What is the Sitrak C7 Dashboard Assembly (Narrow Body-Nano-Quadrant, Air Duct Improvement)

  • The Sitrak C7 Dashboard Assembly (Narrow Body-Nano-Quadrant, Air Duct Improvement) is a meticulously engineered automotive interior solution designed to enhance driver comfort, operational efficiency, and cabin ergonomics for commercial vehicles. Combining a space-saving narrow body design with advanced air duct optimization, this assembly integrates precision components to deliver superior functionality, durability, and aesthetic appeal.​
  • Structural Core and Ergonomic Layout​
  • At the heart of the dashboard lies the Dashboard Left Assembly (Narrow Body – Square Position) and Instrument Panel Right Section Assembly-Narrow Body, forming a balanced framework that maximizes cockpit space without compromising on structural integrity. The Instrument Cover Panel Assembly and Switch Panel Assembly provide intuitive access to critical controls, while the Narrow Body Long Storage Box with Long Storage Box Pad offers practical storage solutions for drivers. The Instrument Panel Center Upper Skeleton Assembly reinforces the dashboard’s rigidity, ensuring long-term resistance to vibration and wear.​
  • Air Duct System Optimization​
  • A key innovation of this assembly is its improved air duct network, designed to enhance climate control efficiency. The Left Front Defroster Grille Assembly and Right Front Defroster Grille Assembly (Narrow Body) deliver precise airflow for windshield defrosting, while side and footwell ducts like the Driver’s Side Exterior Side Duct – Narrow Body and Left interior footwell duct (narrow body) ensure uniform temperature distribution. The inclusion of Passenger Side Interior Door Duct – Wide Body and symmetrical driver-side ducts balances airflow for both occupants, reducing energy consumption and improving comfort in all weather conditions.​
  • Mounting and Installation Components​
  • Robust mounting solutions ensure secure integration with the vehicle’s frame. The Driver’s Side Upper Mounting Bracket (Narrow Body), Lower Mounting Bracket Assembly, and Passenger Side Instrument Panel Bracket provide stable support, while Hexagon head bolts, spring washers, and flat washer assemblies offer industrial-grade fastening for heavy-duty applications. Plastic Push Pins and Self-tapping screws simplify installation of trim and accessory components, ensuring a snug fit without damaging the dashboard surface.​
  • Trim, Sealing, and Finishing​
  • Aesthetic and functional trim elements elevate the cabin’s appearance and usability. The Left Side End Panel Assembly and Right Side End Panel Assembly create a sleek, cohesive look, while Trim Cover and Center Shield Assembly components conceal internal structures for a polished finish. Spring Washers and Flat Washers on fasteners prevent loosening due to vibrations, while Foam Pad inserts reduce noise and improve sealing around air ducts and storage compartments.​
  • Accessibility and Safety Features​
  • Driver-centric design elements include the Front Cabin Handle for secure entry/exit and A-Pillar Armrests that enhance comfort during long hauls. Safety is prioritized with covers like the Clutch Cover-Narrow Body and Brake and Throttle Cover-Narrow Body, protecting vital components from debris and accidental damage. The Diagnostic Interface Cover Pad provides easy access to vehicle diagnostics while shielding connectors from dust and moisture.​
  • Precision Fastening and Compatibility​
  • The assembly relies on a diverse range of fasteners to ensure reliability, including Cross recessed pan head tapping screws with flat washers for trim and panel attachments, and Circlips for securing movable duct components. Standardized components like the Center Harness Channel Assembly and Driver’s Side Harness Channel-Narrow Body simplify wiring management, while symmetrical designs (e.g., Passenger Side Interior Side Duct-Narrow Body) ensure interchangeability and ease of maintenance across fleet vehicles.​
  • Engineered for commercial vehicles that demand both performance and comfort, the Sitrak C7 Dashboard Assembly combines a space-efficient narrow body design with cutting-edge air duct technology. Every component—from structural skeletons to airflow grilles—is precision-crafted to meet OEM standards, ensuring seamless integration, durability, and a driver-focused experience. Ideal for logistics, construction, and long-haul fleets, this assembly sets a new benchmark for ergonomic excellence and functional innovation in narrow-body dashboards.

Product Parameters of Sitrak C7 Dashboard Assembly (Narrow Body-Nano-Quadrant, Air Duct Improvement)

812-#0511-0038 C7 Dashboard Assembly (Narrow Body-Nano-Quadrant, Air Duct Improvement)
Serial No.  Drawing No. Name Quantity
1 812W61701-6325 Dashboard Left Assembly (Narrow Body – Square Position) 1
2 812W61701-0197 Front Cabin Handle 1
3 812W61701-0236 Instrument Cover Panel Assembly 1
4 812W61701-0242 Switch Panel Assembly 1
5 812W61701-0250 Diagnostic Interface Cover Pad 1
6 812W61701-6225 Instrument Panel Right Section Assembly-Narrow Body 1
7 812W61701-6230 Left Side End Panel Assembly 1
8 812W61701-6235 Right Side End Panel Assembly 1
9 812W61701-0253 Narrow Body Long Storage Box 1
10 812W61701-8529 Long Storage Box Pad 1
11 812W61701-6271 Sliding Block 2
13 812W61701-6295 Instrument Panel Center Upper Skeleton Assembly 1
14 812W61470-0025 Left Lower Siding Assembly-Narrow Body 1
15 812W61701-0195 Plastic Push Pins 1
15 812W61701-0195 Plastic Push Pin 4
16 812W61470-0032 Center Shield Assembly 1
17 812W61942-6004 Center Lower Shield Assembly-Narrow Body 1
18 812W61470-0015 Right Lower Shield Assembly-Narrow Body 1
19 812W61950-0301 Right center shield assembly (narrow body) 1
20 812W61940-0122 Trim Cover 1
21 812W61950-0273 Left Front Defroster Grille Assembly 1
22 812W61950-0275 Right Front Defroster Grille Assembly (Narrow Body) 1
23 812W96020-0432 Circlip 6
24 812W61950-0371 Driver’s Side Exterior Door Duct (Narrow Body) 1
25 812W61950-0373 Driver’s Side Interior Door Duct 1
26 812W61950-0375 Passenger Side Interior Door Duct – Wide Body 1
27 812W61950-0381 Driver’s Side Exterior Side Duct – Narrow Body 1
28 812W61950-0383 Driver’s Side Interior Side Duct (Narrow Body) 1
29 812W61950-0384 Passenger Side Interior Side Duct – Wide Body 1
30 812W61950-0388 Left interior footwell duct (narrow body) 1
31 812W61950-0389 Right side interior foot duct 1
32 812W61950-0317 Driver’s side center foot duct – narrow body 1
34 812W61950-0310 Co-Pilot Side Exterior Foot Duct Assembly 1
36 812W61950-0342 Foot Air Outlet 1
37 812W61430-0057 Clutch Cover-Narrow Body 1
38 812W61430-0059 Brake and Throttle Cover-Narrow Body 1
40 812W62430-0030 Driver’s Side Instrument Panel Bracket 1
41 812W61701-0283 Driver’s Side Upper Mounting Bracket (Narrow Body) 1
42 812W62430-0065 Driver’s Side Lower Mounting Bracket Assembly (Narrow Body) 1
43 812W62430-0130 Passenger Side Instrument Panel Bracket 1
44 812W62430-0032 Instrument Panel Front Mounting Bracket (Narrow Body) 1
45 812W61701-6242 Rear instrument panel mounting bracket assembly (narrow body) 1
46 812W62430-0034 Center Harness Channel Assembly 1
47 812W61701-0271 Left center shield assembly 1
48 812W96002-0468 Plug 1
50 812W61950-0318 Driver’s Side Exterior Foot Duct Assembly-Narrow Body 1
51 812W97001-5091 A-Pillar Armrest-Right 1
52 812W97001-5096 B-Pillar Armrest-Narrow 1
53 812W97001-5092 B-pillar armrest-narrow body-right 1
54 812W97001-5095 A-pillar armrest 1
55 YZ16D216000003 Passenger Side Interior Side Duct-Narrow Body 1
56 YZ16D216000004 Passenger Side Interior Defrost Duct-Narrow Body 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 3
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 8
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 5
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 5
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 7
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 1
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 6
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 8
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 4
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 4
57 Q2204816F31 Cross recessed pan head tapping screws and flat washers assemblies 2
58 Q2204825 Cross recessed pan head tapping screws and flat washers assemblies 1
59 Q2140820F31 Cross recessed pan head screws 3
59 Q2140820F31 Cross recessed pan head screws 3
59 Q2140820F31 Cross recessed pan head screws 3
59 Q2140820F31 Cross recessed pan head screws 3
60 Q40108F31 Flat washers 3
60 Q40108F31 Flat washers 3
60 Q40108F31 Flat washers 3
60 Q40108F31 Flat Washers 3
61 Q40310F31 Spring Washers 1
61 Q40310F31 Spring Washers 1
61 Q40310F31 Spring Washers 3
61 Q40310F31 Spring Washers 3
62 812W61700-8352 Ashtray assembly 1
63 Q2204219F31 Self-tapping screws 1
63 Q2204219F31 Self-tapping screws 1
64 812W61950-6061 Center Air Vent Assembly 1
65 812W62430-0041 Driver’s Side Harness Channel-Narrow Body 1
66 812W61441-0001 Foam Pad 2
67 Q1460825F31 Hexagon head bolts, spring washers and flat washer assemblies 2
67 Q1460825F31 Hexagon head bolts, spring washers and flat washer assemblies 2
67 Q1460825F31 Hexagon head bolt, spring washer and flat washer assembly 2
67 Q1460825F31 Hexagon head bolts, spring washers and flat washer assemblies 2
