Sitrak Clamp Body Assembly (Left)

Sitrak Clamp Body Assembly (Left)
Sitrak Clamp Body Assembly (Left)
Download Catalog
Get Quotation

What is the Sitrak Clamp Body Assembly (Left)

  • Sitrak Clamp Body Assembly (Left): Precision Engineering for Heavy – Duty Performance
  • The Sitrak Clamp Body Assembly (Left) is a crucial component designed to provide reliable and precise clamping force in heavy – duty applications. This assembly is meticulously engineered with a focus on durability, functionality, and ease of maintenance.
  • The Transmission and adjustment mechanism (left) is the heart of the assembly. It is designed to efficiently transmit the clamping force and allows for precise adjustment to meet the specific requirements of different operations. The mechanism is constructed with high – quality materials to ensure long – lasting performance under heavy loads.
  • The Bracket provides a stable and secure mounting platform for the other components of the clamp body assembly. It is made from strong and durable materials to withstand the stresses and vibrations associated with heavy – duty use.
  • The Slide pin protection sleeve compression ring and Slide Pin Protective Sleeve work together to protect the slide pins. The compression ring helps to maintain the proper tension on the protective sleeve, ensuring that it effectively shields the slide pins from dust, debris, and other contaminants. This protection is essential for the smooth operation and longevity of the slide pins.
  • The Slide pin bushing reduces friction between the slide pins and the clamp body, allowing for smooth and effortless movement. It is made from a low – friction material that is also resistant to wear and tear.
  • The Short Slide Pins and Long slide pins are integral to the clamping action. They are precisely machined to ensure a perfect fit and smooth operation. The Hexagon socket head cap screws and Hexagon socket cheese head screws are used to secure the various components of the assembly together. These screws are made from high – strength materials and are designed to provide a secure and reliable connection.
  • The Slide pin cover (short slide pin side) and Slide pin cover (long side) protect the slide pins from external damage and also help to keep the area clean. They are easy to install and remove, facilitating maintenance and inspection of the slide pins.
  • In summary, the Sitrak Clamp Body Assembly (Left) is a well – designed and high – quality component that offers reliable clamping performance in heavy – duty applications. Its precision engineering, durable construction, and easy – to – maintain design make it an ideal choice for a wide range of industrial and commercial uses.

Product Parameters of Sitrak Clamp Body Assembly (Left)

AZ4007443010 Clamp Body Assembly (Left)
Serial No.  Drawing No. Name Quantity
1 AZ4007443032 Transmission and adjustment mechanism (left) 1
2 AZ4007443002 Bracket 1
3 WG4007443015 Slide pin protection sleeve compression ring 2
4 WG4007443117 Slide Pin Protective Sleeve 2
5 WG4007443012 Slide pin bushing 3
6 WG4007443014 Short Slide Pins 1
7 Q218B1680TF2 Hexagon socket head cap screws 1
8 WG4007443018 Slide pin cover (short slide pin side) 1
9 WG4007443016 Slide pin cover (long side) 1
10 Q218B1690TF2 Hexagon socket cheese head screws 1
11 WG4007443013 Long slide pins 1
