and axial loads, critical for maintaining suspension efficiency.​
  • 9. U-Bolt & Spring Clamp​
  • U-Bolts securely fasten the leaf spring to the axle, while Spring Clamps maintain proper spring alignment and spacing. Made from quenched-and-tempered steel, these components feature a galvanized finish to resist rust, ensuring long-term reliability in harsh conditions. Their curved design distributes clamping force uniformly across the spring surface.​
  • 10. Spherical Seat Nut M27×2​
  • Designed for the suspension’s articulating joints, the Spherical Seat Nut M27×2 provides a smooth, low-friction interface for spherical bearings. The fine pitch (M27×2) allows precise adjustment of bearing preload, ensuring consistent movement and reducing wear on connected components like the V rod and lower I rod.​
  • 11. High Strength Washer-24​
  • These 24mm high-strength washers are placed under bolt heads and nuts to distribute clamping force over a larger surface area, preventing damage to mating components. Constructed from 硬化 steel, they enhance joint stability and reduce the risk of fastener loosening in high-stress applications.​
  • 12. Bumper Assembly & Rubber Bolster Assembly​
  • The Bumper Assembly acts as a mechanical stop to prevent over-compression of the leaf spring, while the Rubber Bolster Assembly cushions impacts during heavy loading. The rubber bolster’s dual-layer design absorbs high-frequency vibrations, reducing noise and protecting the suspension from sudden shocks, ideal for off-road operations.​
  • 13. Lower I Rod​
  • The Lower I Rod (lateral rod) stabilizes the rear axle laterally, preventing side-to-side movement during cornering. Fabricated from hollow extruded steel for a strength-to-weight balance, it features adjustable ends to fine-tune suspension alignment, ensuring optimal handling and tire contact with the road.​
  • 14. Self-locking Thin Nut​
  • Used in space-constrained areas, the Self-locking Thin Nut provides secure fastening without adding excess weight. Its nylon insert locks onto threads to prevent loosening from vibrations, making it ideal for secondary components like brake line brackets and sensor mounts where reliability and compactness are essential.​
  • 15. Hex Socket Head Bolt​
  • These bolts feature a recessed hexagonal drive for a flush, low-profile installation, often used in areas with limited clearance. The socket design allows high torque application without damaging the fastener, ensuring secure attachment of components like the bearing cover and trunnion brackets.​
  • The Shacman X6000 Rear Suspension (DC9X259521204) combines these components into a cohesive system that excels in load-bearing capacity, durability, and ride control. Each part is rigorously tested for fatigue resistance, corrosion tolerance, and dimensional precision, adhering to international standards for commercial vehicle suspensions. Regular maintenance—including torque checks for fasteners, lubrication of moving joints, and inspection of wear components—will maximize performance and extend the suspension’s service life, ensuring reliable operation in the most demanding heavy-duty applications.​

Product Parameters of Shacman X6000 Rear Suspension (DC9X259521204)

NO Part.No Name Quantity
1 DZ96259520012 V Rod 2
2 Q151B1890TF3 Hexagon Head Bolt – Fine Thread 8
3 SZ952000867 DTF Hexagon Nut With Collar  M18×1.5 8
4 06.02202.1013 Hexagon Bolt With Shoulder M7.015.01 M20*2*75-10.9-ZNPHR 3F 8
5 Q151B1870TF3 Hexagon Head Bolt 12
6 Q1811480TF3 Hexagon Flange Toothed Bolt – Fine Thread 4
7 Q1811490TF3 Hexagon Flange Toothed Bolt 8
8 Q1811460TF3 Hexagon Flange Toothed Bolt -Fine Thread 20
9 06.11251.2005 Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1 40
10 190003888749 Self-locking Thin Nut 2
11 DZ9H319520435 Hex Socket Head Bolt 8
12 DZ9X259521216 Bumper Assembly 4
13 DZ9X259521212 Rubber Bolster Assembly 4
14 Q151C1225TF3 Hexagon Head Bolt – Fine Thread 16
15 Q151B18100TF3 Hexagon Head Bolt – Fine Thread 8
16 DZ9H319520468 Lower I Rod 4
17 DZ9X259521220 Rear Leaf Spring Assembly 2
18 DZ9X259521204 Trunnion Shaft Bracket 2
19 DZ9X259521218 Hexagon Head Bolt  M18×1.5×200 4
20 81.90685.0400 Spherical Seat Nut M27*2 8
21 DZ9X259521205 Trunnion Shaft Housing 2
22 DZ9X259521206 Conical Bearing 4
23 DZ9X259521207 Bearing Cover 2
24 DZ97259520403 High Strength Washer-24 2
25 DZ9M319520030 Hexagon Head Bolt M24×1.5×260 2
26 DZ9X259521210 U-Bolt 4
27 DZ9X259521209 Spring Clamp 2


Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-rear-suspension.html/feed 0 Shacman X6000 Rear Stabilizer https://deruna.com/shacman-x6000-rear-stabilizer.html https://deruna.com/shacman-x6000-rear-stabilizer.html#respond Wed, 25 Jun 2025 08:54:42 +0000 https://deruna.com/?p=79811

Shacman X6000 Rear Stabilizer

Shacman X6000 Rear Stabilizer
Shacman X6000 Rear Stabilizer
Download Catalog
Get Quotation

What is the Shacman X6000 Rear Stabilizer？

  • The Shacman X6000 Rear Stabilizer is a robust suspension component designed to enhance lateral stability, reduce body roll, and improve handling precision for commercial trucks, even under heavy payloads. Crafted with high-quality materials and innovative engineering, this assembly integrates critical components to deliver reliable performance in challenging road conditions. Below is a detailed breakdown of its key parts:​
  • 1. Pin Roll​
  • The Pin Roll serves as a pivotal connection point between the rear stabilizer bar and the vehicle’s suspension links, allowing controlled articulation during suspension travel. Constructed from case-hardened steel, it provides a low-friction pivot that withstands shear forces and rotational stress, ensuring smooth force transfer while minimizing wear. Its precision-machined surface ensures consistent alignment, vital for maintaining stabilizer effectiveness over time.​
  • 2. Front Stabilizer Bar UP Support Assembly​
  • Though named “Front,” this Support Assembly (adapted for rear application) reinforces the rear stabilizer bar’s mounting to the chassis, providing a rigid foundation to resist lateral movement. Fabricated from high-strength alloy steel, it features optimized geometry to distribute dynamic loads evenly, reducing stress on adjacent components. The assembly’s durable powder-coat finish enhances corrosion resistance, ideal for harsh environments.​
  • 3. Bush​
  • Rubber or polyurethane Bushings are strategically placed between the stabilizer bar and its mounting points to dampen vibrations and isolate metal-to-metal contact. These bushings absorb shocks from uneven terrain, reducing noise and preventing fatigue damage to the stabilizer structure. Their custom-molded design ensures a precise fit, maintaining optimal bar alignment and improving ride quality.​
  • 4. Stabilizer Bar Support Cover​
  • The Stabilizer Bar Support Cover protects the inner bushings and mounting hardware from dirt, water, and debris, extending component lifespan. Made from impact-resistant plastic or galvanized steel, it features a secure snap-fit or bolted design for easy installation and maintenance. The cover’s ribbed structure adds structural rigidity, enhancing the overall strength of the stabilizer mounting system.​
  • 5. Hexagon Bolt – Fine Thread​
  • Fine-thread hexagon bolts (e.g., M14×1.5) are used to fasten the stabilizer bar to its support brackets, offering precise torque control for secure clamping. The fine thread pitch reduces the risk of thread stripping under high tension, while the hexagon head allows easy adjustment with standard tools. These bolts undergo heat treatment to meet high tensile strength standards, ensuring reliable performance in load-bearing applications.​
  • 6. Rear Stabilizer Suspender Assembly​
  • The Rear Stabilizer Suspender Assembly connects the stabilizer bar to the axle or control arms, transmitting lateral forces to counteract body roll during turns. Engineered with forged steel links and durable ball joints, it allows articulation while maintaining rigid horizontal stability. The assembly’s adjustable design enables precise alignment, ensuring optimal performance across different vehicle configurations.​
  • 7. DTF Hexagon Nut With Collar M16×1.5​
  • The DTF Hexagon Nut With Collar M16×1.5 is a heavy-duty fastener designed for high-torque applications, featuring an integral collar that increases load distribution and prevents surface indentation. The DTF (Direct Thread Forming) technology enhances thread durability, while the M16×1.5 pitch provides a secure fit with coarse-thread bolts. This nut is critical for securing the stabilizer bar’s main mounting points, ensuring long-lasting vibration resistance.​
  • 8. Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1​
  • Paired with corresponding bolts, the Hexagon Flange Nut M7.112.40 M14×1.5-10-MAN183B1 secures secondary components like brackets and braces within the rear stabilizer system. Its serrated flange grips mating surfaces to prevent rotational slippage, while the fine thread allows precise tightening to manufacturer specifications. Rated to MAN183B1 standards, it offers superior tensile strength and resistance to environmental corrosion.​
  • 9. Hexagon Flange Toothed Bolt – Fine Thread​
  • These specialized bolts feature a toothed flange that locks onto surfaces, eliminating rotational movement in high-vibration scenarios. The fine thread design (M14×1.5) ensures accurate torque application, crucial for maintaining the preload required to keep the stabilizer bar securely attached to its supports. The combination of teeth and fine threads makes them ideal for critical connections that demand both strength and precision.​
  • The Shacman X6000 Rear Stabilizer Assembly integrates these components to deliver exceptional lateral control, enhancing safety and cargo protection for heavy-duty trucks. Each part is rigorously tested for fatigue resistance, corrosion tolerance, and structural integrity, adhering to international standards for commercial vehicle suspensions. Regular inspection of fasteners, bushings, and support components is recommended to maximize performance and service life, ensuring the stabilizer continues to excel in the most demanding operational environments.​

Product Parameters of Shacman X6000 Rear Stabilizer

NO Part.No Name Quantity
1 8191020.0618. Pin Roll 2
2 DZ9X259681009 Front Stabilizer Bar UP Support Assembly 2
3 81.43722.0068 Bush 2
4 81.43718.0045 Stabilizer Bar Support Cover 2
5 Q151B1665TF3 Hexagon Bolt – Fine Thread 4
6 8191020.062 Pin Roll 2
7 DZ9H259681012 Rear Stabilizer Suspender Assembly 2
8 SZ952000864 DTF Hexagon Nut With Collar  M16×1.5 2
9 06.11251.2005 Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1 8
10 DZ9X259681012 Rear Stabilizer Assembly 1
11 SZ952000864 DTF Hexagon Nut With Collar  M16×1.5 2
12 Q1811450TF3 Hexagon Flange Toothed Bolt – Fine Thread 8

Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-rear-stabilizer.html/feed 0 Shacman X6000 Rear Absorber https://deruna.com/shacman-x6000-rear-absorber.html https://deruna.com/shacman-x6000-rear-absorber.html#respond Wed, 25 Jun 2025 08:51:21 +0000 https://deruna.com/?p=79802

Shacman X6000 Rear Absorber

Shacman X6000 Rear Absorber
Shacman X6000 Rear Absorber
Download Catalog
Get Quotation

What is the Shacman X6000 Rear Absorber？

  • The Shacman X6000 Rear Absorber is a high-performance suspension component designed to mitigate road shocks, enhance vehicle stability, and improve cargo protection in heavy-duty applications. Engineered with durability and precision, this assembly integrates advanced components to deliver consistent performance across rugged terrains. Below is a detailed breakdown of its key parts:​
  • 1. Hexagon Head Bolt​
  • Crafted from high-tensile steel, the Hexagon Head Bolt provides robust fastening for critical connections within the rear absorber system. Its standardized hexagonal design allows easy installation and torque adjustment using common tools, ensuring secure attachment of the absorber to the vehicle frame. These bolts are heat-treated to withstand cyclic loading and vibration, maintaining structural integrity under dynamic stress.​
  • 2. Washer​
  • Flat washers are strategically placed between bolt heads/nuts and mating surfaces to distribute clamping force evenly, reducing surface wear and preventing damage to component interfaces. Made from corrosion-resistant materials, they enhance joint stability by minimizing friction and ensuring uniform load transfer, a vital function in high-impact suspension applications.​
  • 3. Rear Absorber Up Support Assembly​
  • The Rear Absorber Up Support Assembly serves as the primary mounting structure, connecting the rear absorber to the vehicle’s frame. Constructed from forged aluminum alloy for a balance of strength and lightweight design, this assembly provides rigid support while allowing controlled movement to absorb vertical shocks. Its precision-engineered geometry aligns the absorber to maintain optimal damping efficiency, even under heavy payloads.​
  • 4. Hexagon Flange Toothed Bolt – Fine Thread​
  • These specialized bolts feature a toothed flange that grips mating surfaces to prevent rotational slippage, a critical design for high-vibration environments. The fine thread (M14×1.5) offers precise torque control, enabling technicians to achieve optimal clamping force when securing the absorber to its mounting brackets. The combination of teeth and fine threads ensures long-lasting, vibration-resistant connections.​
  • 5. Thread Melt Technology​
  • Incorporating Thread Melt (a proprietary anti-loosening treatment), select fasteners in the assembly receive a thermoplastic coating on their threads. This coating melts under torque application, creating a solid bond that locks nuts in place, eliminating the risk of loosening due to continuous road vibrations. It provides a maintenance-free solution for retaining critical connections over extended service life.​
  • 6. DTF Hexagon Nut With Collar M16×1.5​
  • The DTF Hexagon Nut With Collar M16×1.5 is designed for heavy-duty applications, featuring a integral collar that increases load-bearing capacity and distributes stress over a larger surface area. The M16×1.5 thread pitch ensures compatibility with coarse-threaded bolts, while the DTF (Direct Thread Forming) design enhances resistance to stripping, making it ideal for high-torque scenarios in the rear absorber system.​
  • 7. Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1​
  • This specialized nut, paired with corresponding bolts, secures secondary components such as brackets and braces within the rear absorber assembly. The flange design with a serrated underside grips surfaces to prevent rotation, while the M14×1.5 fine thread offers precise tightening control. Rated to MAN183B1 standards, it meets rigorous industrial specifications for tensile strength and corrosion resistance.​
  • The Shacman X6000 Rear Absorber combines these components to deliver superior shock absorption, minimizing tire bounce and body roll for safer, more comfortable hauling. Each part is rigorously tested for fatigue resistance and chemical durability, ensuring compliance with international standards for commercial vehicle suspensions. Regular inspection of fasteners and support structures is recommended to maintain optimal performance and extend the assembly’s service life.​

Product Parameters of Shacman X6000 Rear Absorber

NO Part.No Name Quantity
1 Q151B2090TF3 Hexagon Head Bolt 4
2 8DZ9X259681011 Washer 4
3 DZ9X259681006 Rear Absorber Up Support Assembly 4
4 Q1811440TF3 Hexagon Flange Toothed Bolt -Fine Thread 16
5 DZ9X259681001 Rear Absorber Up Support Assembly 4
6 81.91020.0674 Thread Melt 4
7 SZ952000864 DTF Hexagon Nut With Collar  M16×1.5 4
8 06.11251.2005 Hexagon Flange Nut M7.112.40 M14*1.5-10-MAN183B1 16


Related Shacman Truck Spare Parts

Didn'T Find Your Truck Model?

If you have any problems or questions, please get in touch with us, we will
provide you with the best service.

Contact Us
]]> https://deruna.com/shacman-x6000-rear-absorber.html/feed 0
