Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)

Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)
Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)
Download Catalog
Get Quotation

What is the Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)

  • The Sitrak Cooling System, tailored for C7h models with Wp10h and Wp10.5h engines, is engineered to meet the demanding needs of both medium wide body and wide body cabs. With an 868×720 module and a 730 opening fan, this cooling system is fully compliant with National 5 and National 6 emissions standards, ensuring optimal performance while reducing environmental impact. The inclusion of an intercooling steel pipe further enhances its efficiency, making it a reliable choice for heavy – duty applications.
  • At the heart of the system is the 868X720 Cooling Module, a robust unit designed to dissipate heat effectively. It is supported by the Radiator Left Bracket and Radiator right bracket, which are secured using Hexagonal flange bolts M8 and Large washer combinations, providing a stable and vibration – resistant installation. The Air shield and Gasket(OD60,ID13,3mm) work together to direct airflow and prevent coolant leakage, optimizing the cooling process.
  • The Expansion tank assembly(T7/C7 small) is a crucial component that helps regulate coolant levels and pressure within the system. It is connected to various hoses, including the Radiator inlet hose, Radiator water hose, Radiator outlet hose, Radiator Drain Hose, and Radiator filler hose, all of which are held securely in place by Hose Clamps, Wave spring clamps, and Strong Clamp. These clamps, such as the Wave spring clamp and Single pipe clamp(φ15), ensure leak – proof connections, even under high – pressure and high – temperature conditions.
  • The Intercooler air inlet hose is essential for cooling the intake air, improving engine performance. It is fastened using Hexagonal Flange Nut M8, Spring washers, and Hexagon head bolts, ensuring a tight and reliable connection. The Cooling Module Tie Rod Assembly provides additional structural support, enhancing the stability of the entire cooling system.
  • To protect the cooling module from debris, an Insect Screen Holder with an Insect screen (C7 center module) is included. This screen is mounted using Hexagonal flange bolts M8, preventing insects and other small particles from clogging the radiator fins. The Radiator Water Hose Bracket and Bracket, secured with Hexagonal flange bolts M6 and Hexagonal flange nuts M6, help route and support the hoses, maintaining proper alignment and reducing the risk of damage.
  • The Clamp (tube diameter 60mm) and Connecting hose are used to connect different parts of the system, ensuring a smooth flow of coolant. The Drain hose (engine) allows for easy maintenance and coolant replacement. Throughout the system, Wave Spring Clamps are used extensively to secure hoses and pipes, providing a secure and flexible connection that can withstand the rigors of heavy – duty vehicle operation.
  • In summary, the Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With) is a comprehensive and reliable solution for heavy – duty vehicles. Its robust construction, efficient design, and high – quality components, including a variety of bolts, nuts, clamps, and hoses, ensure stable operation, optimal heat dissipation, and long – term durability, making it an ideal choice for maintaining the performance of C7h models in various operating conditions.

Product Parameters of Sitrak Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)

YC96255300004 Cooling System (C7h/Wp10h/Wp10.5h/Medium Wide Body/Wide Body Cab/868×720 Module/730 Opening Fan/National 5/National 6/Intercooling Steel Pipe Comes With)
Serial No.  Drawing No. Name Quantity
1 YG9003982032 Wave spring clamp 2
2 WG9000365401 Single pipe clamp(φ15) 1
3 Q40208 Large washer 6
3 Q40208 Large washer 4
4 ZQ1840820 Hexagonal flange bolts M8 6
4 ZQ1840820 Hexagonal flange bolts M8 4
5 Q40206 Large washer 2
6 ZQ32006 Hexagonal flange nuts M6 2
6 ZQ32006 Hexagonal flange nuts M6 1
7 190003989300 Hose Clamps 2
8 YG9003981627 Wave spring clamps 2
9 WG9925530139 Insect Screen Holder 2
10 712W06201-0001 Insect screen (C7 center module) 1
11 ZQ1840825 Hexagonal flange bolts M8 3
12 YG9625530101 Radiator Left Bracket 1
13 YG9625530102 Radiator right bracket 1
14 712W06100-0101 868X720 Cooling Module 1
15 712W06620-0101 Air shield 1
16 712W91701-0001 Gasket(OD60,ID13,3mm) 2
17 YG9725530030 Expansion tank assembly(T7/C7 small) 1
18 YG9625530109 Cooling Module Tie Rod Assembly 2
19 WG9925530240 Large washer 4
20 YG9625530129 Radiator inlet hose 1
21 YG9625530128 Radiator water hose 1
22 YG9625530130 Radiator Water Hose Bracket 1
23 WG9326530118 Bracket 1
24 WG9925531301 Clamp (tube diameter 60mm) 2
25 WG9326530120 Connecting hose 1
26 712W96301-0105 Radiator outlet hose 1
27 YG9725530012 Radiator Drain Hose 1
28 712W96301-0108 Radiator filler hose 1
29 712W96301-0109 Drain hose (engine) 1
30 WG9003981910 Strong Clamp 4
31 712W96301-0067 Intercooler air inlet hose 1
32 ZQ32008 Hexagonal Flange Nut M8 2
32 ZQ32008 Hexagonal Flange Nut M8 2
33 Q40312 Spring washers 2
34 Q151C1295 Hexagon head bolts 2
35 ZQ1841025 Hexagonal flange bolts M10 8
36 ZQ1840845 Hexagonal flange bolts M8 2
37 ZQ1840835 Hexagonal flange bolts M8 2
38 ZQ1840630 Hexagonal flange bolts M6 2
39 YG9003985070 Wave Spring Clamps 4
39 YG9003985070 Wave Spring Clamps 1
40 YG9003986080 Wave Spring Clamps 1
712W06100-0101 868X720 Cooling Module
Serial No.  Drawing No. Name Quantity
1 712W06100-0101/1 868X720 Cooling Module(Taian Dingxin) 1
2 712W06100-0101/2 868X720 Cooling Module(Jinan Beier) 1
712W06100-0101/1 868X720 Cooling Module(Taian Dingxin)
Serial No.  Drawing No. Name Quantity
1 712W06100-0102/1 Radiator Assembly(Taian Dingxin) 1
2 712W06100-0103/1 Intercooler Assembly(Taian Dingxin) 1
712W06100-0101/2 868X720 Cooling Module (Jinan Beier)
Serial No.  Drawing No. Name Quantity
1 712W06100-0102/2 Radiator Assembly(Beier Jinan) 1
2 712W06100-0103/2 Intercooler Assembly(Behr Jinan) 1
