FAW Engine Aseembly-Water Pump Group

FAW Engine Aseembly-Water Pump Group
FAW Engine Aseembly-Water Pump Group
Download Catalog
Get Quotation

What is the FAW Engine Aseembly-Water Pump Group

  • 1. Critical Engine Cooling System Component
    The Water Pump Group is essential for maintaining optimal operating temperature within the FAW WP13.550E501 Engine Assembly. Centered on the Water pump, this assembly drives continuous coolant circulation through the engine block, cylinder head, and radiator, preventing overheating and ensuring peak performance under heavy loads.
  • 2. Core Component & Function
  • Water pump: A heavy-duty, impeller-driven pump mechanically powered by the engine (typically via belt). It generates the necessary pressure to force coolant throughout the entire cooling system, absorbing engine heat and transferring it to the radiator.
  • 3. Precision Sealing & Monitoring
  • Seal ring: A critical component creating a leak-proof seal between the water pump housing and the engine block interface, preventing coolant loss.
  • Temperature sensor: Integrated within or near the pump housing/outlet, this sensor provides real-time coolant temperature data to the engine control unit (ECU) for optimal fan control and engine management.
  • Washer & Hexagon screw plug: The washer ensures a tight seal for the Hexagon screw plug, which typically serves as a drain point, air bleed port, or sensor mounting location within the cooling circuit.
  • 4. Secure Mounting & Harness Management
  • Vibration-Resistant Fastening: The pump is secured using multiple Hexagon flange face bolts. These bolts provide superior clamping force and resistance to loosening under engine vibration due to their integrated load-distributing flanges.
  • Wire harness support: A dedicated bracket or clip that securely routes and protects the wiring loom for the Temperature sensor, preventing damage from heat, abrasion, or vibration.
  • 5. Engineered for Heavy-Duty Reliability
    Every element of the FAW Water Pump Group – from the robust cast Water pump housing and wear-resistant impeller to the reliable Seal ring and vibration-proof Hexagon flange face bolts – is manufactured to stringent FAW OEM specifications. The inclusion of a Temperature sensor and protected wiring via the Wire harness support ensures accurate system monitoring. This group guarantees efficient coolant flow, effective heat dissipation, and leak-free operation, directly contributing to the WP13.550E501 engine’s durability, consistent power output, and prevention of costly overheating damage.

Product Parameters of FAW Engine Aseembly-Water Pump Group

Order Part NO. Part Name And Standards Oty
1000410A-DY889R WP13.550E501  Engine Aseembly 1
1 90011410005 Hexagon flange face bolt 2
2 1001053604 Wire harness support 1
3 612630060035 Temperature sensor 1
4 90003962020 Hexagon screw plug 1
5 612600080200 Washer 1
6 612630060056 Seal ring 1
7 1002342029 Water pump 1
8 9000000590 Hexagon flange face bolt 4
9 9000000641 Hexagon flange face bolt 1
