Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)

Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)
Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)
Download Catalog
Get Quotation

What is the Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)

  • The Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate) is a crucial component designed to offer exceptional towing performance while maintaining a lightweight structure.
  • At the heart of this setup is the Lightweight Rear Tow Hook Assembly. This assembly is engineered with precision to ensure optimal functionality and durability. It is specifically crafted to fit the lightweight tail beam of Sitrak vehicles, providing a secure connection point for towing operations.
  • One of the standout features of this tow hook is the Reinforcement plate. This plate adds an extra layer of strength to the tow hook, enhancing its ability to withstand heavy loads and stress during towing. It reinforces the connection between the tow hook and the vehicle’s tail beam, ensuring a stable and reliable towing experience.
  • To protect the components and prevent damage, a Rubber protection sleeve φ42×8 is included. This sleeve acts as a buffer, reducing friction and wear between the tow hook and other parts of the vehicle. It also helps to prevent corrosion and extends the lifespan of the tow hook assembly.
  • The assembly is securely fastened using a variety of high – quality bolts and nuts. The Hexagon head bolt M201.5 and Type 2 hexagonal nut M201.5 are used to provide a strong and tight connection at the main attachment points. These bolts and nuts are designed to withstand high torque and ensure that the tow hook remains firmly in place.
  • In addition, Hexagonal flange face bolts M141.5 and Hexagonal flange face nut M141.5 are used for other critical connections within the assembly. The flange face design provides a larger contact area, distributing the load more evenly and further enhancing the overall stability of the tow hook.
  • Overall, the Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate) is a well – engineered and reliable solution for all your towing needs. Its combination of lightweight design, reinforcement, and high – quality fasteners makes it an ideal choice for Sitrak vehicles.

Product Parameters of Sitrak Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)

AC91259300170 Tow Hook For Lightweight Tail Beam (Tga/With Reinforcement Plate)
No. Part Number Part Name English  Quantity
1 WG9725931230 Lightweight Rear Tow Hook Assembly 1
2 752W41210-0329 Reinforcement plate 1
3 WG9100360037 Rubber protection sleeve φ42×8 1
4 ZQ151B2065TF6 Hexagon head bolt M20*1.5 4
5 ZQ361B20T13F6 Type 2 hexagonal nut M20*1.5 4
6 ZQ1851435TF6 Hexagonal flange face bolts M14*1.5 8
7 ZQ32314T13F6 Hexagonal flange face nut M14*1.5 8
