What is the Sitrak Brake Base Plate Assembly

  • The Sitrak Brake Base Plate Assembly is a crucial component in the braking system of Sitrak vehicles, designed to provide a stable and reliable foundation for the braking mechanism. This assembly plays a vital role in ensuring efficient braking performance and enhancing the overall safety of the vehicle.
  • The Brake Base Plate is the main structural element of the assembly, serving as a mounting platform for various braking components. It is typically made from high-quality steel or cast iron, ensuring durability and strength to withstand the forces generated during braking. The base plate is precisely machined to provide accurate positioning and alignment of the other components, ensuring optimal braking performance.
  • The Joint Bearing is an essential part of the assembly, allowing for smooth movement and articulation of the braking components. It is designed to reduce friction and wear, ensuring long-lasting performance and reliability. The joint bearing is typically made from high-quality materials such as steel or bronze, and is lubricated to ensure smooth operation.
  • The Oil Seal Seat and Oil Seal are used to prevent the leakage of lubricating oil from the braking system. The oil seal seat provides a secure mounting surface for the oil seal, while the oil seal itself is designed to create a tight seal around the rotating components, preventing oil from escaping. The oil seal is typically made from high-quality rubber or synthetic materials, and is designed to withstand the harsh conditions of the braking system.
  • The Hole retaining ring is used to secure the oil seal in place, preventing it from moving or dislodging during operation. It is typically made from high-quality steel or stainless steel, and is designed to provide a secure and reliable hold.
  • The Grease nipple assembly (AM8*1 D71412) is used to lubricate the joint bearing and other moving components of the braking system. It consists of a grease nipple, which is used to inject lubricating grease into the system, and a cap, which is used to prevent the ingress of dirt and debris. The grease nipple assembly is typically made from high-quality materials such as steel or brass, and is designed to be durable and reliable.
  • The Metric tapered thread grease nipple and Grease Nipple Cap are also important components of the assembly. The metric tapered thread grease nipple is used to ensure a secure and leak-free connection between the grease nipple and the lubricating system, while the grease nipple cap is used to prevent the ingress of dirt and debris.
  • In conclusion, the Sitrak Brake Base Plate Assembly is a critical component in the braking system of Sitrak vehicles, providing a stable and reliable foundation for the braking mechanism. Its high-quality components, precise machining, and reliable design ensure optimal braking performance and enhance the overall safety of the vehicle.

Product Parameters of Sitrak Brake Base Plate Assembly

711-50202-6127 Brake Base Plate Assembly
Serial No.  Drawing No. Name Quantity
1 712W50202-0127 Brake Base Plate 1
2 WG9761349009 Joint Bearing 1
3 710W50308-0014 Oil Seal Seat 1
4 WG9761349008 Oil Seal 1
5 710W96501-0843 Oil Seal 1
6 710W29029-0005 Hole retaining ring 1
7 AZ9003963030 Grease nipple assembly (AM8*1 D71412) 1
AZ9003963030 Grease nipple assembly (AM8*1 D71412)
Serial No.  Drawing No. Name Quantity
1 190003963112 Metric tapered thread grease nipple 1
2 AZ9003963010 Grease Nipple Cap 1
