What is the Sitrak C5 Midland Detection Radar

  • The Sitrak C5 Midland Detection Radar is an integral part of the vehicle’s advanced safety and detection system. It comes with a well – structured bumper assembly (CU Radar) that serves as the protective housing and mounting base for the radar unit.
  • Several circlip nuts are used in the assembly process. These nuts are crucial for ensuring a secure and stable connection between different components, preventing any unwanted loosening during the vehicle’s operation.
  • The upper decorative mesh not only adds an aesthetic touch to the front of the vehicle but also protects the underlying components from dust and debris. It is fastened in place using cross – recessed pan head tapping screws. These screws are known for their ease of installation and reliable holding power, and they are used in multiple locations, including for the middle decorative mesh.
  • The middle decorative mesh further enhances the vehicle’s appearance while also playing a role in protecting the radar system. The left and right decorative plates are installed on either side, providing a balanced and stylish look.
  • To ensure safety, the left and right anti – skid plates are included. These plates prevent slipping in certain areas around the radar and bumper assembly. Washers are used in combination with dodecagonal bolts to evenly distribute the load and prevent damage to the components during tightening.
  • The bumper left bracket assembly and bumper right bracket assembly are essential for mounting the bumper and the radar unit securely to the vehicle’s frame. Hexagonal flange with teeth bolts M141.5 and hexagonal flange nuts with teeth M141.5 are used to firmly attach these brackets, providing a strong and stable connection.
  • Overall, the Sitrak C5 Midland Detection Radar and its associated components work together to provide a reliable and visually appealing solution for the vehicle’s detection needs.

Product Parameters of Sitrak C5 Midland Detection Radar

712-#04A0-0123 Bumper (C5H2376) (Midland Detection Radar)
No. Part Number Part Name English  Quantity
1 712W41610-6006 Bumper Assembly (CU Radar) 1
2 WG1632110004 Circlip Nut 7
2 WG1632110004 Circlip Nut 4
2 WG1632110004 Circlip Nut 4
3 812W41610-0533 Upper decorative mesh 1
4 Q2714816F31 Cross recessed pan head tapping screws 7
4 Q2714816F31 Cross recessed pan head tapping screws 4
4 Q2714816F31 Cross recessed pan head tapping screws 4
5 812W41610-0534 Middle Decorative Mesh 1
6 812W41610-0535 Left decorative plate 1
7 812W41610-0536 Right Decorative Plate 1
8 812W41610-0537 Left anti-skid plate 1
9 812W41610-0538 Right Skid Plate 1
10 MQ6W41610-0249 Washers 6
11 MQ6W90410-0014 Dodecagonal Bolt 6
12 752W41610-5002 Bumper Left Bracket Assembly 1
13 752W41610-5003 Bumper right bracket assembly 1
14 ZQ1811435TF2 Hexagonal flange with teeth bolt M14*1.5 6
15 ZQ32514T13F2 Hexagonal flange nut with teeth M14*1.5 6
