Sitrak Clutch Hydraulic Actuator (C7h)

Sitrak Clutch Hydraulic Actuator (C7h)
Sitrak Clutch Hydraulic Actuator (C7h)
Download Catalog
Get Quotation

What is the Sitrak Clutch Hydraulic Actuator (C7h)

  • The Sitrak Clutch Hydraulic Actuator (C7h) is a high – performance, precision – engineered component designed to enhance the efficiency and reliability of the clutch system in C7h commercial vehicles. This advanced actuator plays a crucial role in transmitting hydraulic force to engage and disengage the clutch, ensuring smooth gear shifts and optimal vehicle performance.
  • The Clutch Brake Fluid Labeling is an essential feature that provides clear and precise information regarding the type and level of brake fluid required for the system. This labeling helps prevent improper fluid use, which could lead to reduced performance or system failure, ensuring that the actuator operates at its best with the correct fluid specifications.
  • The High Pressure Hose is a key component of the actuator, engineered to withstand high – pressure hydraulic fluid flow. Made from durable, reinforced materials, this hose ensures leak – free operation and reliable transfer of hydraulic power from the master cylinder to the clutch booster cylinder. Its robust construction allows it to endure the rigors of heavy – duty use, including exposure to vibrations, temperature fluctuations, and mechanical stress.
  • The Hollow Bolt and Sealing washer work in tandem to create a secure and leak – proof connection within the hydraulic system. The hollow bolt facilitates the passage of hydraulic fluid while providing a strong fastening point, and the sealing washer ensures that there are no fluid leaks at the connection points, maintaining the integrity and efficiency of the hydraulic circuit.
  • The Clutch booster cylinder (Φ102, Φ25) is the heart of the actuator, responsible for amplifying the hydraulic force applied to the clutch. With its precisely engineered diameters (Φ102 and Φ25), this cylinder provides the necessary mechanical advantage to engage and disengage the clutch smoothly, even under heavy loads. Its durable construction and high – quality components ensure long – lasting performance and reliable operation.
  • To ensure secure installation and prevent components from loosening during operation, the actuator utilizes various fastening elements. The External serrated lock washer and Hexagon head bolt M8 combination provides a vibration – resistant connection, while the Elastic element NG8, Circlip NG8, and Nut seat NG8 work together to secure and position other critical parts. These components are carefully selected for their strength and reliability, ensuring that all parts of the actuator remain firmly in place, even in the demanding environment of commercial vehicle operation.
  • In summary, the Sitrak Clutch Hydraulic Actuator (C7h) is a comprehensive and reliable solution for enhancing the performance of the clutch system in C7h vehicles. With its high – quality components, precise engineering, and attention to detail, this actuator offers commercial vehicle operators a dependable and efficient means of controlling their clutch, contributing to smoother driving, improved fuel efficiency, and extended vehicle lifespan.

Product Parameters of Sitrak Clutch Hydraulic Actuator (C7h)

AC99252300404 Clutch Hydraulic Actuator (C7h)
Serial No.  Drawing No. Name Quantity
1 WG9114230019 Clutch Brake Fluid Labeling 1
2 WG9123230037 High Pressure Hose 1
3 190003962621 Hollow Bolt 1
4 Q72314T5F Sealing washer 2
5 WG9725230041 Clutch booster cylinder (Φ102, Φ25) 1
6 Q41208 External serrated lock washer 4
7 ZQ150B0818 Hexagon head bolt M8 4
8 WG9000361004 Elastic element NG8 1
9 WG9000361005 Circlip NG8 1
10 WG9000361006 Nut seat NG8 1
