Sitrak Scrubber Unit

What is the Sitrak Scrubber Unit

  • The Sitrak Scrubber Unit is a sophisticated and reliable component designed to ensure effective cleaning of the vehicle’s critical areas, such as windshields. This unit comprises a series of well – crafted parts that work in harmony to deliver top – notch performance.
  • The Scrubber assembly serves as the heart of the Sitrak Scrubber Unit. It is a carefully engineered combination of multiple elements that together form a functional system for delivering cleaning fluid precisely where it is needed. The Forming Tube is an integral part of this assembly. It is designed to guide the flow of the cleaning fluid in an efficient and controlled manner, ensuring that it reaches the intended areas with optimal pressure and coverage.
  • End caps are used to seal the ends of the tubes and components within the scrubber unit. They prevent leakage of the cleaning fluid and protect the internal parts from dirt, dust, and other contaminants. Plugs also play a similar role, closing off any openings to maintain the integrity of the fluid – delivery system.
  • The Left bracket and Right Bracket are essential for mounting the scrubber unit securely onto the vehicle. They provide stable support and proper alignment, ensuring that the scrubber unit functions correctly even under the vibrations and movements associated with vehicle operation. Clamps are used in conjunction with the brackets to hold the various components in place firmly, preventing any unwanted shifting or disconnection.
  • The Hose Tee is a vital component that allows for the splitting of the fluid flow. It enables the cleaning fluid to be distributed to multiple locations, such as different wiper blades or cleaning points, enhancing the overall cleaning efficiency of the Sitrak Scrubber Unit.
  • Round head bolts (M3299 – D – 6X 25 – ST – MAN183 – B1) and Hexagonal flange face nut M6 are used for fastening different parts of the scrubber unit. The round – head bolts provide a smooth and flush surface, while the hexagonal flange face nuts offer a secure and stable connection. The Washer hose assembly and Wash hose assembly are responsible for transporting the cleaning fluid from the reservoir to the scrubber assembly. They are designed to be flexible and durable, with proper insulation to prevent any leakage.
  • The Control valve is the key to regulating the flow of the cleaning fluid. It allows the driver to control when and how much cleaning fluid is dispensed, depending on the cleaning requirements. This provides a high level of flexibility and efficiency in using the Sitrak Scrubber Unit.
  • In conclusion, the Sitrak Scrubber Unit, with its diverse range of components including the Scrubber assembly, Forming Tube, End caps, and others, offers a comprehensive and effective cleaning solution for Sitrak vehicles, ensuring clear visibility and a clean driving environment.

Product Parameters of Sitrak Scrubber Unit

YC16D86-000001  Scrubber Unit
No. Part Number Part Name English  Quantity
1 810W26481-6049 Scrubber assembly 1
2 810W26481-0078 Forming Tube 1
3 810W26481-0080 End caps 1
4 810W96001-0519 Plugs 1
5 810W26488-0033 Left bracket 1
6 810W26488-0032 Right Bracket 1
7 810W97430-0032 Clamps 4
8 810W98131-0119 Hose Tee 1
9 MQ6-07213-4314 Round head bolts (M3299-D-6X 25-ST-MAN183-B1) 8
10 ZQ32006 Hexagonal flange face nut M6 1
11 712W37134-9005 Washer hose assembly 1
12 712W37134-9006 Wash hose assembly 1
13 810W26484-0009 Control valve 1
810W26481-6049 Washer Assembly
No. Part Number Part Name English  Quantity
1 810W26481-6049/1 Washer assembly(Yueqing Wanda) 1
2 810W26481-6049/2 Scrubber assembly(Shandong Huatong) 1
810W26481-6049/1 Washer Assembly(Yueqing Wanda)
No. Part Number Part Name English  Quantity
1 810W26481-0057/1 Seal(Yueqing Wanda) 1
2 810W26481-0065/1 Plug(Yueqing Wanda) 1
3 810W26481-0079/1 Washer Tank(Yueqing Wanda) 1
4 810W26485-6033/1 Window Washer Pump(Yueqing Wanda) 1
5 810W98131-0129/1 Two way(Yueqing Wanda) 1
810W26481-6049/2 Washer Assembly (Shandong Huatong)
No. Part Number Part Name English  Quantity
1 810W26481-0057/2 Seal ring (Shandong Huatong) 1
2 810W26481-0079/2 Scrubber tank (Shandong Huatong) 1
3 810W26485-6033/2 Window scrubber pump (Shandong Huatong) 1
