Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)

Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)
Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)
Download Catalog
Get Quotation

What is the Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)

  • Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector): Superior Braking Performance and Safety Assurance​
  • The Sitrak St Dual Rear Axle Brake Unit Abs, designed for vehicles with a cast crossmember and 300 frame, integrates cutting-edge technology and robust components to deliver exceptional braking performance. Equipped with a Gb7258 test connector for seamless compliance with national safety standards, this unit ensures reliable operation and enhanced safety on the road.​
  • Core Braking and Control Components​
  • At the heart of the system, Relay valves play a crucial role in regulating air pressure, ensuring precise and responsive braking. Mounted securely on the Relay valve bracket, these valves work in tandem with the ABS system to prevent wheel lock-up during sudden stops. The ABS solenoid valve bracket (air suspension) provides a stable foundation for the solenoid valves, facilitating accurate control over the anti-lock braking function.​
  • Secure and Vibration-Resistant Assembly​
  • A variety of fastening elements and fittings guarantee a durable installation. Hexagonal flange face bolts M10 and Hexagonal flange nuts M10, along with Hexagonal flange bolts M8 and Hexagonal flange nuts M8, firmly attach key components, distributing pressure evenly and preventing loosening due to vibrations. The Hexagonal flange bolts with teeth M14*1.5 and Hexagonal flange nuts with teeth M14*1.5 offer enhanced grip for critical connections, ensuring long-term stability.​
  • Elastic elements NG8, Circlip NG8, and Nut seat NG8 work together to cushion and secure smaller components, absorbing shocks and reducing mechanical stress. Similarly, the Elastic element NG12, Clip spring NG12, and Nut seat NG12 provide robust support for larger parts, maintaining their position even under heavy braking forces.​
  • Efficient Air Flow and Wiring Management​
  • The system features a range of high-quality fittings for optimized air flow. Right angle joint body NG12/NW9, L-type tee fitting body NG12/2-NW9, Right angle fitting body NG8/NW6, Tee body 3-NW9, and Tee body NW9/NG12/TEST ensure smooth routing of air lines, minimizing pressure loss and ensuring consistent performance. The Polyamide tube (Φ12*1.5) offers durability and flexibility for air conveyance, resistant to corrosion and abrasion.​
  • For wiring organization, Tube bundle fixing bracket (ST double rear axle), Plastic fastening tape 2.4×92, Plastic fastening tape 3.6×140, BHT 375M Tie Tape, CSCT120R double head tie 7.6*380, and Wire Harness Fixing Clamp keep the wiring harnesses neatly arranged, preventing tangling and damage. This meticulous cable management not only simplifies maintenance but also enhances the overall reliability of the braking system.​
  • Design for Heavy-Duty Applications​
  • Tailored for heavy-duty vehicles, this brake unit is built to withstand the harsh conditions of continuous use. The inclusion of the Gb7258 test connector allows for easy diagnostic testing, ensuring the system remains compliant with safety regulations. Each component is rigorously tested for durability, corrosion resistance, and performance, making the Sitrak St Dual Rear Axle Brake Unit Abs a trusted choice for commercial fleets and professional drivers.​
  • SEO-Optimized Features​
  • Keyword Precision: Incorporates the full product name, frame details, test connector specification, and component names to target exact-match searches in parts catalogs, technical databases, and industry resources.​
  • Technical Depth: Details the function and benefits of each component, highlighting braking performance, secure assembly, and efficient management to attract automotive professionals, fleet managers, and vehicle maintenance experts.​
  • Benefit-Driven Messaging: Emphasizes safety, reliability, and compliance, addressing the key concerns of heavy-duty vehicle operators and owners seeking top-tier braking solutions.​
  • In summary, the Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector) sets a high standard for braking technology in heavy-duty vehicles. With its advanced components, secure installation, and compliance with national safety standards, it provides peace of mind and consistent performance in the most demanding driving scenarios.

Product Parameters of Sitrak St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)

712-#0320-2013 St Dual Rear Axle Brake Unit Abs (Cast Crossmember/300 Frame/With Gb7258 Test Connector)
Serial No. Drawing No.  Name Quantity
1 WG9000360524 Relay valves 2
2 WG9000361004 Elastic elements NG8 2
3 WG9000361005 Circlip NG8 2
4 WG9000361006 Nut seat NG8 2
5 WG9000361007 Elastic element NG12 6
5 WG9000361007 Elastic element NG12 4
5 WG9000361007 Elastic element NG12 8
6 WG9000361008 Clip spring NG12 6
6 WG9000361008 Clip spring NG12 4
6 WG9000361008 Clip spring NG12 8
7 WG9000361009 Nut seat NG12 6
7 WG9000361009 Nut seat NG12 4
7 WG9000361009 Nut seat NG12 8
8 WG9725360946 Relay valve bracket 2
9 ZQ1841030TF6 Hexagonal flange face bolts M10 4
10 ZQ32010T13F6 Hexagonal flange nuts M10 4
11 ZQ32008 Hexagonal flange nuts M8 4
11 ZQ32008 Hexagonal flange face nut M8 4
12 AZ9918360801 ABS solenoid valve bracket (air suspension) 2
13 ZQ1811450TF6 Hexagonal flange bolts with teeth M14*1.5 4
14 ZQ32514T13F6 Hexagonal flange nuts with teeth M14*1.5 4
15 ZQ1840875 Hexagonal flange bolts M8 4
16 WG9000361204 Right angle joint body NG12/NW9 1
16 WG9000361204 Right angle fitting body NG12/NW9 2
17 WG9000361305 L-type tee fitting body NG12/2-NW9 2
18 WG9725360187 Tube bundle fixing bracket (ST double rear axle) 1
19 752W51715-0182 Tube bundle fixing bracket (ST double rear axle) 1
20 ZQ1840812 Hexagonal flange bolts M8 2
21 ZQ1840825 Hexagonal flange bolts M8 2
22 WG9000361201 Right angle joint body NG8/NW6 2
23 WG9000361101 Right angle fitting body NG12/NW9 3
24 WG9000361310 Tee body 3-NW9 2
25 WG9000361406 Tee body NW9/NG12/TEST 8
26 811W97401-0580 Plastic fastening tape 2.4×92 4
27 811W97401-0746 Plastic fastening tape 3.6×140 6
28 190003179785 Polyamide tube (Φ12*1.5) 9
29 711W97401-3001 BHT 375M Tie Tape 20
30 711W97401-2002 CSCT120R double head tie 7.6*380 20
31 WG9925773050 Wire Harness Fixing Clamp 20
