Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)
Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)
Download Catalog
Get Quotation

What is the Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts) is a highly sophisticated and meticulously crafted automotive seat solution. This assembly is engineered to provide superior comfort, safety, and durability for truck drivers and passengers.
  • At its core, the seat lower frame welding assembly forms the sturdy foundation, ensuring stability and structural integrity. The internal and external bracket welding assemblies are precisely attached, adding to the overall robustness of the seat. The gas spring, a key component, offers smooth adjustment capabilities, and the gas spring locking seat, along with the gas spring locking plate, allows for secure locking in the desired position.

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The use of various fasteners and components like hexagon socket head cap screws, Type 2 all – metal hexagonal lock nuts, and spring washers guarantees a tight and reliable connection between different parts. The inner limit block assembly and limit strip mounting plate help in defining the movement range of the seat, enhancing safety and functionality.
  • The upper frame assembly, in combination with the limit bracket assembly, provides support and stability to the overall structure. Oval head bolts and cross – recessed pan head tapping screws are used for secure attachment of different sub – assemblies. The skeleton fixing shaft assembly and open end blind rivets with break pull mandrel and flat round head ensure proper alignment and connection of various components.

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The cushion elevator frame and its cover, along with the spring, allow for height adjustment of the seat cushion. The lock plate and rotor Ⅰ are involved in the locking mechanism of the seat adjustment. Cables such as Cable IV and guide blocks are used for smooth operation and control.
  • The seat cushion fixing slider enables easy movement and adjustment of the seat cushion. The left and right seatback angle adjuster assemblies, along with the locking torsion springs on both sides, allow for precise adjustment of the backrest angle. Large washers and cross – recessed pan head screws are used for proper fastening.

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The left and right tie wire retainers, along with tie wires VI and VII, help in organizing and securing cables. Cotter rings, split rings, and open end rings are used for additional locking and securing purposes. Cable clamps and seat limit straps ensure the proper positioning of cables and limit the movement of the seat.

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The backrest frame welding assembly, along with the backrest trim cover fixing block, provides support and a finished look to the backrest. The seat belt cover, left and right torsion springs, and backrest mounting bolts are essential for the proper functioning and safety of the seat.
  • The internal tooth retaining ring and various cross – recessed pan head tapping screws are used throughout the assembly for secure attachment. The left and right seat rear and front trim covers, along with the right cover fixing bracket, enhance the aesthetic appeal of the seat.

  • Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

  • The seat cushion base plate, plate spring, and seat cushion upholstery provide comfort to the user. The seat cushion clamp and elevation handle assemblies allow for easy adjustment of the seat cushion height. The right seat frame welding assembly, right handle assembly, and rubber boot add to the functionality and durability of the right – hand side of the seat.
  • The right seat backrest upholstery, skin assembly, seat belt, and all related trim covers and holders are designed to provide a complete and comfortable seating experience. The seat cushion cover assembly gives the final touch to the seat, making it both functional and visually appealing. Overall, the Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts) is a comprehensive and high – quality seating solution for trucks.


Product Parameters of Sitrak Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)

AZ1662511004  Truck C7 Dual Locking Gas Spring Right Seat Assembly (With Seat Belts)
No. Part Number Part Name English  Quantity
1 AZ1662512101 Seat lower frame welding assembly 1
2 AZ1662512119 Internal and External Bracket Welding Assembly 1
3 WG1662510145 Gas Spring 1
4 WG1662510913 Gas Spring Locking Seat 1
5 WG1662510914 Gas spring locking plate 1
6 WG1662510146 Tension wire Ⅰ 1
7 Q43660 Open end retaining ring 1
7 Q43660 Opening retaining ring 1
8 WG1662510148 Fixed shaft Ⅰ 1
9 WG1662510149 Fixed shaft Ⅱ 1
10 WG1662512132 Slider 4
10 WG1662512132 Slider 4
11 Q218B0840 Hexagon socket head cap screws 2
12 Q33208 Type 2 all-metal hexagonal lock nuts 2
12 Q33208 Type 2 all-metal hexagonal locknut 2
13 WG1662510133 Inner limit block assembly 2
14 WG1662511932 Hexagon socket cheese head screws(II) 2
15 WG1662511150 Rubber cushion block 2
16 WG1662511163 Limit strip mounting plate 1
17 Q40308 Spring washers 1
17 Q40308 Spring washers 4
18 WG1662511931 Hexagon socket cheese head screws (Ⅰ) 1
18 WG1662511931 Hexagon socket cheese head screws (Ⅰ) 2
18 WG1662511931 Hexagon socket cheese head screws (Ⅰ) 4
19 WG1662511134 Upper frame assembly 1
20 WG1662510160 Limit bracket assembly 1
21 WG1662510142 Oval head bolts 2
22 WG1662510143 Inner limit block II 2
23 Q2725513F31 Cross recessed pan head tapping screws 2
25 WG1662511925 Limit Block 2
26 WG1662510229 Skeleton fixing shaft assembly 2
27 Q4400413T19 Open end blind rivets with break pull mandrel and flat round head 2
27 Q4400413T19 Open end blind rivets with break pull mandrel and flat round head 4
27 Q4400413T19 Open end blind rivets with break pull mandrel and flat round head 4
28 WG1662511152 Cushion Elevator Frame 1
29 WG1662511153 Cushion Elevator Frame Cover 1
30 WG1662511154 Spring 2
31 WG1662511155 Lock plate 2
32 WG1662511156 Rotor Ⅰ 2
33 WG1662511157 Cable IV 1
34 WG1662511158 Guide block 2
36 WG1662510220 Seat cushion fixing slider 4
37 Q4404825T19 Open end blind rivets with flat round head 4
38 WG1662511117 Left seatback angle adjuster assembly 1
39 WG1662510221 Right seatback angle adjuster assembly 1
40 Q4400611T19 Open end blind rivets with break pull mandrel and flat round head 4
41 WG1662511207 Locking torsion spring right 1
42 WG1662510225 Locking torsion spring left 1
43 Q40206 Large washers 2
44 Q2140612 Cross recessed pan head screws 2
45 WG1662510235 Left Tie Wire Retainer 1
46 WG1662510236 Right Tie Wire Holder 1
47 WG1662510234 Tie wire VI 1
48 WG1662510237 Wire Tie VII 1
49 Q43640 Cotter ring 4
49 Q43640 Split Ring 3
49 Q43640 Split ring 2
49 Q43640 Open end rings 1
51 Q2724219 Cross recessed pan head tapping screws 3
52 WG1662511912 Cable Clamp II 3
53 WG1662511162 Seat Limit Strap 1
55 WG1662511170 Rubber Cover Nail 16
56 WG1662512052 Slideway assembly 1
57 WG1662511302 Backrest Frame Welding Assembly 1
59 WG1662510331 Backrest Trim Cover Fixing Block 2
62 WG1662511923 Seat belt cover 1
65 Q218B0820 Hexagon socket cheese head screws 1
65 Q218B0820 Hexagon socket head cap screws 2
67 WG1662510336 Left Torsion Spring 1
68 WG1662510337 Right Torsion Spring 1
69 WG1662510335 Backrest mounting bolts 2
71 WG1662511911 Internal tooth retaining ring 2
73 Q2724213 Cross recessed pan head tapping screws 1
73 Q2724213 Cross recessed pan head tapping screws 1
74 WG1662510240 Left seat rear trim cover 1
75 Q2204295F31 Combination of cross recessed pan head tapping screws and flat washers 4
77 WG1662511926 Right cover fixing bracket 2
78 Q2204213F31 Cross recessed pan head tapping screws and flat washers assemblies 2
78 Q2204213F31 Cross recessed pan head tapping screws and flat washers assemblies 2
78 Q2204213F31 Cross recessed pan head tapping screws and flat washers assemblies 2
79 WG1662510241 Left seat front trim cover 1
80 WG1662511403 Seat cushion base plate 1
81 WG1662511409 Plate spring 2
82 Q4400408T19 Open end blind rivets with break pull mandrel and flat round head 2
83 WG1662510413 Cord retainer plate 1
84 WG1662510405 Seat cushion upholstery 1
85 WG1662510407 Seat Cushion Clamp 20
86 WG1662512146 Seat Cushion Elevation Handle Assemblies 1
87 Q2724216 Cross recessed pan head tapping screws 2
88 WG1662510201 Right Seat Frame Welding Assembly 1
89 WG1662510232 Right Handle Assembly 1
90 WG1662511161 Rubber Boot 1
91 WG1662511303 Right Seat Backrest Upholstery 1
92 WG1662512302 Right Seat Backrest Skin Assembly 1
93 WG1664560051 Right Seat Belt 1
94 WG1662511330 Right Seat Back Trim Cover 1
95 WG1662511934 Right Seat Belt Front Trim Cover 1
96 WG1662512150 Right seat belt holder assembly 1
97 WG1662510338 Right seat backrest adjustment handle 1
98 WG1662510006 Right seat right trim cover 1
99 WG1662511901 Right seat left trim cover 1
100 WG1662512075 Seat cushion cover assembly 1
